- Page 1 USER MANUAL Double Deck Electric Pizza Oven: EPO-2D-Premia...
- Page 2 Wiring diagrams Ⅰ Control board operating instruction 1. Operating instruction of the EPO-2D-Premia control board. 1.1 The right switch is for controlling the internal lighting. 1.2 The left switch is for controlling all the heating elements, turn it on, then the thermostats can be used.
- Page 3 User Manual Ⅱ Functions 1. Functions 1.1 Heating up quickly. This oven is equipped with 350℃ thermostat, greatly save the cooking time. 1.2 Equipped with baking stone, which makes the food are heated more evenly. 1.3 Two thermostats separately control the top and bottom heating elements, you can freely adjust the temperature of each heating element.
-
Page 4: Front Panel
User Manual Front Panel: Chamber: Ⅳ. Parts list Part No. Description EP2T-001 Door EP2T-002 Double row switch EP2T-003 Indicator light EP2T-004 Thermostat EP2T-005 Front frame EP2T-005-001 Bottom rail EP2T-005-002 Left clevis EP2T-005-003 Top clevis EP2T-005-004 Right clevis EP2T-005-005 Left vertical board EP2T-005-006 Top rail EP2T-005-007... - Page 5 User Manual EP2T-006-006 Right layer board 2 EP2T-006-007 Main panel of the chamber EP2T-006-008 Cover board of the chamber EP2T-006-009 Fixed plate for the pyrocotton 6.10 EP2T-006-010 Lamp shade EP2T-007 Bottom fixed plate for the pyrocotton EP2T-008 Top fixed plate for the pyrocotton EP1T-009 Durothermic lamp EP2T-010...
- Page 6 User Manual Ⅵ. Operation instruction 1. Turn on the power supply. 1.1 The temperature of the oven can be adjusted between 0~350℃. 1.2 Turn the timer clockwise to the desired time, then the indicator light on and the heating element starts working, when it reaches the set temperature, the indicator light off.
-
Page 7: Ⅸ. Trouble Shooting
Readjust the thermostats for each heating elements to see how they work, Baking unevenly If they work well, please contact the service center to check if the Heating element need to change. Ⅹ. Specification Temperature Internal Model Dimension(mm) Voltage(V) Power(KW) range dimension(mm) EPO-2D-Premia 0~350 ℃ 560X570X440 415X400X120X2PCS 220-240V... - Page 8 User Manual Ⅺ. Wiring diagrams Marketed globally by: TRUFROST COOLING PRIVATE LIMITED 1215, 12th Floor, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122102 (India) T. +91-124- 4246560 info@trufrost.com www.trufrost.com...
