- Page 1 Test Report No.: GETEC-E3-05-049 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 37” LCD TV/Monitor FCC ID: BEJ37LAD...
- Page 2 Installation and Operating Guide | Warranty Model Numbers | Z37LZ5D | LCD TV © Copyright 2005, LG Electronics USA, Inc.
-
Page 3: Fcc Notice
CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mod- ification could void the user’s authority to operate this product. COMPLIANCE:... -
Page 4: Important Safety Instructions
Safety Instructions Safety Instructions Safety Instructions IMPORTANT SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the appara- tus. - Page 5 Safety Instructions Safety Instructions Safety Instructions 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has exposed to rain or moisture, does not operate normally, or has been dropped.
-
Page 6: Front Panel Controls
Introduction Controls Controls - This is a simplified representation of front panel. Here shown may be somewhat different from your TV. Front Panel Controls Front Panel Controls Channel Buttons Volume Buttons Enter Button ENTER Menu Button MENU TV·Video Button VIDEO ON/OFF Button Owner’s Manual... -
Page 7: Connection Options
Introduction Connection Options Connection Options Back Connection Panel Back Connection Panel S-VIDEO Input A connection available to provide bet- ter picture quality than the video input. VIDEO Input Connects the video signal from a video device. AUDIO Input Use to connect to hear stereo sound from an external device. -
Page 8: Remote Control Key Functions
Introduction Remote Control Key Functions Remote Control Key Functions - When using the remote control, aim it at the remote control sensor on the TV. TV INPUT • Rotates the input mode between Antenna TV INPUT TV/VIDEO TV/VIDEO and Cable. External input modes rotate in regular sequence: Antenna, Cable, Video, Front MODE... - Page 9 Introduction Remote Control Key Functions Remote Control Key Functions VCR/DVD BUTTONS • Control some video cassette recorders TV/VIDEO TV INPUT or DVD players. ("RECORD" button is not POWER available for DVD players.) Turns your TV or any other programmed equipment on or off, depending on mode. MODE GUIDE Shows program schedule.
-
Page 10: Installation Instructions
Installation Installation Installation Accessories Accessories Ensure that the following accessories are included with your plasma display. If an accessory is missing, please contact the dealer where you purchased the product. 1.5V Owner’s Manual Batteries Power Cord 75Ω Round Cable TV INPUT TV/VIDEO MODE GUIDE... -
Page 11: Wall Mount: Horizontal Installation
Installation Installation Instructions Installation Instructions • The TV can be installed in various ways such as on a wall, or on a desktop etc. • The TV is designed to be mounted horizontally. GROUNDING Power Supply Ensure that you connect the earth ground wire to prevent possible electric shock. -
Page 12: External Equipment Connections
Installation External Equipment Connections External Equipment Connections Antenna or Cable Connection Antenna or Cable Connection 1. Analog and Digital TV signals provided on antenna - Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections - For optimum picture quality, adjust antenna direction if needed. Multi-family Dwellings/Apartments (Connect to wall antenna socket) Wall Antenna... -
Page 13: Vcr Setup
Installation 3. Analog and Digital TV signals provided on cable and antenna Antenna Bronze Wire RF Coaxial Wire (75 ohm) Turn clockwise to tighten. Cable TV Wall ANTENNA Jack RF Coaxial Wire (75 ohm) CABLE Bronze Wire • To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly. -
Page 14: How To Use
Installation External A/V Source Setup External A/V Source Setup How to connect Connect the audio and video cables from the external equip- MONITOR OUTPUT COMPONENT INPUT 2 ment's output jacks to the TV input jacks, as shown in the /DTV figure. - Page 15 Installation HDSTB Setup HDSTB Setup - This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below. - This TV supports HDCP (High-bandwidth Digital Contents Protection) protocol for Digital Contents (480p,720p,1080i).
- Page 16 Installation PC Setup PC Setup - This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. - The TV perceives 640x480, 60Hz as DTV 480p based on the PC graphic card, change the screen scanning rate for the graphic card accordingly.
