- Page 1 Operator's Manual CAGE™ PERMANENT HUB BLIND MODEL CBR30T Get parts online at P/N: 34982 © 2020 Ardisam C/N: 35790 www.HuntRiversEdge.com All Rights Reserved REV1: 08/24/2020...
-
Page 2: Table Of Contents
RETI before shipping your package to us by calling our customer service department at 800-345-6007 or by writing to: Ardisam, Inc., P.O. Box 755, 1160 Eighth Avenue, Cumberland, WI 54829 for a return material authorization number (RMA#). -
Page 3: Warnings
Operator's Manual CAGE™ R30 READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP WARNING INSPECTION AND MAINTENANCE This tent is made with fabric that meets CPAI-84 specifications for flame resistance. It is not fire proof. • Never put blind away wet. Always put away dry to avoid The fabric will burn if left in continuous contact with any mildew. -
Page 4: Service Parts List
Operator's Manual CAGE™ R30 SERVICE PARTS LIST (NOT TO SCALE) Item Part No. Image Description ROOF HUB # 38396 ASSEMBLY # 37034 ROOF LOCK WALL HUB # 37113 ASSEMBLY BOTTOM CORNER # 38395 HUB ASSEMBLY TOP CORNER # 38390 HUB ASSEMBLY Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 M-F 8-5... - Page 5 Operator's Manual CAGE™ R30 SERVICE PARTS LIST (NOT TO SCALE) Item Part No. Image Description FIBERGLASS POLE # 36283 ASSEMBLY HORIZONTAL # 35791 SPREADER POLE ASSEMBLY VERTICAL # 35795 SPREADER POLE ASSEMBLY ROOF POLE # 35806 ASSEMBLY CBR30BT TIE DOWN #25162 CORKSCREW STAKE...
-
Page 6: Set-Up And Use Instructions
Operator's Manual CAGE™ R30 SET-UP INSTRUCTIONS Remove the blind from carry bag. Lay the blind flat on the ground so any wall panel is facing WALL upward. Be completely sure there is no material twisted or overlapping the ends of any poles. SEE FIGURE 1. FIGURE 1 Grab the handle on the eyelet located in the center of wall and pull upward so it pops open. - Page 7 Operator's Manual CAGE™ R30 Unzip the door and enter the blind. Place palm of your hand on the roof hub and push the spring loaded roof straight up until it pops over center. SEE FIGURE 4. NOTE: For easier set up, it’s best to open up some window panels to allow light into blind for better visibility.
- Page 8 Operator's Manual CAGE™ R30 UNLOCKED CLAMP Unpack the horizontal and vertical spreader poles from the pole bag. Starting with the (4) horizontal spreader poles with the disc shaped ends, place one end into slot on any top corner hub. Make FIGURE 6A sure clamp is in the unlocked position.
- Page 9 Operator's Manual CAGE™ R30 INSERT 11. Install (4) vertical spreader poles with the round peg ends. With FIGURE 8A clamp on the vertical pole in the unlocked position, place peg into hole on bottom corner hub. SEE FIGURE 8A & 8B. NOTE: The larger diameter pole should go towards the bottom corner.
- Page 10 Operator's Manual CAGE™ R30 UNLOCKED CLAMP 15. Go back to the (4) horizontal spreader poles; while spreading FIGURE 9A them outward (tight), flip clamp lever into the locked position. SEE FIGURE 9A & FIGURE 9B. NOTE: Once all of the poles are clamped locked return to the roof lock and give it one final twist to ensure it is tight.
- Page 11 Operator's Manual CAGE™ R30 FIGURE 11 17. Anchor the side walls by attaching the short part of the strap to eye bolt. SEE FIGURE 11. 18. Attach the long strap to spiral anchor. SEE FIGURE 12. FIGURE 12 19. Measure the distance from side wall eye bolt to approximate FIGURE 13 location of spiral anchor, and twist anchor into ground.
-
Page 12: Take-Down Instructions
Operator's Manual CAGE™ R30 TAKE-DOWN INSTRUCTIONS TURN Remove all ground stakes and store them in the provided bag. COUNTER- CLOCKWISE Remove all native brush from brush holder straps. Unscrew the roof lock fully by rotating counter-clockwise until it FIGURE 14A - LOCKED POSITION hits nut on bottom of bolt. - Page 13 Operator's Manual CAGE™ R30 Zip door closed. From outside of blind push in each wall allowing them to fold onto themselves. SEE FIGURE 16. 10. Blind will be back in its flat stage just as it was when it was unfolded out of the backpack bag.
-
Page 14: Illustrated Parts Breakdown
Operator's Manual CAGE™ R30 ILLUSTRATED PARTS BREAKDOWN Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 M-F 8-5... - Page 15 Operator's Manual CAGE™ R30 PARTS LIST Item Part No. Description PARTS NOT SHOWN Item Part No. Description # 38396 ROOF HUB ASSEMBLY # 25162 TIE DOWN CORKSCREW STAKE # 37034 ROOF LOCK # 35279 GROUND STAKE 12 IN # 37113 WALL HUB ASSEMBLY # 35293 TIE DOWN STAKES KIT...
- Page 16 Rivers Edge® Treestands, Phone: 800-345-6007 A Division of Ardisam, Inc. Fax: 715-822-2124 1160 Eighth Avenue, PO Box 755 www.huntriversedge.com Cumberland, WI 54829 *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
