Toyota RAV4 1999 Quick Start Manual

1999-2000 steering steering columns - standard
Hide thumbs Also See for RAV4 1999:
Table of Contents

Advertisement

Quick Links

Download this manual
DESCRIPTION & OPERATION
Steering column is a collapsible 2-piece design. Columns use shear pins to absorb collision impact. Steering
shaft is connected directly to steering gear with either a flexible coupling or "U" joint. Some models have an air
bag integral with the steering wheel pad.
NOTE:
For models with tilt wheel steering columns, see appropriate STEERING
COLUMNS - TILT WHEEL article.
WARNING:
To avoid injury from accidental air bag deployment, read and carefully
follow all SERVICE PRECAUTIONS. Deactivate air bag system before
performing any repairs. See DISABLING & ACTIVATING AIR BAG
SYSTEM .
SERVICE PRECAUTIONS
Observe the following precautions when servicing Supplemental Restraint System (SRS):
Disable SRS before servicing any SRS or steering column component. Failure to do this could result in
accidental air bag deployment and possible personal injury. See DISABLING & ACTIVATING AIR
BAG SYSTEM .
Remove air bag sensor assembly/center air bag sensor and front air bag sensors if repairing the vehicle
requires impacting (shocking) the vehicle.
Replace dropped, cracked, dented or otherwise damaged components.
DO NOT expose front air bag sensors, air bag sensor assembly/center air bag sensor or steering wheel
pad (air bag module) directly to heat or flame.
Information labels are attached to air bag components. Follow all notices on labels.
After work on SRS is completed, check air bag warning light to ensure system is functioning properly.
See appropriate AIR BAG RESTRAINT SYSTEMS article in ACCESSORIES & EQUIPMENT.
Always wear safety glasses when servicing or handling an air bag.
When placing a live air bag on a bench or other surface, always face air bag and trim cover upward, away
from surface. This will reduce motion of module if it is accidentally deployed.
Carry a live air bag module with trim cover (air bag) pointed away from your body to minimize injury in
case of accidental deployment.
If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and
becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way
disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and
functions properly.
1999 Toyota RAV4
1999 Toyota RAV4
1999-2000 STEERING Steering Columns - Standard
1999-2000 STEERING Steering Columns - Standard
1999-2000 STEERING
Steering Columns - Standard

Advertisement

Table of Contents
loading

Related Manuals for Toyota RAV4 1999

Summary of Contents for Toyota RAV4 1999

  • Page 1 1999 Toyota RAV4 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard 1999-2000 STEERING Steering Columns - Standard 1999-2000 STEERING Steering Columns - Standard DESCRIPTION & OPERATION Steering column is a collapsible 2-piece design. Columns use shear pins to absorb collision impact. Steering shaft is connected directly to steering gear with either a flexible coupling or "U"...
  • Page 2 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard DISABLING & ACTIVATING AIR BAG SYSTEM WARNING: Back-up power supply maintains SRS voltage for about 90 seconds after battery is disconnected. After disabling SRS, wait at least 90 seconds before servicing SRS to prevent accidental air bag deployment and possible personal injury.

  • Page 3: Removal And Installation

    1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 1: Adjusting Air Bag Spiral Cable (Typical) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. REMOVAL & INSTALLATION WARNING: Failure to follow air bag service precautions may result in air bag deployment and personal injury.
  • Page 4 See Fig. 2 . Fig. 2: Removing Steering Wheel Pad (Typical) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. 3. Pull steering wheel pad from steering wheel, and disconnect air bag electrical connector. Remove steering wheel pad.

  • Page 5: Torque Specifications

    1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard 1. To install, reverse removal procedure. Before installing steering wheel, ensure spiral cable is properly aligned. See ADJUSTMENTS . Tighten steering wheel nut and Torx screws to specification. See TORQUE SPECIFICATIONS .

  • Page 6: Steering Wheel & Air Bag

    1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard 1. Disconnect and shield negative battery cable. Remove steering wheel pad. Remove steering wheel. See STEERING WHEEL & AIR BAG . 2. Remove upper and lower steering column covers. Disconnect connectors. Remove 4 screws and air bag spiral and combination switch.
  • Page 7 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 3: Identifying Bolts For Removing Intermediate Shaft (Celica Shown; Tundra Is Similar) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. Removal & Installation (Corolla)
  • Page 8 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard 1. Disconnect and shield negative battery cable. Remove steering wheel. See STEERING WHEEL & AIR BAG . 2. Remove front door scuff plate and cowl side trim. Remove instrument cluster lower finish panel after disconnecting hood release handle.
  • Page 9 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard shift lever assembly. 5. If equipped with 2WD, place match marks across intermediate shaft and steering gear shaft. Loosen clamp bolt just above floorboard. Remove lower "U" joint bolt at steering gear shaft connection.

  • Page 10: Steering Column

    1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard 3. Align match marks on No. 2 "U" joint assembly and No. 2 intermediate shaft assembly. Align match marks on control valve shaft and No. 2 intermediate shaft assembly. Install "A" and "B" bolts. See Fig. 3 .

  • Page 11: Specifications

    1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Ensure lock mechanism, key cylinder, key interlock solenoid (A/T), and ignition switch operate properly. Check column bearing for rotating smoothness. Replace column housing if bearing or housing shows any damage. Check steering shaft for bends, damaged splines or damaged "U" joints. Repair or replace components as necessary.
  • Page 12 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 4: Identifying Energy Absorbing Plates (RAV4) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. Inspection Ensure lock mechanism, key cylinder, ignition switch, key unlock warning switch and key interlock solenoid (A/T) operate properly. Check column bearing for rotating smoothness. Replace column housing if bearing or housing shows any damage.
  • Page 13 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Disassembly (Tacoma) 1. Place steering column assembly in vise. Center punch and drill into both steering column bracket bolts. Use screw extractor to remove bolts. 2. Remove snap ring from shaft assembly. Using soft-face hammer, tap shaft assembly from column tube.
  • Page 14 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Reassembly 1. Install compression ring and spring retainer. Ensure main shaft assembly does not rotate. Install main shaft stopper. Install NEW lower column tube attachment, bolt and washer to column tube support.
  • Page 15 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 5: Exploded View Of Steering Column (Celica) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
  • Page 16 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 6: Exploded View Of Steering Column (Corolla) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
  • Page 17 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 7: Exploded View Of Steering Column (RAV4) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
  • Page 18 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 8: Exploded View Of Steering Column (Tacoma) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
  • Page 19 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 9: Exploded View Of Steering Column (Tundra) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
  • Page 20 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Fig. 10: Exploded View Of Steering Column (4Runner) Courtesy of TOYOTA MOTOR SALES, U.S.A., INC. TORQUE SPECIFICATIONS TORQUE SPECIFICATIONS Application Ft. Lbs. (N.m)
  • Page 21 1999 Toyota RAV4 1999-2000 STEERING Steering Columns - Standard Intermediate Shaft-To-Mainshaft Bolt 26 (35) Steering Column Bracket Retaining Bolts/Nuts 19 (25) Steering Column Lower Bracket Bolt (Celica) 11 (15) Steering Column Tube Support/Attachment Bolt (RAV4) 14 (19) "U" Joint Bolt 26 (35) INCH Lbs.
