- Page 1 All manuals and user guides at all-guides.com DA560D COMPACT SERIES INSTALLATION / OWNER'S MANUAL Mobile Power Amplifiers...
- Page 2 All manuals and user guides at all-guides.com INSTALLATION Preparation Please read entire manual before installation. Due to the technical nature of amplifiers, it is highly recommended that your Dual amplifier is installed by a professional installer or an authorized dealer. Before You Start instructions) the installation.
-
Page 3: Connection Descriptions
All manuals and user guides at all-guides.com INSTALLATION Connection Descriptions NOTE: Be sure to follow specific instructions included with your amplifier installation kit (not included with this amplifier). The information below should be used as a general guideline only. Power Wire (+12V) technician for instructions if you are unsure. - Page 4 All manuals and user guides at all-guides.com INSTALLATION Audio Inputs and Controls DA560D High Pass Filter Low Pass Filter Crossover Mode Bass Boost Gain...
- Page 5 All manuals and user guides at all-guides.com INSTALLATION Power and Speaker Connections DA560D Ground Connection Speaker Connections Fuse +12VDC Battery Connection...
-
Page 6: Typical Wire Routing
All manuals and user guides at all-guides.com INSTALLATION Typical Wire Routing No more than 36" (1 meter) POWER SPEAKER WIRE Main Power Connections Connect +12V, GND and REM wires accordingly. A suitable fuse MUST be installed on the +12V lead within 18" of the battery for protection of the vehicle’s electrical system. -
Page 7: Amplifier Connections
All manuals and user guides at all-guides.com INSTALLATION Amplifier Connections Speaker Connections recommended and may cause amplifier damage. Input Signal Connections Low Level Input (RCA) High Level Input (Speaker Wire) High-Level Input (speaker cables) connection to chassis ground Low-Level Input (RCA) installation. - Page 8 All manuals and user guides at all-guides.com INSTALLATION Configuration/Setup Input level Control until audible distortion is heard, then slightly Crossover Mode FLAT Note: Choose FLAT professional for recommendations. Crossover Frequency Control Bass Boost Subsonic Filter designed to handle. LED Indicators POWER PROTECT).
-
Page 9: Troubleshooting
All manuals and user guides at all-guides.com INSTALLATION Troubleshooting Problem Cause Unit will not turn on (no power LED indicator) Unit has power - each other or touching chassis each other and chassis ground LED is green (but ground no sound) proper connection Unit blows fuse(s) clean bare metal... -
Page 10: Specifications
All manuals and user guides at all-guides.com INSTALLATION Specifications DA560D Channels 1,2,3 and 4 Power Output (14.4VDC, 20Hz ~ 20kHz): •60 Watts RMS x 4 channels @ 4 Ohms •85 Watts RMS x 4 channels @ 2 Ohms •200 Watts RMS x 2 channels @ 4 0hms (bridged) Peak Music Power Output: 400 Watts Subwoofer... -
Page 11: One-Year Limited Warranty
Who is covered? to the original retail purchaser for products purchased from an authorized Dual dealer What is covered? damage resulting from accident, misuse, abuse, neglect, product modification,... - Page 12 All manuals and user guides at all-guides.com...
