Fluke 718 Service Information

Introduction
Use the following diagrams to rebuild the Fluke 718
Pressure Calibrator pump.
How to Contact Fluke
To order accessories, receive operating assistance, or
get the location of the nearest Fluke distributor or
Service Center, call one of the following telephone
numbers:
USA and Canada: 1-888-99-FLUKE (1-888-993-
5853)
Europe: +31 402-678-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-356-5500
Address correspondence to:
Fluke Corporation
P.O. Box 9090
Fluke Everett, WA
98206-9090
U.S.A.
Or, visit Fluke's Web site at www.fluke.com.
1274353
PN
May 1999
©1999 Fluke Corporation. All rights reserved. Printed in U.S.A.
Fluke Europe B.V
P.O. Box 1186,
5602 BD Eindhoven
The Netherlands
MP15
MP11
MP13
MP12
MP14
Figure 1. Pump Rebuild Kit Parts
Pressure Calibrator
LIMITED WARRANTY & LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and
workmanship for 90 days from the date of purchase. This warranty
does not cover fuses, disposable batteries or damage from
accident, neglect, misuse or abnormal conditions of operation or
handling. Resellers are not authorized to extend any other warranty
on Fluke's behalf. To obtain service during the warranty period,
send your defective tester to the nearest Fluke Authorized Service
Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT
LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM
ANY CAUSE OR THEORY. Since some states or countries do not
allow the exclusion or limitation of an implied warranty or of
incidental or consequential damages, this limitation of liability may
not apply to you.
Parts List
Reference
Designator Description
MP11-14 O-ring
MP15 Nylon Spacer
MP16 Piston, Pump
MP17 Piston, Vernier
Not Shown 718 Pump Rebuild Kit
Service Information
MP16
MP17
718
Pump Rebuild Kit
Service Information
Part Number
146688
687449
-
-
1270835
zc01f.eps
®
1
