- Page 1 Quicklite Let’s get started VRS107/VRS1071/VRS1072/ vax.co.uk VRS108/VRS1081/VRS1082...
- Page 2 Let’s talk safety This vacuum cleaner is intended for household use only and NOT for commercial or industrial use. • Only use the vacuum cleaner indoors on dry surfaces and Basic keep the area you’re cleaning well lit. safety • Keep fingers, hair and loose clothing away from moving parts precautions and openings whilst using the vacuum cleaner.
- Page 3 Cleaning and user maintenance shall not be made by children without supervision. • Only Vax recommended tools should be used with the vacuum cleaner, use of non-branded Vax accessories/tools will invalidate your warranty. • Don’t vacuum up any flammable or combustible materials (lighter fluid, petrol, kerosene etc) or use the vacuum cleaner in an area with explosive vapours or liquid.
- Page 4 Maintaining your carpets and hard floors will ensure they keep their appearance for longer. You’ve chosen the carpets and hard floors for your home for a reason and Vax will help you take good care of them.
- Page 5 Quicklite Contents (Included with all models) Included with your machine Let’s talk safety Getting to know your machine 2-in-1 crevice tool and dusting brush Getting started Using your machine Hard floor adaptor Taking care of your machine Let’s talk technical Quicklite Pet Accessories TurboTool holder...
- Page 6 Wattage Please refer to product rating label on machine Belt Kit (Type 17)* 1-1-132048-00 Capacity 2.4L Cord length 7m TurboTool (Type 6)* 1-1-134419-00 Weight 4.7kg (dependant on model) vax.co.uk Subject to technical change without notice. To purchase consumables and accessories, please visit...
- Page 7 Getting started CAUTION: Always switch off the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and emptying the dirt container. IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will automatically turn the vacuum cleaner off. If this happens, switch the vacuum cleaner off and unplug.
- Page 8 Using your machine Plug vacuum cleaner into Turn brushbar height the mains, switch on. adjuster dial to desired setting. Place foot on floorhead Press the On/Off button and pull handle to switch on. backwards to recline. Using the hard floor adaptor Use the hard floor adaptor for best results on hard floors.
- Page 9 Using your machine IMPORTANT: Always switch off the vacuum cleaner before disconnecting or connecting the hose and accessories. The accessories can be attached directly to the hose. This vacuum cleaner is fitted with a constantly rotating brushbar. To avoid damage to your flooring, ensure the brushbar is raised to the highest setting when using the accessories.
- Page 10 Taking care of your machine IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the machine should overheat, the thermostat will automatically turn the machine off. Switch off and unplug the vacuum cleaner. Check the machine for blockages and clean the filters. Wash the filters with warm water (40°C max) and leave for 24 hours or until fully dry before replacing into the machine.
- Page 11 Taking care of your machine Cleaning the pre-motor filter Turn the dirt container lid Turn the separator Lift the pre-motor anti-clockwise to unlock clockwise to remove from filter out of the and lift to remove. the dirt container lid. central separator. 40 C max 24hr Tap excess dirt from...
- Page 12 Taking care of your machine Re-fitting the pre-motor filter and separator Slide the pre-motor filter Line up tabs on separator Line up the dirt container The separator should into the central separator. with tabs in dirt container lid with the dirt container. sit on seal in bottom of lid.
- Page 13 Let’s talk technical IMPORTANT: Unplug and switch off vacuum cleaner before performing maintenance or troubleshooting checks. Removing debris from brushbar Using a pair of scissors remove any threads or hair caught around the brushbar. Removing dirt/debris from TurboTool (Quicklite Pet only) Tabs Tabs Tabs...
- Page 14 Let’s talk technical Removing a blockage from the hose Twist upper hose Twist lower hose Remove any blockage connector anti-clockwise connector anti-clockwise by inserting wire coat and remove upper hose. to unlock. Pull and remove hanger into hose. lower hose. IMPORTANT: If the brushbar does not rotate easily then the belt may not have been fitted correctly.
- Page 15 Accessories Don’t forget your accessories! Order at: www.vax.co.uk/spares-and-solutions Pro Cleaning Kit (Type 2) 1-1-133326-00 All our best tools all in one kit that makes cleaning your home quicker, easier and with even better results. We’ve taken care of cleaning all of the hard to reach areas such as on top of cupboards and in between blinds to the dust that collates behind and within the radiator.
- Page 16 What to do if it goes wrong Problem Solution • Check the ‘This pack contains’ panel on the box to make sure the part is included with your vacuum cleaner. Is there an accessory missing? • The plug may not be fully pushed into the electrical socket. •...
- Page 17 Getting in touch * Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling. Registration required. Terms and conditions apply, see vax.co.uk for details. †...
- Page 18 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. © 2014 All rights reserved. VAX®, VAX Lozenge, are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
