- Page 1 USER MANUAL PRV-1220 Remote CompactFlash Adaptor MNL-0516-01 Rev B1 REF. ECO-3182 22 Feb 10 RUGGED SOLUTIONS FOR REAL WORLD APPLICATIONS www.parvus.com...
- Page 2 Parvus reserves the right to change the contents and form of this document, as well as the features and specifications of its products at any time without notice.
-
Page 3: Table Of Contents
PRV-1220 User Manual Table of Contents Table of Contents ..............................3 Chapter 1 Introduction ............................4 Functional Description ............................4 Features ................................4 Chapter 2 Quick Start-up ..........................5 Installation ................................5 Board Mounting ............................. 5 Setup ................................5 Attaching Media............................. 5 Chapter 3 Connector Description ........................ -
Page 4: Chapter 1 Introduction
This section provides a functional description of the PRV-1220. Functional Description PRV-1220 is a low-cost, CompactFlash® to IDE adapter flexibly designed with both 40-pin (0.10") and 44-pin (2mm) IDE connectors. Fully compatible with Type I and Type II cards, the adapter enables both solid-state CompactFlash and IBM®... -
Page 5: Chapter 2 Quick Start-Up
PRV-1220 User Manual Chapter 2 Quick Start-up This section describes the installation of the PRV-1220. Installation Board Mounting There are four holes, one on each corner of the board, to aid in mounting the board. The board can also be mounted with the two provided L-brackets. -
Page 6: Chapter 3 Connector Description
PRV-1220 User Manual Chapter 3 Connector Description This chapter includes the pinouts, signal descriptions and connector part numbers for the PRV-1220. Connector Identification Component and Connector Placement Connector / Jumper / LED Function 44 Pin IDE Connector CompactFlash Connector +5V Power Connector for CompactFlash... -
Page 7: Connector Pinouts
Connector Pinouts This section provides the pinouts necessary for creating cables that would properly connect to this assembly. If custom cabling is not designed and built by Parvus all EMI and EMC consideration must be handled by the customer. J1: 44 Pin 2mm IDE Connector J4: 40 Pin 0.1”... - Page 8 PRV-1220 User Manual Ground Ground Data 11 Data 12 Data 13 Data 14 Data 15 CS1* Ground IOR* IOW* +IRQ Master/Slave Select Reset* IORDY_IDE J3: Power Connector for CompactFlash Card Function Ground Note: This connector is only to be used when using the 40 pin IDE connector to provide power to the CompactFlash card.
-
Page 9: Chapter 4 Operational Description
PRV-1220 User Manual Chapter 4 Operational Description Configuration JP1: CompactFlash Master/Slave Select Jumper Jumper Function 1 - 2 Master None Slave Connector J5 can be used to bring out the power and hard drive activity signals to an external source. The figure below shows how a connection should be made. -
Page 10: Chapter 5 Specifications
Electrical • Requirements +5Vdc • Do not insert/remove CompactFlash card with power applied Environmental Specifications This section describes the environmental standards that the PRV-1220 has either been designed to meet or tested to. • Operating Temperature -40°C to +85°C •... - Page 11 PRV-1220 User Manual MNL-0516-01 RevB1 REF. ECO-3182 Effective: 26 Feb 10 Page 11 of 16...
- Page 12 PRV-1220 User Manual Page 12 of 16 MNL-0516-01 RevB1 REF. ECO-3182 Effective: 26 Feb 10...
-
Page 13: Chapter 6 Troubleshooting
• Phone: +1 (801) 433-4322 • Fax: +1 (801) 483-1523 Returning For Service Before returning any Parvus product, please fill out a Returned Material Authorization (RMA) request form available for download from the following website under the support section: www.parvus.com Email this form to the email address listed above to receive authorization for shipment. -
Page 14: Chapter 7 Contact Info
PRV-1220 User Manual Chapter 7 Contact Info Main Phone: +1 (801) 483-1533 Fax: +1 (801) 483-1523 Sales +1(800) 483-3152 or (801) 483-1533, sales@parvus.com Product Technical Support +1 (801) 433-6322, tsupport@parvus.com Customer Feedback feedback@parvus.com Company contact info: ® Parvus Corporation 3222 S. Washington St. -
Page 15: Eurotech Group Worldwide Presence
China PARVUS EUROTECH VANTRON Tel. +1 800.483.3152 Tel. +44 (0) 1223.403410 Tel. +86 28.85.12.39.30 +1 801.483.1523 +44 (0) 1223.410457 +86 28.85.12.39.35 E-mail: sales@parvus.com E-mail: sales.uk@eurotech.com E-mail: sales@vantrontech.com.cn E-mail: tsupport@parvus.com E-mail: support.uk@eurotech.com E-mail: support.cn@eurotech.com Web: www.parvus.com Web: www.eurotech.com Web: www.vantrontech.com.cn France EUROTECH Tel. - Page 16 www.parvus.com...
