Rohm BD9E304FP4-EVK-001 User Manual

Buck converter with integrated fet
Hide thumbs

Advertisement

Table of Contents

Switching Regulator Series
Buck Converter with Integrated FET
BD9E304FP4 EVK
BD9E304FP4-EVK-001 (12V→1.2V, 3.0A)
Introduction
This user's guide provides the necessary steps to operate the EVK of ROHM's BD9E304FP4 1-channel Buck DC/DC
converter. This includes the external parts, operating procedures, and application data.
Description
This EVK has been developed for ROHM's synchronous buck DC/DC converter customers evaluating BD9E304FP4 and
outputs 1.2V from 12V input voltage. The BD9E304FP4 accepts a power supply input range of 4.5V to 36V and generates
an output voltage ranging from (0.1 x V
300 kHz. The Light Load Mode control provides good efficiency characteristics in light load conditions, which is ideal for
applications that needs to lessen the standby power. The current mode control DC/DC converter provides high-speed
transient response performance. Additional protection functions includes a built-in soft start function to prevent inrush
current at startup, UVLO (Under Voltage Lock Out), TSD (Thermal Shutdown Detection), SCP (Short Current Protection),
OCP (Over Current Protection), and OVP (Over Voltage Protection).
Application
Industrial Products as Factory Automation
Secondary power supply and adapter equipment
Telecommunication Devices
Operating Limits
Parameter
Input Voltage
Output Voltage
Output Current Range
Operating Frequency
Maximum Efficiency
UVLO Detect Voltage
UVLO Hysteresis Width
© 2021 ROHM Co., Ltd.
or 0.7V) to 0.8 x V
using external resistors. The operating frequency is fixed at
IN
IN
Min
Typ
Max
5.5
-
12.0
1.2
3.0
300
90.15
3.9
350
1/9
User's Guide
Units
Conditions
V
V
A
kHz
%
Vin=5.5VIout=0.7A
V
Vin sweep down
mV
No. 63UG030E Rev.001
2021.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD9E304FP4-EVK-001 and is the answer not in the manual?

Questions and answers

Related Manuals for Rohm BD9E304FP4-EVK-001

Summary of Contents for Rohm BD9E304FP4-EVK-001

  • Page 1 BD9E304FP4 EVK BD9E304FP4-EVK-001 (12V→1.2V, 3.0A) Introduction This user’s guide provides the necessary steps to operate the EVK of ROHM’s BD9E304FP4 1-channel Buck DC/DC converter. This includes the external parts, operating procedures, and application data. Description This EVK has been developed for ROHM’s synchronous buck DC/DC converter customers evaluating BD9E304FP4 and outputs 1.2V from 12V input voltage.

  • Page 2: Operating Procedure

    User’s Guide Figure 1. BD9E304FP4-EVK-001(Top View) EVK Schematic Figure 2. BD9E304FP4-EVK-001 Circuit Diagram Operating Procedure Turn off the DC power supply and connect the GND terminal of the power supply to the GND_F terminal (left side in EVK) of the EVK.

  • Page 3: Parts List

    BD9E304FP4-LB ROHM Short Shorted by solder Open Short Shorted by solder VIN_S,VIN_F, GND_Fx2, GND_Sx2, Test Pin 1mm hole ST-2-2 Mac8 VOUT_S, VOUT_F SW_EN Header 68000-103HLF Amphenol FCi SW_EN Jumper QPC02SXGN-RC SULLINS © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...

  • Page 4: Board Layout

    Material Board Size Copper Thickness FR-4 67.5mm x 67.5mm x 1.6mmt 1oz (35μm) The layout of BD9E304FP4-EVK-001 is shown below. Figure 3. Top Layer Layout Figure 4. Middle1 Layer Layout (Top View) (Top View) Figure 5. Middle2 Layer Layout Figure 6. Bottom Layer Layout...
  • Page 5 Figure 8. Switching Frequency vs Input Voltage （V =1.2V, I =3A) =1.2V, I =0A） VIN=5.5V VIN=10.0V VIN=12.0V 1000 10000 Output Current: I [mA] Figure 9. Efficiency vs Output Current (V =1.2V) © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...
  • Page 6 VIN (10V/div) VIN (10V/div) EN (10V/div) EN (10V/div) VOUT (1V/div) VOUT (1V/div) SW (10V/div) SW (10V/div) 2ms/div Figure 12. Rise-up Waveform Figure 13. Shut-down Waveform =0V→12V, I =3A) =12V→0V, I =3A) © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...
  • Page 7 =5 V/div 2µs/div =5 V/div Figure 14. SW Waveform Figure 15. SW Waveform （V =12V, V =1.2V, I =3A) =12V, V =1.2V, I =30ｍA） Figure 16. Frequency Response =12V, I =3A) © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...
  • Page 8 12V of DC bias voltage. (The data shown in Figure 18 is for reference only. Please check with the capacitor manufacturer for the DC bias characteristics of ceramic capacitors.) DC bias characteristics P/N:GRM23EC72A106KE05 C-DC bias capchange,25degC,AC1mVrms DC Bias:12.0V Cap.Change Rate:-19% Figure 17. GRM32EC72A106KE05 (Murata) DC bias characteristics © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...

  • Page 9: Revision History

    BD9E304FP4-EVK-001 User’s Guide Revision History Revision Date Description Number 28.Jul.2021 Initial release © 2021 ROHM Co., Ltd. No. 63UG030E Rev.001 2021.7...
  • Page 10 Products. ROHM does not grant you, explicitly or implicitly, any license to use or exercise intellectual property or other rights held by ROHM or any other parties. ROHM shall have no responsibility whatsoever for any dispute arising out of the use of such technical information.
