- Page 1 USER MANUAL PRV-0414 PCB Double Height Adaptor (Adaptor for Tall PCB Components) MNL-0337-01 Rev H3 REF. ECO-3163 01 Feb 10 RUGGED SOLUTIONS FOR REAL WORLD APPLICATIONS www.parvus.com...
- Page 2 Parvus reserves the right to change the contents and form of this document, as well as the features and specifications of its products at any time without notice.
-
Page 3: Table Of Contents
PRV-0414 User Manual Table of Contents Table of Contents ..............................3 Chapter 1 Introduction ............................4 Functional Description ............................4 Features ................................4 About PC/104 ..............................4 Chapter 2 Quick Start-up ..........................5 Installation ................................5 Installing the PC/104 Double Height Adapter....................5 Chapter 3 Connector Description ........................ -
Page 4: Chapter 1 Introduction
This section provides a functional description of the PRV-0414. Functional Description The PRV-0414 PC/104 Double Height Adapter is a low-cost interconnection board that gives embedded PC/104 computer systems a method for connecting circuit board modules taller than the prescribed PC/104 specification height. -
Page 5: Chapter 2 Quick Start-Up
PRV-0414 User Manual Chapter 2 Quick Start-up This section describes the installation of the PRV-0414. It then describes power-up of the assembly. Installation Installing the PC/104 Double Height Adapter Remove the PC/104 Double Height Adapter from the anti-static bag. There are two pieces; One piece (PART 1), contains the stack-through connector(s) for the PC/104 bus. - Page 6 PRV-0414 User Manual Page 6 of 14 MNL-0337-01 RevH3 REF. ECO-3163 Effective: 01 Feb 10...
-
Page 7: Chapter 3 Connector Description
PRV-0414 User Manual Chapter 3 Connector Description This chapter includes the pinouts, signal descriptions for the PRV-0414. Connector Identification RoHS PCB (PCB-0526-05) with 10-pin Power Connector: Connector Function J1,J2 PC/104 Bus 10-pin Power Header Used to supply power to or take power from PC/104 Bus MNL-0337-01 RevH3 REF. -
Page 8: Connector Pinouts
PRV-0414 User Manual Connector Pinouts J1/J2: PC/104 Bus Row A Row B Row C Row D /IOck /SBHE /MCS16 Rstdrv LA23 /IOCS16 LA22 IRQ10 IRQ9 LA21 IRQ11 LA20 IRQ12 DRQ2 LA19 IRQ15 -12v LA18 IRQ14 /Exfer LA17 /DA0 +12v DRQ0... -
Page 9: 10-Pin Power Connector
PRV-0414 User Manual 10-Pin Power Connector – Used in supplying power or taking power from the PC/104 bus Pins 1 & 2 are designated on applicable drawing above for current PCB version (PCB-0526-04). Function Function Ground Ground +12V Ground Ground MNL-0337-01 RevH3 REF. -
Page 10: Specifications
Operating Temperature -40C to +85C Storage Temperature -40C to +85C Mechanical This section provides details related to the mechanical construction of the PRV-0414. Dimensions Dimensions 3.510" x 0.550" (part 1), 3.510" x 0.40" (part 2). Page 10 of 14 MNL-0337-01 RevH3 REF. -
Page 11: Chapter 4 Troubleshooting
Phone: +1 (801) 433-4322 Fax: +1 (801) 483-1523 Returning For Service Before returning any Parvus product, please fill out a Returned Material Authorization (RMA) request form available for download from the following website under the support section: www.parvus.com Email this form to the email address listed above to receive authorization for shipment. -
Page 12: Chapter 5 Contact Info
PRV-0414 User Manual Chapter 5 Contact Info Main Phone: +1 (801) 483-1533 Fax: +1 (801) 483-1523 Sales +1(800) 483-3152 or (801) 483-1533, sales@parvus.com Product Technical Support +1 (801) 433-6322, tsupport@parvus.com Customer Feedback feedback@parvus.com Company contact info: ® Parvus Corporation 3222 S. Washington St. -
Page 13: Eurotech Group Worldwide Presence
China PARVUS EUROTECH VANTRON Tel. +1 800.483.3152 Tel. +44 (0) 1223.403410 Tel. +86 28.85.12.39.30 +1 801.483.1523 +44 (0) 1223.410457 +86 28.85.12.39.35 E-mail: sales@parvus.com E-mail: sales.uk@eurotech.com E-mail: sales@vantrontech.com.cn E-mail: tsupport@parvus.com E-mail: support.uk@eurotech.com E-mail: support.cn@eurotech.com Web: www.parvus.com Web: www.eurotech.com Web: www.vantrontech.com.cn France EUROTECH Tel. - Page 14 www.parvus.com...
