- Page 1 LCD display solutions User Manual 23” FHD 1920 x 1080 LCD AP-F23 Aluminum front bezel NAP-F23 Front NEMA4 / IP65 DP-F23 Aluminum Front Panel OP-F23 Universal Open Frame Designed and manufactured by Austin Hughes UM-UV-621-F23-Q420V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2020 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > AP-F23 / NAP-F23 Package Content Structure Diagram & Dimension Mounting Hardware & Installation < Part. 2 > DP-F23 Package Content Structure Diagram & Dimension Mounting Hardware & Installation < Part. 3 > OP-F23 Package Content Structure Diagram &... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > AP-F23 / NAP-F23 < 1.1 > Package Content 23” FHD LCD Display AP-F23 / NAP-F23 23” FHD LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack...
- Page 6 < 1.2 > Structure Diagram Front view Side View AP-F23 / NAP-F23 Bottom view Rear case Rear view LCD panel Protective 3mm glass 6mm aluminum front bazel Audio speaker, pair LCD membrane Remote sensor Product Dimension Packing Dimension Gross Model...
-
Page 7: Part. 1 > Ap-F23 / Nap-F23
< 1.2 > Dimension 23” FHD LCD Display Front View Side View AP-F23 / NAP-F23 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-F23-Q420V1 www.austin-hughes.com... - Page 8 < 1.3 > Installation ( I ) Panel mount M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■...
-
Page 9: Package Content
< Part 2 > DP-F23 23” FHD LCD Display < 2.1 > Package Content DP-F23 23” FHD LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power DVI-D Upgrade I/O with advanced features Power Audio HDMI... -
Page 10: Structure Diagram & Dimension
< 2.2 > Structure Diagram Front view Side View DP-F23 Bottom view Rear case Rear view LCD panel 6mm aluminum front cover Audio speaker, pair LCD membrane Remote sensor Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 562.4 x 59.6 x 341.6 mm... -
Page 11: Part. 2 > Dp-F23
< 1.2 > Dimension 23” FHD LCD Display Front View Side View DP-F23 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-F23-Q420V1 www.austin-hughes.com... - Page 12 < 2.3 > VESA mount Installation M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-UV-621-F23-Q420V1 www.austin-hughes.com...
-
Page 13: Package Content
< Part 3 > OP-F23 < 3.1 > Package Content 23” FHD LCD Display OP-F23 23” FHD LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power DVI-D Upgrade I/O with advanced features Power Audio HDMI... -
Page 14: Structure Diagram & Dimension
< 3.2 > Structure Diagram Front view Side View OP-F23 Bottom view Rear case LCD panel Audio speaker, pair Rear view Universal open frame mounting LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Product Dimension Packing Dimension Gross... -
Page 15: Part. 3 > Op-F23
< 3.2 > Dimension 23” FHD LCD Display Front View Side View OP-F23 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-F23-Q420V1 P.11 www.austin-hughes.com... - Page 16 < 3.3 > Installation ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided UM-UV-621-F23-Q420V1 P.12 www.austin-hughes.com...
- Page 17 Intentionally Left Blank UM-UV-621-F23-Q420V1 P.13 www.austin-hughes.com...
-
Page 18: Product Specifi Cations
< Part 4 > < 4.1 > Product Specifi cations Mechanical Design AP-F23 NAP-F23 DP-F23 OP-F23 Protection 6mm front bezel NEMA 4 / IP65 front cover open frame Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 VESA mount... - Page 19 40,000 ft Shock 10G acceleration ( 11ms duration ) Vibration 10~300Hz 0.5G RMS random vibration Physical Specifi cation AP-F23 NAP-F23 DP-F23 OP-F23 Product ( W x D x H ) 584.2 x 63.6 x 363.6 562.4 x 59.6 x 341.6 581.4 x 65.3 x 360.6...
-
Page 20: On-Screen Display Operation ( Osd )
< 4.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 21 23” FHD LCD Display Color Color temperature : User / Warm / Cool / 5400k mode and Red / Green / Blue color balance Sharpness : Adjust the image from weak to sharp : Adjust the screen hue value Saturation : Adjust the saturation of the image color Dynamic luminous control : Control the dynamic brightness...
-
Page 22: Option Table
< Part 5 > Options < 5.1 > Option Table Options AP / NAP ✓ ✓ ✓ SDI *** ✓ ✓ ✓ Composite ( BNC ) ✓ ✓ ✓ Audio ✓ ✓ ✓ Touchscreen ✓ ✓ ✓ MCS multi-display control ✓... - Page 23 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 24 LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with UltraView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 25 < 5.4 > Upgrade Options : 23” FHD LCD Display - HMDI ( HDMI 1.4, CEA-861-E ) - Display Port ( DP 1.0, HCDP 1.3 ) - Audio ( Built-in Dual Stereo Speakers, 2W x 2 ) ( 3.5mm audio jacks for audio in & out ) Power Audio HDMI...
- Page 26 How to Use RC-2 Remote Controller INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 and 0 - 9 above, enter the second digit within two seconds.
- Page 27 < 5.5 > Options : Touchscreen & driver 23” FHD LCD Display F23" USB Touchscreen Specifi cation Model e-Resistive TPC-10 Multi-touch IR-06 Infrared Technology Projected Capacitive 5-Wire Resistive Infrared Touch Point Single Input Type Pen, Finger, Finger of Finger or Capacitive Stylus Finger or Stylus gloved hand activation Resolution...
- Page 28 Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc or download the driver from the link below : http://www.austin-hughes.com/resources/driver/ultraview Step 2. Double click the Setup.exe Step 3. Follow the installation instruction to fi nish the setup Step 4.
- Page 29 < 5.6 > Options : DC Power 23” FHD LCD Display Model 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 50 mA...
- Page 30 < 5.7 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
- Page 31 < 5.8 > Options : Quad Display 23” FHD LCD Display QD Specifi cation Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System NTSC Resolution 1024 x 525 1024 x 625 Refresh Rate Video Input 1.0 Vpp, 75 Ohm x 4 Camera Input...
- Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2020 Austin Hughes Electronics Ltd. All rights reserved. UM-UV-621-F23-Q420V1 P.28 www.austin-hughes.com...
