Unlock Button
Press once to unlock and disarm alarm
Press and hold 3 seconds for panic
alarm where applicable.
OPTION 1
Press and release to activate
option 1 where added
Check with your installation center for features and functions operational on your system.
To Operate System:
1) Press the lock button to lock the doors and arm the alarm if installed. The LED alongside the
lock button will flash and the transmitter will beep once when the vehicle receives and responds
to the command.
2) Press the unlock button to unlock the doors and disarm the alarm if installed. The LED along-
side the unlock button will flash and the transmitter will beep twice when the vehicle receives and
responds to the command.
3) Press and hold the Trunk/Start button for 3 seconds to unlock the trunk. The LED alongside
the button will flash when the vehicle receives and responds to the command.
4) Press the Trunk/Start button two times in succession to start the vehicle a melody will sound
upon start. The vehicle will start and run the predetermined time set up during installation (5 to
60 minutes selectable). During this run cycle, the LED alongside the button will flash 1 time every
10 seconds indicating the vehicle is in fact running.
Anytime during the run cycle, enter the vehicle by first unlocking the doors with your transmitter,
insert your key and turn it to the run, NOT START, position, then step on the brake, the vehicle is
now in control of the ignition key the transmitter will sound a shut down / owner take over melody.
NOTE: For push to start vehicles contact your installation center for proper procedure
.
PATENTED: www.voxxintl.com/company/patents
Model PR2LED
Operators Manual
RF Upgrade Kit
Lock Button
Press once to lock and arm alarm.
Press and hold 3 seconds for panic
alarm where applicable
Trunk / Start Button
Press two times in succession to
start vehicle. Press and hold for
3 seconds for Trunk Release where applicable
OPTION 2
1
2
Press and release to activate
option 2 where added
128-9486
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PURSUIT PR2LED
Summary of Contents for PURSUIT PR2LED
- Page 1 Model PR2LED Operators Manual RF Upgrade Kit Lock Button Press once to lock and arm alarm. Press and hold 3 seconds for panic Unlock Button alarm where applicable Press once to unlock and disarm alarm Press and hold 3 seconds for panic alarm where applicable.
- Page 2 Consult your installation center for operation and information on convenience options 1 & 2 which may have been connected or added to your vehicle. Quick Stop Mode: With vehicle running, if you wish to make a quick stop and leave the vehicle running, once you arrive at your destination: a) Place the gear selector in Park, b) Set the parking brake,...
- Page 3 4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the Receivers push-button switch from 1 up to 9 times. 5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off then on. 6.
- Page 4 2) Within 5 seconds, press and release the Receivers push-button switch 1 time. 3) Within 5 seconds, turn the ignition switch off then on. 4) Within 5 seconds, press and release the Receivers push-button switch 1 time. 5) Turn the ignition switch off then on and start the vehicle. NOTE: If you have changed the programmed override code then substitute your new code tenths for step 2 above, and units for step 5 above.
- Page 5 TO BEGIN THE AUTOMATIC START UP TIMER 1. Turn the ignition key on then off. 2. Within 10 seconds, activate the RF start command two times. (Push the programmed channel button of your keychain transmitter 4 times). The parking lights will flash and the siren will chirp 4 times indicating the timed start mode is activated. The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the preprogrammed time (5, to 60 minutes), and then shut off.
- Page 6 set up and installed by your installation center. Once this feature is added when the unlock button of transmitter 1 is used, it will set driver 1 priority and when the unlock button of transmitter 2 is used it will set driver 2 priority. In this situation, the unlock button can be programmed into two receiver channels, unlock, channel 2 and driver priority 6 or 7.
- Page 7 This Page Intentionally Left Blank Page 7 128-9486 Page 7...
- Page 8 To purchase replacement transmitters or to get additional product information go to: www.pursuitcarsecurity.com FCC COMPLIANCE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
