DURAVIS 3400
User Manual
MNL-0545-01 revB
REF ECO-1119
Effective: 27-APR-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DURAVIS 3400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Parvus DURAVIS 3400

  • Page 1 DURAVIS 3400 User Manual MNL-0545-01 revB REF ECO-1119 Effective: 27-APR-07...
  • Page 2: Disclaimer

    Parvus reserves the right to change the contents and form of this document, as well as the features and specifications of its products at any time without notice. The information in this publication does not represent a commitment on the part of Parvus.
  • Page 3: Important Information To The User

    Parvus is not responsible for any radio or device, which may be affected by harmful interference. Appropriate shielding of susceptible devices is not the responsibility of Parvus. Further, Parvus is not responsible for unauthorized modifications of Parvus equipment including the substitution or attachment of cables and/or other unauthorized equipment.
  • Page 4: Raee

    RAEE The information below is issued in compliance with the regulations as set out by the 2002/96/CE directive, subsequently superseded by 2003/108/CE, and refers electrical and electronic equipment and the management of their waste (WEEE). When disposing of a device, including all of its components, subassemblies and materials that are an integral part of the product, you should take the WEEE directive into consideration.
  • Page 5: Conventions

    DuraVIS-3400 Conventions The following table lists the conventions that are used throughout this manual. Icon Notice Type Description Information note Important features or instructions Information to alert you to potential Warning damage to a program, system or device or potential personal injury The “Mode”...
  • Page 6: Table Of Contents

    Table of Contents Disclaimer ................................2 Trademarks ................................2 IMPORTANT INFORMATION TO THE USER .....................3 Safety Notices and warnings..........................3 RAEE................................4 RoHS ................................4 Anti-static precautions............................4 Conventions ................................5 Table of Contents ..............................6 Chapter 1 Product Overview ..........................8 Product Definition..............................9 Chapter 2 Connector Descriptions ........................ 10 DB9 Male (Serial)...............................
  • Page 7 DuraVIS-3400 Descriptions of Color Functions ........................22 Descriptions of PIP-Control Functions ......................22 OSD Control Menu ............................23 Factory Reset .............................. 24 Chapter 7 Troubleshooting..........................25 Technical/Sales Assistance ..........................25 Returning For Service ............................25 LIMITED WARRANTY ............................26...
  • Page 8: Chapter 1 Product Overview

    Chapter 1 Product Overview The DuraVIS 3400 is a rugged 10.4" resistive touch screen flat panel display optimized for panel-mount installations in ships, aircraft, and ground vehicles. Its 400 Nit SVGA (800x600) resolution color Liquid Crystal Display is built into a robust mechanical design with internal shock and vibration isolation, hardened aluminum housing, and integrated gaskets for water and EMI resistance.
  • Page 9: Product Definition

    DuraVIS-3400 Product Definition Panel Type: 10.39" Diagonal TFT-LCD with CCFL Backlight Touch screen: Resistive Film Touch screen Overlay and RS-232 Controller Viewable Area: 211.2mm (W) x 158.4mm (H) Resolution: SVGA (800x600 pixels) Contrast Ratio: 500:1 (typical) Number of Colors: 260,000 Response Time: 30ms (typical) black to white;...
  • Page 10: Chapter 2 Connector Descriptions

    Connector Descriptions The DuraVIS 3400 is equipped with two DB9 connectors and one DB15 connector. The male DB9 port is used as an RS-232 interface for touch screen control. The VGA connector serves as the video input to the display and the female DB9 connector is used for power input.
  • Page 11: High Density Db15 (Vga)

    DuraVIS-3400 High Density DB15 (VGA) Pin Number Signal Name Input / Output Comment Input VGA Signal Green Input VGA Signal Blue Input VGA Signal Ground Input Ground Input Ground Input Ground Input VGA_Vcc Input VGA Signal Ground Input VGA_SDA Input VGA Signal HSYNC Input...
  • Page 12: Chapter 3 Interconnection/Cable Description

    Chapter 3 Interconnection/Cable Description The following cables are necessary to connect to the DuraVIS-3400: • Standard Male to Male VGA/SVGA cable. • Power cable with a DB9 Male Connector: The input voltage is applied to pin 1 or 6 (The two pins are connected in the unit), and the ground input is applied to pin 5 or 9 (The two pins are connected in the unit).
  • Page 13: Chapter 4 Touch Screen Driver

