QUICK GUIDE
MULTI-
PARAMETER
TESTER 35
pH/ Conductivity/ TDS/
Salinity/ Temperature
PCSTestr35, PCTestr35, PTTestr35
Technology Made Easy ...
Part of Thermo Fisher Scientific
68X441601 Rev 0 Jan'08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EUTECH INSTRUMENTS PCSTestr35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermo Scientific EUTECH INSTRUMENTS PCSTestr35

  • Page 1 All manuals and user guides at all-guides.com QUICK GUIDE MULTI- PARAMETER TESTER 35 pH/ Conductivity/ TDS/ Salinity/ Temperature PCSTestr35, PCTestr35, PTTestr35 Technology Made Easy ... Part of Thermo Fisher Scientific 68X441601 Rev 0 Jan’08...
  • Page 2: Before You Begin

    All manuals and user guides at all-guides.com Thank you for purchasing the multi-parameter tester. Please use the following instructions to set up and calibrate your tester before taking measurements. There are 3 stages to execute before using your meter: STAGE 1 : Conditioning and temperature calibration STAGE 2: Setup the system and the parameters...
  • Page 3: Calibrating The Temperature

    All manuals and user guides at all-guides.com STAGE 1 CONDITIONING Condition your tester by immersing it in tap water for at least 30 minutes before use. DO NOT use de-ionized water. CALIBRATING THE TEMPERATURE Before taking measurements, it is important to calibrate your tester to read accurately.
  • Page 4: Changing The Sensor

    All manuals and user guides at all-guides.com 5. Press the HOLD key for 5 seconds and wait till screen changes. 6. Use the keys to manually adjust until you reach the correct temperature of your sample according to the reference thermometer. 7.
  • Page 5 All manuals and user guides at all-guides.com Then replace the new electrode/sensor, ensuring the pins are lined up to the connector before inserting. Large O-Ring Insert Electrode Module Electrode Module Small O-Ring Small Tab Large Tab STAGE 2 : SET UP 1.
  • Page 6 All manuals and user guides at all-guides.com Select SYST to enter the main menu for general settings. Select PARA to set up the various parameters – pH, COND, TDS, Salinity. SAVING THE SET UP After any manual changes have been done during set up, you are required to save the setting.
  • Page 7: System Setup

    All manuals and user guides at all-guides.com SYSTEM SETUP After selecting SYST, you will see the display Unit Use the keys to switch to other settings and press ENT to select : Use this to reset the UNit calibration or factory settings.
  • Page 8 All manuals and user guides at all-guides.com Resetting previous UNit calibrations or factory settings 1. When the above screen appears, press ENT to select. 2. Use the keys to toggle between 3. To reset previous calibrations in the pH parameter, select by pressing ENT.
  • Page 9 All manuals and user guides at all-guides.com Turning the AUTO OFF function on or A.off 1. Use the keys from UNit and find a. off 2. Press ENT to select it. Use the keys to switch between a. off a. off Selecting YES means your tester will turn OFF automatically if it is not used...
  • Page 10 All manuals and user guides at all-guides.com 2. Press ENT to select it. The standard coefficient used is 2.1. Press ENT if this is correct for your sample. If not, use the keys to manually set the coefficient, then press ENT when done. Turning on or off the Automatic Temperature...
  • Page 11: Parameter Setup

    All manuals and user guides at all-guides.com Setting up the temperature unit °C°F of measurement 1. Use the keys from UNit and find °C°F 2. Press ENT to select it. 3.Use the keys to select either °C °F Press ENT when done. 4.
  • Page 12 All manuals and user guides at all-guides.com You will see the displayed on the screen first. 3. Use the keys to scroll to COND, TDS or SALT parameter. 4. Press ENT to select the parameter you want to set up. Setting up the pH Buffer 1.
  • Page 13 All manuals and user guides at all-guides.com Setting up the CoND Conductivity Parameter 1. From press ENT. PArA Then use keys to select CoND 2. Press ENT. 3. Then use keys to select either A.CAL A.CAL Selecting YES means the automatic calibration will be activated.
  • Page 14 All manuals and user guides at all-guides.com Setting up the TDS Factor 1. From press ENT. PArA Then use keys to select 2. Press ENT. 3. Use the keys to change the TDS value. For example: 0.67 FACT 4. Press ENT to confirm and return to main menu.
  • Page 15 All manuals and user guides at all-guides.com 3. Then use keys to select either UNIT UNIT to measure in Parts Per Thousand as PPT or Percentage as PER. 4. Press ENT to confirm and return to the main menu. 5. Save the changes as described on page 6.
  • Page 16 All manuals and user guides at all-guides.com 4. To continue with another buffer calibration, simply remove tester and place in another buffer solution. 5. Press ENT again to confirm the buffer value when it has stabilized. 6. When calibration is done, press the CAL key to confirm.
  • Page 17 All manuals and user guides at all-guides.com and press ENT. The tester will return to measurement mode. Calibrating TDS 1. At the display press the CAL key. 2. Place the tester in the buffer solution. 3. Press keys to scroll to the calibration standard value and press ENT.
  • Page 18: Hold Function

    All manuals and user guides at all-guides.com HOLD FUNCTION To stop measurements and lock on to a reading, press the HOLD key. The tester will not change the last reading on the screen until the HOLD key is pressed again. This function is useful when taking measurements in a dim environment.
  • Page 19 All manuals and user guides at all-guides.com Warranty The waterproof testers are warranted to be free from manufacturing defects for 1 year and the electrode module is warranted for 6 months, unless otherwise stated. If repair, adjustment or replacement is necessary and has not been the result of abuse or misuse within the time period specified, please...
  • Page 20 All manuals and user guides at all-guides.com more information Eutech Instruments’/ Oakton Instruments’ products, contact your nearest distributor or visit our website listed below: Oakton Instruments P.O Box 5136, Vernon Hills, IL 60061, USA Tel: (1) 888-462-5866 Fax: (1) 847-247-2984 E-mail: info@4oakton.com Web-site:...
