LED EMERGENCY EXIT SIGN
FOR MODEL: LFACLED502B
INTRODUCTION
The LED Emergency Exit
Sign has a 3.3W LED
strip and will last for
3 hours in emergency
mode. It comes with an
up arrow exit legend
included.
SPECIFICATION
220-
LED
240V
• Dimensions:
Blade: L: 300 x W: 170 x D: 10mm
Face: L: 410 x W: 135 x D: 10mm
• LED: 10 x White LED
• Working Temperature: 0°C - 40°C
BOX CONTENTS
• 1 x LED Emergency Exit Sign
• 1 x Arrow Up Legend
SAFETY WARNING
• The installation should be carried out by a qualified electrician in compliance with the current edition
of the IEE Wiring Regulations.
• Prior to installation carry out the necessary risk assessment considering the people who could be at
risk, the level of risk and the precautions required to control the risk.
• Ensure that the circuit supply is isolated either by the circuit supply fuse being removed or the
applicable circuit breaker being turned off before installation or any maintenance.
• Check the total load on the circuit including the luminaire does not exceed the rating of the circuit
cable, fuse or circuit breaker.
• If the fitting incorporates control gear, ensure careful sizing to avoid instances of nuisance tripping of
the protective device used in the installation.
•
Follow the provided installation instructions, using the fixings supplied or recommended.
INSTALLATION INSTRUCTIONS
1. Ensure there is adequate free air circulation of at least 100mm
around the fitting. All fittings run hot. It is the installer's
responsibility to consider any fire risk and take appropriate
precautions.
Red Arrow Trading
Elsworth House, Herries Road South
Sheffield, S6 1QS
6000K-
9lm
IP20
7000K
T: 0800 195 0006 F: 0870 195 0006
E: sales@redarrowtrading.com
www.redarrowtrading.com
3.3W