    Chapter 4 Touch Screen Driver Parvus provides a Windows XP driver and calibration program for the DuraVIS 3400. This chapter describes how to install this driver and run the calibration program. Touch screen drivers for DOS and Linux are available upon request.
  • Page 14: Installing The Driver

    Installing the Driver Follow these steps to install the touch screen driver: • Install SFT-0369X-01 by running setup.exe. • On the welcome screen, click next. • Read and accept the EULA, and click next. • On the next screen select “12 or10 Bit Controller” for controller type and “Serial (RS/232)” for the controller interface then try to auto-detect.
  • Page 15: Chapter 5 User Controls

    DuraVIS-3400 Chapter 5 User Controls Operating System Display buttons On the back side of the touch screen, under the OSD cover plate, there are several buttons to interface with the display. The functions of these buttons are as follows: Button Name Function Button 1...
  • Page 16: Chapter 6 On Screen Menu

    Chapter 6 On Screen Menu All the display functions, except for backlight intensity, can be controlled and adjusted using an On-Screen- Menu. This chapter explains all functions and their factory settings (valid for Firmware v2.13 and above). MNL-0545B-01...
  • Page 17 DuraVIS-3400...
  • Page 18: Window Structure

    Window Structure OSD Start Menu The main menu consists of the main input symbol, the PIP symbol, the OSD setting symbol, and factory auto- reset symbol. By selecting one of these symbols and pressing the Enter key, the sub-menus will be displayed. Main menu This menu is used to control the functions associated with the main input of choice.
  • Page 19: Descriptions Of Display Functions

    DuraVIS-3400 Descriptions of Display Functions Brightness: The brightness control on the OSD menu is not interfaced with the brightness up/down of the unit. This is an option that is not implemented in this design. The backlight intensity can be controlled through the OSD buttons on the back of the display or through the external switches (optional).
  • Page 20: Image Function Vga Mode

    Image Function VGA mode Scaling: User can choose between 1:1, Fill, Aspect and Panorama modes. Auto Adjust: Allows the performing of automatic setting adjustment. The display will change the settings for optimum image quality. Phase: This function is a slider to adjust the sampling phase of the analog interface. For optimum image quality, input pixels should be sampled at the ideal sampling points as shown below: Clock: This function is a slider to adjust the sample clock of the analog interface.
  • Page 21: Position Functions Vga Mode

    DuraVIS-3400 Position Functions VGA Mode Zoom: Selection of image zooming in and out. Zoom Horizontal Pan: Allows moving the zoomed image left and right. Zoom Vertical Pan: Allows moving the zoomed image up and down. Vertical: This slider moves the image up and down. Horizontal: This slider moves the image left and right.
  • Page 22: Descriptions Of Color Functions

    Descriptions of Color Functions sRGB: Enables/Disables the standard RGB color space. Gamma Correction: Turns gamma correction off, or sets its value to one of two predefined values. Color Temperature: User can set the color temperature to either self defined values, or to predefined values of 6500K or 9300K.
  • Page 23: Osd Control Menu

    DuraVIS-3400 OSD Control Menu Vertical: This slider moves the OSD left/right across the screen. Horizontal: This slider moves the OSD up/down across the screen. Blend: This slider sets the amount of blending of OSD into the background. Time out: This slider sets the time, in seconds, in which the inactive OSD will shut itself down. OSD Zoom: Enables and disables zooming into the OSD.
  • Page 24: Factory Reset

    Factory Reset By selecting ‘Yes’ and pressing enter, the user can reload the factory settings. All settings previously set by the user will be lost. MNL-0545B-01...
  • Page 25: Chapter 7 Troubleshooting

    If you have a sales-related question, please contact your local Sales Representative. Returning For Service Before returning any Parvus product, you must contact Parvus to obtain a Returned Material Authorization (RMA) number. Note. You must have the RMA number in order to return any product for any reason! Pack the module in an anti-static material and ship it in a sturdy cardboard box with enough packing material to adequately cushion it.
  • Page 26: Limited Warranty

    Parvus. This Warranty is valid for a period of one (1) year from the date of purchase. Parvus reserves the right to repair or replace any Warranted products at its sole discretion. Any product returned to Parvus for repair or replacement under the provisions of this warranty must be accompanied by a valid Return Material Authorization (RMA) number issued by the Parvus Customer Service Department.
