ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3543T/ PT
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of
(Included)
(Not Included)
Rev: 17-05-18
Advertisement
Related Manuals for Furniture of America CM3543T
Summary of Contents for Furniture of America CM3543T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3543T/ PT ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Table Top Bolt Ø5/16"x4-3/4" #2 x 2pcs #B x 4pcs Foot box Bolt Ø5/16"x2-1/8"...
- Page 4 2) Align and attach bottom plate (#3) to the bottom holes of the side panels (#2). Secure with bolts (#B) and fully tighten all bolts (#A,B). #A x 4pcs #B x 4pcs #D x 8pcs #E x 8pcs #D #E 1) Prepare 8 bolts assembly by inserting lock washer (#D), then flat washer (#E)
- Page 5 Prepare 8 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C). Align the foot box (#2) to the holes of the table top (#1). Secure with bolts (#C). #C x 8pcs #D x 8pcs #E x 8pcs This wood in the use of the process to be removed 4PCS Unlock the bottom switches of the table top.
- Page 6 Remove the leaf of the table to make the table top condensed. Lock the switch under the table. LOCK Page...
