Rohm BD9E304FP4-LBZ EVK User Manual

Switching Regulator Series
Buck Converter with Integrated FET
BD9E304FP4-LBZ EVK
BD9E304FP4-EVK-003 (12V→5V, 3.0A)
Introduction
This user's guide provides the necessary steps to operate the EVK of ROHM's BD9E304FP4-LBZ 1-channel Buck DC/DC
converter. This includes the external parts, operating procedures, and application data.
Description
This EVK has been developed for ROHM's synchronous buck DC/DC converter customers evaluating BD9E304FP4-LBZ
and outputs 5V from 24V or 12V input voltage. The BD9E304FP4-LBZ accepts a power supply input range of 4.5V to
36V and generates an output voltage ranging from (0.1 x V
frequency is fixed at 300 kHz. The Light Load Mode control provides good efficiency characteristics in light load conditions,
which is ideal for applications that needs to lessen the standby power. The current mode control DC/DC converter provides
high-speed transient response performance. Additional protection functions include a built-in soft start function to prevent
inrush current at startup, UVLO (Under Voltage Lock Out), TSD (Thermal Shutdown Detection), SCP (Short Current
Protection), OCP (Over Current Protection), and OVP (Over Voltage Protection).
Application
Industrial Products as Factory Automation
Secondary power supply and adapter equipment
Telecommunication Devices
Operating Limits
Parameter
Input Voltage
Output Voltage
Output Current Range
Operating Frequency
Maximum Efficiency
UVLO Detect Voltage
UVLO Hysteresis Width
