INSTALLATION AND OPERATING INSTRUCTIONS
Models: GCB-18i, -24i, -36i, -48i Gas Char-Broilers
Models: GCRB-18i, -24i, -36i, 48i Gas CharRock Broilers
WARNING: California Residents Only. This product can expose you to chemicals including
chromium which is known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information go to www.P65Warnings.ca.gov.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause property
damage, injury or death. Read and understand these instructions thoroughly before
positioning, installing, maintaining or servicing this equipment.
WARNING: Instructions must be posted in a prominent location. All safety precautions
must be taken in the event the user smells gas. Safety information can be obtained from
your local gas supplier.
APW Wyott Food Service Equipment Company is a wholly owned subsidiary of Standex International Corporation.
972.908.6100 Phone
214.565.0976 Fax
DESIGNED SMART. BUILT SOLID.
APW Wyott Food Service Equipment Company
1307 N. Watters Road, Suite 180 • Allen, TX 75013
®
1
P/N 882201 09/18
+1.800.527.2100
www.apwwyott.com
Advertisement
Table of Contents
Related Manuals for APW Wyott GCB-18i
Summary of Contents for APW Wyott GCB-18i
- Page 1 P/N 882201 09/18 APW Wyott Food Service Equipment Company 1307 N. Watters Road, Suite 180 • Allen, TX 75013 APW Wyott Food Service Equipment Company is a wholly owned subsidiary of Standex International Corporation. 972.908.6100 Phone +1.800.527.2100 214.565.0976 Fax...
-
Page 2: Table Of Contents
® refrigeration equipment. APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully. -
Page 3: Safety Precautions
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and follows these instructions. If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, 1307 N. Watters Road, Suite 180 • Allen, TX 75013 SAFETY PRECAUTIONS DANGER: This symbol warns of imminent hazard which will result in serious injury or death. -
Page 4: General Installation Instructions
B IN. (MM) C IN. (MM) D IN. (MM) # OF BTU/kW PER TOTAL BTU/kW W.C. BURNERS BURNER HOUR IN.(‘Mbar’) NATURAL GAS GCB-18i 18 (457) 24.1 (639) 15.6 (396) 9.0 (229) 60,000/17.5 60,000/17.5 6/10(15/25) GCB-24i 24 (610) 24.1 (639) 15.6 (396) 8.6 (219) -
Page 5: Conversion
DIMENSIONS: GCB-18i & GCRB-18i CONVERSION • Instructions are for conversion from Natural Gas to Propane (L.P.) on all models GCRB and GCB. • The conversion should be done before connecting the unit to the gas supply. • Units are shipped from the factory equipped for use on natural gas. Orifices necessary for LP (propane) are provided in a bag tied to the valve on the front panel. - Page 6 If the pilot goes out, an automatic shutoff valve turns off the gas supply to the burners. To relight the pilot, follow this procedure: • Turn the control valve to “OFF”. Wait a sufficient length of time to allow gas, which may have accumulated in the burner compartment, to escape (at least five minutes).
-
Page 7: Operation Instructions
CAUTION: Never attempt to move a grill section while cooking. An unexpected flare could cause severe injury. Turn off the unit, let it cool and use potholders and/ or gloves to reposition or remove. The space between the legs at the bottom admits combustion air. -
Page 8: Cleaning/Maintenance
SKETCH 1 SKETCH 2 CLEANING / MAINTENANCE Initial Cleaning: Prior to operating your new broiler, thoroughly wash the exterior with a mild detergent or soap solution. Do not use abrasive cleaners, since this might damage the cabinet finish. If the stainless steel surfaces become discolored, scrub by rubbing only in the direction of the finished grain. -
Page 9: Service/Repair
C. Burner ports must be kept clean. To clean burners, boil them in a strong solution of lye water for fifteen to twenty minutes. Then, either brush with a wire brush or clean gas ports with a sharp pointed metal instrument to insure open ports. CAUTION: Clean the regulator at least once a month. - Page 10 PLACE ROCKS WITH ARI SPACES BETWEEN THE ROCKS. DO NOT OVERLOAD ROCK GRATES Please Use The Following Amount of Lava Rock Per Model. GCRB 18” = Approximately 3 LBS. GCRB 24” = Approximately 4 LBS. GCRB 36” = Approximately 7 LBS. GCRB 48”...
- Page 11 PARTS LIST: GCB-18i & GCRB-18i Item P/N Description Item P/N Description 218207-55 Weldment, 18” Bullnose 35 218212-16 Radiant Med Duty - H 218215-11 Body, 18” Firebox GGM 36 43813149 Label, Warning Hot Surface (French) 8431300 1/4-20 Flanged Hex Locknut 37 8706300 Knob, Metal Cook line .375 D Shaft...
- Page 12 EXPLODED VIEW: GCB-18i & GCRB-18i...
- Page 13 PARTS LIST: GCB-24i & GCRB-24i Item P/N Description Item P/N Description 218208-55 Weldment, 24” Bullnose 21813129 Grate Support 218208-51 Body, 24” Firebox GCRB-GGM 8706300 Knob, Metal Cook Line .375 D Shaft 8417100 Nut, Hex, KEPS 10-32 2425500 Pan, Grease 24” Shallow Draw 8153100 #8-32 X 3/8 Type T 40* 8834910...
- Page 14 EXPLODED VIEW: GCB-24i & GCRB-24i...
- Page 15 PARTS LIST: GCB-36i & GCRB-36i Item P/N Description Item P/N Description 218209-55 Weldment, Bullnose 36” 218209-22 Support, 36” Rock Grate Front 218209-51 Body, 36” Firebox GGM 43813149 Label, Warning Hot Surface (French) 218209-52 Support, 36” Firebox Divider 218212-16 Radiant Med Duty - H 81546-00 #8 X 3/8 8633700...
- Page 16 EXPLODED VIEW: GCB-36i & GCRB-36i...
- Page 17 PARTS LIST: GCB-48i & GCRB-48i Item P/N Description Qty Item P/N Description 218210-55 Weldment, 48” Bullnose 218210-22 Support, 48” Rock Grate Front 8417100 Nut, Hex, KEPS 10-32 22030020 Support, Leg 48”, i-Line 8153100 #8-32 X 3/8 Type T 38* 2065847 Logo, APWWYOTT Casted.
- Page 18 EXPLODED VIEW: GCB-48i & GCRB-48i...
- Page 19 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes...
-
Page 20: Warranty
Authorized Service Agencies. The use of other than APW Wyott Authorized Service Agencies will void this warranty and APW Wyott will not be responsible for such work or any charges associated with same. The closest APW Wyott Authorized Service Agent must be used.
