- Page 1 AVM101LH INSTALLATION/OWNER’S MANUAL Multimedia Receiver with Bluetooth featuring a 10.1" Touch Screen Display...
- Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
-
Page 3: Safety Information
Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your Axxera AVM101LH is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only. - Page 4 AVM101LH INSTALLATION Preparation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
- Page 5 AVM101LH INSTALLATION Wiring Diagram - Inputs/Outputs USB INPU T CAMERA AUDIO INPUT BT AN TEN NA HDMI HD MI INPU T USB CH ARG E SW C-I R Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage.
-
Page 6: Control Locations
AVM101LH OPERATION Control Locations 3 4 5 Mircophone MicroSD Card Volume Up Power / Mode IR Sensor Camera Volume Down Reset Audio Power Go To / * Key Mode Loudness / Bluetooth Talk Play / Pause Number Keys Mute Root... -
Page 7: Remote Control Preparation
AVM101LH OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly. -
Page 8: General Operation
AVM101LH OPERATION General Operation Power On/Off Press to turn the unit on. Press and hold to turn the unit off. Volume Press Volume Up or Volume Down to increase or decrease the volume level. USB Port Connect a USB device to the USB port on the front panel to play MP3 files or view JPG photos. - Page 9 AVM101LH OPERATION General Operation From the Main Menu screen, press Settings in the bottom right corner to Setup Menu access the Setup Menu and select from the following categories: General, Audio, Video and Bluetooth. General: • OSD Language - Select English only.
-
Page 10: Am/Fm Tuner Operation
AVM101LH OPERATION AM/FM Tuner Operation Radio Operation Select the Radio icon from the Main Menu screen. Main Menu Press to return to Main Menu screen. Current Mode Indicator Displays current mode of operation. Tune Frequency Down Press momentarily to tune the unit down one step at a time. Press and hold to tune down by seeking the next strong station. - Page 11 AVM101LH OPERATION AM/FM Tuner Operation Press and hold to automatically store the six strongest stations in the AS/PS current band as presets. Press briefly for a preset scan, which will scan all preset stations and play 10 seconds of each. Press again to cancel the scan and continue playing the current station.
-
Page 12: Usb Operation
AVM101LH OPERATION USB Operation To play MP3 files from a USB device, insert device into the USB CD/MP3 slot on the front of the unit and playback will begin automatically. To or JPG Operation return to USB playback from another mode of operation, select the corresponding icon from the Main Menu. - Page 13 AVM101LH OPERATION USB Operation 9 10 Folder Search Press to access the directory of folders and files. Use the up/down arrows to scroll through the folder list, then press on the name of the desired folder to access it. Use the up/down arrows to scroll through the file list, then press on the name of the desired file to access it.
-
Page 14: Bluetooth Operation
The unit broadcasts the pairing signal constantly when no devices are currently connected. Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "Axxera AVM101LH". The Bluetooth passcode "0000". - Page 15 AVM101LH OPERATION Bluetooth Operation Screen Press to adjust screen brightness or put the monitor into standby mode. Audio Press to access audio setting such as EQ, Surround Sound Settings and Field Settings (Balance and Fader). Settings Press to access the Settings Menu.
- Page 16 AVM101LH OPERATION Rear RCA A/V Input Using AV Input Connect an optional audio/video source to the rear auxiliary input (Red/White/ Yellow RCA connectors). Refer to page 6 for details. Select AV Input from the Main Menu to listen to audio.
-
Page 17: Limited One Year Warranty
AVM101LH OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You What to do? may also have other rights which vary from state to 1. Before you call for service, check the state. troubleshooting guide in your owner’s manual. A slight adjustment of any custom controls may save Dual Electronics Corp. -
Page 18: Specifications
AVM101LH OPERATION Specifications FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range: 530kHz-1710kHz Usable sensitivity: 24uV Frequency response: 30Hz-2.3kHz Front USB Compatibility: High Speed USB 2.0... -
Page 19: Troubleshooting
Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your Axxera product. Dealer Name... - Page 20 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.axxeraaudio.com ©2018 Dual Electronics Corp. All rights reserved. NSA0418-V02 Printed in China...