-
Page 17: Monitor Out Setup
Installation Monitor Display Specifications (HDMI/DVI Mode) Horizontal Vertical Horizontal Vertical Resolution Resolution Frequency(KHz) Frequency(Hz) Frequency(KHz) Frequency(Hz) 48.363 31.469 60.00 59.94 640x480 56.476 37.861 70.06 72.80 1024x768 60.023 75.02 37.500 75.00 35.156 56.25 37.879 60.31 800x600 48.077 72.18 46.875 75.00 Monitor Out Setup Monitor Out Setup The TV has a special signal output capability which allows you to hook up a second TV or monitor. - Page 18 Installation HDMI HDMI - HDMI , the HDMI logo and High-Definition Multimedia Interface is a trademark or registered trademark of HDMI Licensing." - This TV can receive the High-Definition Multimedia Interface(HDMI) or the Digital Visual Interface(DVI). - This TV supports HDCP(High-bandwidth Digital Contents Protection) Protocol for 720x480p, 1280x720p, and 1920x1080i resolu- tion.
-
Page 19: Hdmi Cable
Installation Reference Reference Cable sample HDMI Cable (not supplied with the product) HDMI to DVI Cable (not supplied with the product) Fiber Optic Digital Audio Cable (not supplied with the product) Analog Audio Cable(RCA type) (not supplied with the product) Analog Audio Cable(Stereo to RCA type) (not supplied with the product) Operating Guide... - Page 20 Installation How to use 1. Connect the HDMI/DVI Source Devices(DVD Player or Set Top Box or PC) and the TV SET. 2. Turn on the display by pressing the POWER button on the TV SET and HDMI/DVI Source Devices remote control. 3.
-
Page 21: Screen Setup For Pc Mode
Operation Screen Setup for PC mode Operation Operation • When RGB connect to PC input and select the RGB-PC, this function is used. • When HDMI/DVI connect to PC input and select HDMI/DVI input, this function is used. • In RGB-DTV mode, SIZE and PHASE is not available. Adjustment for screen Position, Size, Phase, Reset Adjustment for screen Position, Size, Phase, Reset •After connecting RGB-PC or HDMI/DVI to PC input and checking the screen quality. -
Page 22: External Control Device Setup
External Control Device Setup External Control Device Setup External Control Device Setup - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and control the Monitor’s functions externally. - Connect the serial port of the control device to the RS-232C jack on the Monitor back panel. - RS-232C connection cables are not supplied with the Monitor. -
Page 23: Communication Parameters
External Control Device Setup Set ID Set ID Use this function to specify a monitor ID number. Refer to ‘Real Data Mapping’. See page 44. EZ Scan SETUP 1. Press the MENU button and then use button to select the SETUP menu. - Page 24 External Control Device Setup 01. Power (Command2:a) 05. Volume Mute (Command2:e) G To control Power On/Off of the Monitor. G To control volume mute on/off. You can also adjust mute using the MUTE button on Transmission remote control. [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 0 : Power Off 1 : Power On...
- Page 25 External Control Device Setup 09. Color (Command2:i) 13. Remote Control Lock Mode (Command2:m) G To adjust the screen color. G To lock the remote control and the front panel controls on You can also adjust color in the Video menu. the set.
- Page 26 External Control Device Setup 17. Color Temperature (Command2:u) * All data are transmitted by Hexadecimal code *Two/One part Channel: 6th bit G To adjust color temperature. This bit is used in a cable-ready system. You can also adjust color temperature in the Video *Using physical channel: 5th bit menu.
- Page 27 External Control Device Setup 21. Input select(Command: x b) (Main Picture Input) G To select input source for TV. Transmission [x][b][][Set ID][][Data][Cr] Data Structure INPUT DATA(Hex) DTV (Antenna) DTV (Cable) Analog (Antenna) Analog (Cable) Video Front Video Component 1 Component 2 RGB DTV RGB PC HDMI/DVI...
-
Page 28: Product Specifications
Specification Product Specifications Product Specifications MODELS Z37LZ5D 1060.8 Width (mm) 675.2 Height (mm) 136.2 Depth (mm) 28.6 Weight (kg) 852 x 480 (Dot) Resolution Power requirement AC100-240V ~ 50/60Hz 2.0A 190W Power Consumption NTSC-M, ATSC, 64 & 256 QAM Television System VHF 2 ~ 13, UHF 14 ~ 69, CATV 1 ~ 135, CADTV 1 ~ 135, DTV 2 ~ 69 Program Coverage 75 Ω...
