NG Hook up Guide
1
Prior to installation make sure you have all the
neccessary equipment before moving forward.
In this kit you should have received:
NG regulator *1pc
NG Jet 1.85mm *4pcs
2
Before you begin your installation rst start by
taking o both the front control panel and rear
access panel.
* Keep all hardware
2-2
2-1
There are 6 screws on the rear panel of your grill. Remove them and carefully take the panel o .
Set aside screws for later.
2-3
2-4
2-5
Remove the 2 screws holding
Next, remove the front panel of
Once removed, you may need to
together the gas line. Set aside
your grill. There are two screws on
disconnect the four ignitor wires
screws for later.
both sides of the grill.
from the panel. This allows for
easier access.
Advertisement
Table of Contents
Related Manuals for Grilla Grills PRIMATE PM-500-A
Summary of Contents for Grilla Grills PRIMATE PM-500-A
- Page 1 NG Hook up Guide Prior to installation make sure you have all the neccessary equipment before moving forward. In this kit you should have received: NG regulator *1pc NG Jet 1.85mm *4pcs Before you begin your installation rst start by taking o both the front control panel and rear access panel.
- Page 2 NG Hook up Guide Remove LP jet with spanner wrench Install NG jet with sealing glue. Remove LP connector with spanner wrench. Install NG regulator to make sure the OUT side connect to bellows.
- Page 3 NG Hook up Guide Reassemble control panel Fix NG regulator with phillips head screw driver Remove four knobs of the control panel. The regulator is set to LP by default, switch the valve rod with straight screwdriver clockwise 1.5~2 rotations, check the gas ow with ow gauge to meet standard pro essional regulations.
