- Page 1 INSTRUCTION MANUAL Cordless Lawn Mower DLM330 Read before use. Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DLM330 Mowing width (blade diameter) 330 mm No load speed 4,300 min Part number of replacement mower blade GB00000042 Dimensions during operation L: 1,285 mm to 1,350 mm (L x W x H) W: 375 mm H: 935 mm to 975 mm... -
Page 3: Safety Warnings
Intended use SAFETY WARNINGS The machine is intended for lawn mowing. General power tool safety warnings Noise WARNING: Read all safety warnings, instruc- The typical A-weighted noise level determined accord- tions, illustrations and specifications provided ing to EN 60335-2-77, IEC 62841-4-3: with this power tool. Failure to follow all instructions Sound pressure level (L ) : 82.4 dB(A) listed below may result in electric shock, fire and/or... - Page 4 Use personal protective equipment. Always Disconnect the plug from the power source wear eye protection. Protective equipment such and/or remove the battery pack, if detachable, from the power tool before making any adjust- as a dust mask, non-skid safety shoes, hard hat or ments, changing accessories, or storing power hearing protection used for appropriate conditions will reduce personal injuries.
- Page 5 Follow all charging instructions and do not 13. Use extreme caution when reversing or pulling charge the battery pack or tool outside the the lawnmower towards you. Always be aware temperature range specified in the instruc- of your surroundings. This reduces the risk of tions. Charging improperly or at temperatures tripping during operation.
- Page 6 Do not insert the lock key into mower until it is Never operate the mower with defective ready to be used. guards or shields, or without safety devices, for example deflectors and/or grass basket, in Always wear protective goggles to protect place.
- Page 7 23. If the mower strikes a foreign object, follow Never remove or tamper with safety devices. these steps: Check their proper operation regularly. Never - Stop the mower, release the switch lever and do anything to interfere with the intended wait until the blade comes to a complete stop.
- Page 8 Avoid storing battery cartridge in a con- tainer with other metal objects such as CAUTION: Only use genuine Makita batteries. nails, coins, etc. Use of non-genuine Makita batteries, or batteries that Do not expose battery cartridge to water have been altered, may result in the battery bursting or rain. causing fires, personal injury and damage. It will...
-
Page 9: Installing The Handle
Tips for maintaining maximum NOTE: Make sure that there is no gap between the lower handle and the mower body after the clamping battery life levers are folded. Charge the battery cartridge before completely discharged. Always stop tool operation and charge the battery cartridge when you notice less tool power. Never recharge a fully charged battery car- tridge. -
Page 10: Removing The Mulching Plug
Hold the handle of the grass basket, and then Removing the mulching plug hook the grass basket on the rod of the mower body as shown in the figure. Open the rear cover. Fig.5 ► 1 . Rear cover Fig.8 Hold the mulching plug by the handle, and then ► 1 . Rod 2. Handle 3. Grass basket pull it out from the mower body as shown in the figure. To remove the grass basket, open the rear cover, and then remove the grass basket by holding the handle. -
Page 11: Functional Description
Insert the lock key in the place shown in the figure FUNCTIONAL DESCRIPTION as far as it will go. Installing or removing battery cartridge CAUTION: Always switch off the machine before installing or removing of the battery cartridge. CAUTION: Hold the machine and the battery cartridge firmly when installing or removing bat- tery cartridge. - Page 12 Turn the machine off, and then turn it on again to restart. 50% to 75% Charge the battery(ies) or replace it/them with recharged battery(ies). 25% to 50% Let the machine and battery(ies) cool down. If no improvement can be found by restoring protection 0% to 25% system, then contact your local Makita Service Center. Charge the NOTE: The timing, at which the lamp lights up, battery. depends on the temperature at work place and the battery cartridge conditions. The battery may have malfunctioned.
-
Page 13: Adjusting The Mowing Height
Press the switch button and hold it. The table below shows the relationship between the number on the mower body and the approximate mow- Hold the upper handle and pull the switch lever. ing height. Number Mowing height 20 mm 26 mm 33 mm 42 mm 52 mm 62 mm 71 mm 75 mm... -
Page 14: Adjusting The Handle Height
Adjusting the handle height OPERATION WARNING: Do not touch rotating blade. Mowing CAUTION: Before removing the bolts, hold WARNING: Before mowing, clear away sticks the upper handle firmly. Otherwise, the handle may and stones from mowing area. Furthermore, clear fall and cause an injury. away any weeds from mowing area in advance. The handle height can be adjusted in three levels. -
Page 15: Maintenance
Using the mower with the grass basket full prevents smooth blade rotation and places To maintain product SAFETY and RELIABILITY, an extra load on the motor, which may cause repairs, any other maintenance or adjustment should breakdown. be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Mowing a long-grass lawn Maintenance Do not try to cut long grass all in one go. Instead, mow Remove the lock key and battery cartridge, and the lawn in some steps. Leave a day or two between... -
Page 16: Carrying The Mower
Store the grass basket between the handle and Storage the mower body. CAUTION: When putting the machine in the upright position, place the machine on a flat and stable surface. If the machine is placed on an unstable surface, the machine may fall over and cause an injury. Store mower indoors in a cool, dry and locked place. Don't store the mower and charger in locations where the temperature may reach or exceed 40 °C. -
Page 17: Troubleshooting
WARNING: When you replace the blades, always follow the instructions provided in this manual. TROUBLESHOOTING Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to disassemble the machine. Instead, ask Makita Authorized Service Centers, always using Makita replacement parts for repairs. State of abnormality Probable cause (malfunction) Remedy Mower does not start. Battery cartridge is not installed. Install charged battery cartridge. -
Page 18: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita machine specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attach- ment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Mower blade •... - Page 20 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan DLM330- ENEU-2105 www.makita.com 20210914...
