- Page 1 Subwoofer Caisson de grave NS-SW100/NS-SW050 OWNER’S MANUAL MODE D’EMPLOI MANUAL DE INSTRUCCIONES...
- Page 2 We Want You Listening For A Lifetime YAMAHA and the Electronic Industries Association’s Since hearing damage from loud Consumer Electronics Group want you to get the most out sounds is often undetectable until it is of your equipment by playing it at a safe level.
- Page 3 Please read the following operating precautions before use. • Never place a fragile object near the YST port of this Yamaha will not be held responsible for any damage and/ unit. If the object falls or drops as a result of the air or injury caused by not following the cautions below.
- Page 4 • VOLTAGE SELECTOR (Asia and General models only) The voltage selector switch on the rear panel of this unit must be set to your local main voltage BEFORE plugging this unit into the AC main supply. Voltages are 110-120/220-240 V AC, 50/60 Hz. This unit is not disconnected from the AC power source as long as it is connected to the wall outlet, even if this unit itself is turned off.
-
Page 5: Table Of Contents
Outputs super-bass sound. the production of higher quality, super-bass sound. VOLUME control (Refer to page 5 for details on Advanced Yamaha Active Adjusts the volume level. Turn the control clockwise to Servo Technology II.) This super-bass sound adds a increase the volume, and counterclockwise to decrease more realistic, theater-in-the-home effect to your audio the volume. -
Page 6: Placement
PLACEMENT Since the low-end frequencies of audio signals feature long wavelengths, they are almost non-directional to human ears. The super-bass range does not create a stereo image. Therefore, a single subwoofer may be enough to produce a high- quality super-bass sound. Note The placement shown in the figure on the right is also... -
Page 7: Connections
CONNECTIONS Note Plug in the subwoofer to the AC outlet • Unplug the subwoofer and other audio/video After all connections are completed, plug the subwoofer components before making connections, and do not and other audio/video components into AC outlets. plug them in until all connections are completed. •... -
Page 8: Adjusting The Subwoofer Before Use
ADJUSTING THE SUBWOOFER BEFORE USE Before using the subwoofer, adjust the subwoofer to obtain the optimum volume balance between the subwoofer and the front speakers by following the procedure described below. Set the VOLUME control to minimum (0). Turn on the power of all the other components. Make sure that the POWER switch is set to the ON position. -
Page 9: Advanced Yamaha Active Servo Technology Ii
ADVANCED YAMAHA ACTIVE SERVO TECHNOLOGY II In 1988, Yamaha brought to the marketplace speaker systems utilizing YST (Yamaha Active Servo Technology) to give powerful, high quality bass reproduction. This technique uses a direct connection between the amplifier and speaker, allowing accurate signal transmission and precise speaker control. -
Page 10: Troubleshooting
If the instructions given below do not help, or if the problem you are experiencing is not listed below, turn off the power to the unit, disconnect the power cord and contact an authorized Yamaha dealer or service center. Problem... -
Page 11: Specifications
Weight .............8.5 kg (18.7 lbs.) * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. Frequency characteristic This subwoofer’s frequency characteristic...
