- Page 1 ASSEMBLY MANUAL YULIA IV-11/IV-12 VFD CLOCK If you will have any questions, contact with me here: info@kama-labs.com GOOD LUCK!
- Page 2 1) You have a PCB with ICs. MCU preprogrammed already: 2) Place all resistors vertical:...
- Page 3 3) Place res.arrays. Common pin to square 4) Place diodes according marking on PCB:...
- Page 4 5) Place all electrolytic capacitors. Be careful with polarity!
- Page 5 6) Place ceramic capacitor. Polarity is not matter.
- Page 6 7) Place all transistors and IC5 according marking on PCB:...
- Page 7 8) Place temperature sensor IC7 on bottom side of PCB:...
- Page 8 9) Place inductor:...
- Page 9 10) Place photoresistor.
- Page 10 11) Install buzzer:...
- Page 11 12) Place battery holder and insert battery when clock will be fully assembled: 13) Place sockets for IC. Insert MC34063 chip at the end of assembling process:...
- Page 12 14) Install Infrared receiver: 15) Install leds to the bottom side of PCB:...
- Page 13 16) Install socket for power supply:...
- Page 14 17) After all, your board should looks like on photo:...
- Page 16 18) Prepare and install all IV-11 tubes. You can see that pins of tubes cuts spiral already. The longest pin – the first pin:...
- Page 19 19) How to install IV-12 tubes:...
- Page 21 20) Place 2x IV-1 tubes. Pins of tubes cut spiral already too:...
- Page 23 21) After all clock should work. CONGRATULATIONS!
-
Page 24: Parts List
PARTS LIST Please note, that elements in kit can be a little different. If you doubt value of element, check it with multimeter. IF VALUE OF ELEMENT IN SPECIFICATION AND ON PCB IS DEFFERENT, PLEASE USE VALUES FROM SPECIFICATION OR SCHEME. - Page 25 C5, C12 10u/25v 470u/10v 220u/35v 240p D1, D3, RGB LED 3528 D4, D5, Common D6, D7 Anode P6KE6.8...
- Page 26 1N5819 D9, D10, LED Auto D11, D12 IC1, IC2 HV518 MC34063AP1 DS32KHZS...
- Page 27 LP2950ACZ3.3 STM32F100C6T DS18B20-PAR LM4871MX...
- Page 28 sensor/пульт 220uH SF2-1 R1, R6, resistor array R2, R5, 1.2k R12, R14, R17, R23 4.3k R4, R29 6.2k...
- Page 29 3.3k R11, R15, 9.1k R20, R22, R25, R26 0.33 6.8k R18, R19, R21, R24...
- Page 30 T1, T2, T3, IV-11/IV-12 T4, T5, T6 T7, T8 IV-8/IV-1 VT1, VT2, BC337 VT3, VT4, VT5, VT6 Power socket...
- Page 31 Micro USB Battery CR1220 holder Board Plastic case / wooden case 5V Power adapter...
- Page 32 Remote control...
