- Page 1 10843 Medium Cabinet INSTALLATION INSTRUCTIONS 01-18643-00 06/20 © 2020 ClosetMaid LLC | Ocala, FL 34471 | 1-800-874-0008 | www.closetmaid.com...
-
Page 2: Before Beginning
SAFETY PRECAUTIONS BEFORE BEGINNING • Please read all instructions carefully. • Familiarize yourself with all parts (see “PARTS”) and check quantities. • Follow all safety precautions (see “SAFETY PRECAUTIONS”). WARNING • • CHOKING HAZARD FOR SMALL CHILDREN. This unit DO NOT USE THIS UNIT AS A TELEVISION STAND. contains small parts which could be a choking hazard for Serious bodily injury and/or damage to personal small children. -
Page 3: Tools Required
PARTS Call 1-800-874-0008 for parts and service. For faster service, have the style number ready when calling. TOOLS REQUIRED #3 Phillips Screwdriver 10 mm. Wrench HARDWARE PROVIDED Name Qty. ST6.3 x 12 mm. Screw 28 + 2 Electrical Bushing M6-1.0 x 12 mm. Bolt... - Page 4 PARTS Call 1-800-874-0008 for parts and service. For faster service, have the style number ready when calling. PRODUCT Name Part # Name Part # Left Side Panel 35857 Caster without Brake 20624 Right Side Panel 35858 Caster with Brake 20624 Back Panel 35859 Bottom Shelf...
- Page 5 STEP 1 Attach side panels to back panel. Align both side panels (A & B) with the back panel (C) as shown. Slide the metal tabs on the back panel (C) into the matching slots on the side panels (A & B). Pull the side panels down to secure the tabs in place.
- Page 6 STEP 2 Attach top panel. Align top panel (D) with the top of the unit as shown. Push in to secure into place. Make sure that all the triangular tabs on the back and side panels completely snap into place in the square holes on the top panel. *Please note location of predrilled holes on each part.
- Page 7 STEP 3 Attach bottom panel. Align bottom panel (E) with the bottom of the unit as shown. Push in to secure into place. Make sure that all the triangular tabs on the back and side panels completely snap into place in the square holes on the bottom panel. *Please note location of predrilled holes on each part.
- Page 8 STEP 4 Attach door frame. Align the door frame (F) with the front of the unit as shown. Please note that the holes on the bottom of the door frame will match up with the upper holes on the bottom panel. Use a #3 Phillips screwdriver to secure the door frame to the unit using twelve ST6.3 x 12 mm.
- Page 9 STEP 5 Attach casters. Align two casters without brakes (G) with the lower holes on the bottom panel (E). Use a #3 Phillips screwdriver to secure the casters to the unit using eight ST6.3 x 12 mm. screws (AA). Align two casters with brakes (H) with the upper holes on the bottom panel (E). Use a #3 Phillips screwdriver to secure the casters to the unit using eight ST6.3 x 12 mm.
- Page 10 STEP 6 Attach shelves. Stand the unit up on the casters. Place the bottom shelf (I) inside the unit at the bottom. Push down to secure into place, making sure all metal tabs are connected. Please note that the bottom shelf is larger than the inner shelf and will rest on the lowest three metal tabs on the back panel.
- Page 11 STEP 7 (Optional) Attach unit to workbench top. Note: This step is only if you are planning to attach a workbench top (sold separately). If not, skip to next step. Place cabinets next to each other and align workbench top with the top of the units. For each cabinet, use a 10 mm. wrench to attach four M6-1.0 x 12 mm.
- Page 12 STEP 8 Attach electrical bushing. Align the electrical bushing (BB) with the large circle on the back of the unit. Push in to secure. *Please note location of predrilled holes on each part.
- Page 13 STEP 9 Attach doors. Align the right door (L) with the right side of the unit. Place the bottom lock of the door in the hole on the bottom of the door frame. Pull the top lock down, align it with the hole on the top of the door frame, and push up to lock into place.
