IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
• Made from particleboard,MDF with a wood effect finish.
• Made in Indonesia.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching or
damage.
• Ensure the mats and coasters used do not have an abrasive surface underneath.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly
and periodically check all fixings and tighten if necessary.
804833
ASSEMBLY INSTRUCTIONS.
1 of 12
BARLOW BOOKCASE

Advertisement

loading
Need help?

Need help?

Do you have a question about the BARLOW BOOKCASE 804833 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next BARLOW BOOKCASE 804833

  • Page 1 804833 BARLOW BOOKCASE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS 15x12 mm. 7.5X32 mm. P6x30 mm. 8x32 mm. F6x13 mm. Ax16 Bx16 Dx23 Ex24 Fx12 P4x12 mm. 6x40 mm. F4x19 mm. T-35 Curve P4x15 mm. 25x30 mm. Hx20 Ix20 P6X19 mm. F6x31 mm. 150 mm. 20x9 mm. 1793 mm. 4 mm PARTS 3Lx1...
  • Page 3 STEP ONE - Attach 4x cambolts (B) into the holes of panel 1.Tighten with a cross blade screwdriver. Recommend to use cross-blade screwdriver. STEP TWO - Insert 4x camlocks (A) into the holes of panel 2 and ensure that arrow indicator is pointing towards the panel edge before tightening with a screwdriver.
  • Page 4 STEP FOUR - Insert 2x camlocks (A) into the holes of panel 3L and ensure that arrow indicator is pointing towards the panel edge before tightening with a screwdriver. - Attach 6x cambolts (B), 2x wooden dowels (D) into the holes of panel 3L.
  • Page 5 STEP SEVEN - Insert 2x camlocks (A) into the holes of panel 6 and ensure that arrow indicator is pointing towards the panel edge before tightening with a screwdriver. - Insert 4x camlocks (A) into the holes of panel 9 and ensure that arrow indicator is pointing towards the panel edge before tightening with a screwdriver.
  • Page 6 STEP TEN - Insert panel 10 (x3) to the recessed grooves of panel 2 and 3R and ensure that the arrow mark is positioned as shown in the diagram and insert 2x backboard "H" bar (Q) between panel 10. STEP ELEVEN - Attach panel 3L to the assembled unit by tightening 7 x camlocks (A) clockwise with flat-blade screwdriver.
  • Page 7 STEP TWELVE - Carefully lift the unit upright. (This should be lifted using 2 people.) - Attach panel 1 to the assembled unit by tightening 4 x camlocks (A) clockwise with flat-blade screwdriver. Recommend to use cross-blade screwdriver. STEP THIRTEEN - Attach 6x screws (G) into the holes of panel 10(x3) and tightening with a cross-blade screwdriver.
  • Page 8 STEP FOURTEEN - Attach panel 4 to assembled unit by tightening 3x screws (N) clockwise with a cross-blade screwdriver. Recommend to use cross-blade screwdriver. STEP FIVETEEN - Insert 12x shelf support (F) into the holes of panel 3R and 8 of 12...
  • Page 9 STEP SIXTEEN - Put panel 7 (x2) and panel 8 to assembled unit. STEP SEVENTEEN - Attach 2x hinges (J) to the holes of panel 12L and secure by tightening 4x screws (E) clockwise with a screwdriver. - Attach 1x handle (L) to the holes of panel 12L and secure by tightening 1x screw (K) clockwise with a screwdriver.
  • Page 10 STEP EIGHTEEN - Attach panel 12R and 12L to assembled unit and tightening 8 x screws (E) clockwise with a cross-blade screwdriver until tight. (For adjust the hinge, look the diagrams) STEP NINETEEN - Attach 2x wall brackets (O) to the panel 1 and using 2x washer (R) and secure by tightening 2 x screws (M) clockwise with a cross blade screwdriver until tight.
  • Page 11 NB : Wall fixing are not included. Please source suitable fixing for your wall type. If in doubt please consult a qualified trades person. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 11 of 12...
  • Page 12 Note : Whilst position foil stickers to cover the holes. Ensure that you arrange them on the centre of the holes before sticking. And ensure the grain direction of foil sticker have to be in the same direction as current surface area. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 12 of 12...
