Chimp Front Shelf
CHIMP REV-1 MODEL
Install (Page 2-3)
If you DO NOT have two holes
located on both ends of your
chimp, you have a previous model.
Please continue to the next page
to complete installation.
CHIMP REV-2 MODEL
Install (Page 4)
If you have two holes located on
both ends of your chimp you
have a updated model. Please
continue to page 4 to complete
installation.
1
Advertisement
Table of Contents
Related Manuals for Grilla Grills CHIMP REV-1
Summary of Contents for Grilla Grills CHIMP REV-1
- Page 1 Chimp Front Shelf CHIMP REV-1 MODEL Install (Page 2-3) If you DO NOT have two holes located on both ends of your chimp, you have a previous model. Please continue to the next page to complete installation. CHIMP REV-2 MODEL...
- Page 2 Chimp Front Shelf CHIMP REV-1 MODEL INSTALL First start by removing the existing base skirt screws. To do this you will need to access the inside of your grill. Remove screws and nuts using a screwdriver and 7/16” socket *Save the hardware for Step 3.
- Page 3 Chimp Front Shelf Once the brackets are in place, take 2 of the 4 screws supplied and install them into the inward most screw holes. Take your front shelf and position it onto the brackets. Try and rest the shelf on the back two screws while applying upward pressure.
- Page 4 Chimp Front Shelf CHIMP REV-2 MODEL INSTALL Take 2 of the 4 screws supplied and install them into the inward most screw holes. Take your front shelf and position it onto the brackets. Try and rest the shelf on the back two screws while applying upward pressure.
