Summary of Contents for UltraView OP-W55
-
Page 1: User Manual
LCD display solutions User Manual 55” FHD 1920 x 1080 LCD AP-W55 Aluminum front bezel NAP-W55 Front NEMA4 / IP65 OP-W55 Universal Mounting Open Frame Designed and manufactured by Austin Hughes UM-UV-621-W55-Q215V2 www.austin-hughes.com... -
Page 3: Legal Information
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 4: Table Of Contents
AP-W55 / NAP-W55 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation < Part. 2 > OP-W55 Package Content Structure Diagram & Dimension P.6 - 7 Mounting Hardware & Installation < Part. 3 > Specifi cations / OSD / Remote Controller Product Specifi... -
Page 5: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. - Page 6 < Part 1 > < 1.1 > Package Content - AP / NAP-W55 AP-W55 / NAP-W55 55" FHD LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Wall-mount bracket set X 1 Basic I/O Power Audio...
-
Page 7: Structure Diagram & Dimension
< 1.2 > Structure Diagram - AP / NAP-W55 55" FHD LCD Display Front view AP-W55 NAP-W55 Bottom view Rear case Rear view LCD panel 8mm aluminum front bazel Audio speaker, pair LCD membrane Wall-mount bracket Remote sensor Product Dimension Packing Dimension Gross Model... -
Page 8: Ap-W55 / Nap-W55
< 1.2 > Dimension - AP / NAP-W55 Side View AP-W55 NAP-W55 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-W55-Q215V2 www.austin-hughes.com... - Page 9 < 1.3 > Wall-mount Installation - AP / NAP-W55 55” FHD LCD Display Front wall-mount bracket Step ■ Install left & right front wall-mount brackets at the rear side of the LCD shown above. ■ M5 screw x 8 pcs included ( Left & right side ). Rear side Step Rear wall-mount bracket...
-
Page 10: Package Content
< Part 2 > < 2.1 > Package Content - OP-W55 OP-W55 55" FHD LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Power Audio Audio DVI-D S-Video R C A... -
Page 11: Structure Diagram & Dimension
< 2.2 > Structure Diagram - OP-W55 55" FHD LCD Display Front view OP-W55 Bottom view Rear case LCD panel Rear view Universal open frame mounting Audio speaker, pair LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) -
Page 12: Part. 2 > Op-W55
< 2.3 > Dimension - OP-W55 Front View Side View OP-W55 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-W55-Q215V2 www.austin-hughes.com... - Page 13 < 2.3 > Installation - OP-W55 55" FHD LCD Display Universal mount No VESA mount provided for 46" and 55” models. Only universal mount available. UM-UV-621-W55-Q215V2 www.austin-hughes.com...
-
Page 14: Product Specifi Cations
< Part 3 > < 3.1 > Product Specifi cations Mechanical AP / NAP-W55 OP-W55 Design Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 Black, RAL 9005 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount... - Page 15 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random AP-W55 NAP-W55 OP-W55 Physical Specifi cation Product ( W x D x H ) 1325 x 75.3 x 796 To be confi rmed inch 52.2 x 3 x 31.3...
-
Page 16: On-Screen Display Operation ( Osd )
< 3.2 > On-screen Display Operation ( OSD ) 55” FHD LCD Display Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen... - Page 17 < 3.2 > On-screen Display Operation ( OSD ) Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance : Set the balance value of treble and bass sound...
-
Page 18: Picture In Picture ( Pip ) / Picture By Picture ( Pbp )
< 3.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 3.3.1 > Picture in Picture ( PIP ) Mode Display the Sub screen in the Main screen. OSD Menu → MISC → PIP Mode → Large / Small / OFF Main screen Sub screen Position... - Page 19 55” FHD LCD Display < 3.3.2 > Picture By Picture ( PBP ) Mode Display the Sub screen next to the Main screen. OSD Menu → MISC → PIP Mode → PBP Main screen Sub screen Size LCD Monitor Main / Sub screen 1920 x 1200 955 x 716 1920 x 1080...
-
Page 20: Remote Controller ( Rc-2 )
< 3.4 > Remote Controller ( RC-2 ) INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds. -
Page 21: Part 4 > Options
< Part 4 > Options < Part 4 > Options 55” FHD LCD Display < 4.1 > Option Table Options AP / NAP MCS multi-screen control MIL-type / lockable connector DC Power P.16 UM-UV-621-W55-Q215V2 www.austin-hughes.com... -
Page 22: Options : 3G / Hd / Sd-Sdi Input
Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Austin Hughes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty. -
Page 23: Multi-Display Control
LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with UltraView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty. - Page 24 < 4.4 > Options : DC Power Model Input rating Input voltage: 24-Volt 48-Volt Input range: 18 ~ 36V 36 ~ 75V Input current - No load 180 mA 90 mA - Full load 8396 mA 4198 mA Output rating Output voltage: 24-Volt 24-Volt...
- Page 25 < 4.5 > Options : MIL-type or Lockable Connector 55” FHD LCD Display Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
-
Page 26: Tv ( Analog )
< 4.6 > Options : TV ( Analog ) HDMI DVI-D Audio S-Video R C A Audio Power For RC-2 remote controller specifi cations, please refer to P.15 P.21 UM-UV-621-W55-Q215V2 www.austin-hughes.com... - Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2015 Austin Hughes Electronics Ltd. All rights reserved. UM-UV-621-W55-Q215V2 www.austin-hughes.com...
