Next BARLOW 802062 Assembly Instructions Manual

Coffee trunk

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be
faulty.
Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons are required to assemble this product.
PRODUCT INFORMATION
• Made from particleboard,MDF with a wood effect finish.
• Made in Indonesia.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching or
damage.
• Ensure the mats and coasters used do not have an abrasive surface underneath.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
802062
ASSEMBLY INSTRUCTIONS.
BARLOW COFFEE TRUNK
1 of 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the BARLOW 802062 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next BARLOW 802062

  • Page 1 802062 BARLOW COFFEE TRUNK ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS 15x12 mm. 7.5X32 mm. 8x32 mm. F6x13 mm. 7.5X15 mm. P4x15 mm. 25x30 mm Ax30 Bx30 Cx33 F10x70 mm. F6x30 mm. 350 mm. 350 mm LLx2 LRx2 PARTS 3Lx1 3Rx1 10Lx2 10Rx2 11x2 12x2 13x2 2 of 9...
  • Page 3 STEP ONE - Attach 8 x cambolts (B) into the holes on panel 1. - Turn clockwise with cross-blade screwdriver to tighten. Recommend to use cross-blade screwdriver. STEP TWO - Insert 1x wooden dowel (C) into the hole on panel 8. - Attach panel 8 to panel 2 using 1 x screw (I) and tighten by turning clockwise with cross-blade screwdriver.
  • Page 4 STEP FOUR - Insert 2x camlocks (A) into the holes on panel 3R and ensure that arrow indicator is pointing towards the panel edge - Attach 4x cambolts (B) and 2x wooden dowels (C) into the holes on panel 3R. STEP FIVE - Insert 2x camlocks (A) into the holes on panel 4 and ensure that arrow indicator is pointing towards the panel edge.
  • Page 5 STEP SEVEN - Attach panel 5 to panel 7 and tightening 2x camlocks (A) clockwise with a flat-blade screwdriver until tight. STEP EIGHT - Attach panel 5,7 and 6 to panel 3R and tighten using the 4x camlocks (A). Turn camlocks clockwise with a flat-blade screwdriver until tight. STEP NINE - Attach panel 3L to the assembled using 4 x camlocks (A).
  • Page 6 STEP TEN - Attach panel 4 to the assembled unit using 2 screws (H) and tighten by turning clockwise with a cross-blade screwdriver. STEP ELEVEN - Slide panel 2 into the unit. - Insert 4x mini cambolts (E) into the holes of assembled unit tightening with a cross-blade screwdriver until tight.
  • Page 7 STEP THIRTEEN - Insert 3x cambolts (B) into the holes on panel 9. - Attach 1x handle (G) to panel 9 using 1 x screw (F) Tighten screw (F) using a flat-blade screwdriver . - Attach 1x camlock (A) into the hole on panel 10L and 10R and ensure that arrow indicator is pointing towards the panel edge.
  • Page 8 STEP SIXTEEN - Attach panel 11 to the assembled unit and tighten camlocks (A) by turning clockwise with a flat-blade screwdriver. - Repeat step 16 for the second set of components. STEP SEVENTEEN - Insert panel 13 to the recessed grooves of panel 10L,10R and 12.
  • Page 9 2x screws (D) - Repeat this step for the second drawer STEP TWENTY - Insert the drawers into the assembled unit. - The coffee trunk is ready for use. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 9 of 9...
