Veto VS-228 Manual

Veto VS-228 Manual

Digital automotive analyser

Advertisement

Quick Links

Thank you for purchasing the product. Manufactured to a high standard this product will, if used according to these
instructions and properly maintained, give you years of trouble free performance.
IMPORTANT:
OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY
AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
PLEASE KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1
PERSONAL PRECAUTIONS
W h e n u s i n g t h i s m u l t i m e t e r, p l e a s e o b s e r v e a l l n o r m a l s a f e t y r u l e s c o n c e r n i n g :
Protection against the dangers of electrical current.
Protection of the meter against misuse.
Full compliance with safety standards can only be guaranteed if used with the test leads supplied. If
necessary,they must be replaced with genuine The test leads supplied with the same electronic ratings.
Failure to do so will invalidate the warranty.
×
DO NOT use leads if damaged or if the wire is bared in any way.
×
DO NOT use the meter if it has been damaged.
1.2
GENERAL SAFETY INSTRUCTIONS
WARNING! USE EXTREME CAUTION when working with high voltages.
Familiarise yourself with the application and limitations of the multimeter as well as the potential hazards.
IF IN ANY DOUBT CONSULT A QUALIFIED ELECTRICIAN.
Before commencing testing, follow instructions below and select the correct input sockets, function and
range on the multimeter.
When the meter is connected to a circuit, do not touch any unused meter terminals.
When the magnitude of the value to be measured is unknown beforehand, set the range selector to the
highest value available.
Before rotating the range selector to change functions, disconnect test probes from the circuit under test.
WARNING! Never perform resistance, transistor, diode or continuity measurements on live circuits.
Always take care when working with voltages above 35V DCor 25V ACrms. These voltages are considered a
shock hazard.
Always keep fingers behind the probe barriers whilst measuring and DO NOT use when hands are wet.
×
DO NOT touch the test leads, tips or the circuit being tested.
Choose the proper range and function for the required measurement. Do not try voltage or current
measurements that may exceed the ratings marked on the Function/Range switch.
When testing for the presence of a voltage or current, make sure the meter is functioning correctly. Take a
reading of a known voltage or current before accepting a zero reading.
×
DO NOT test voltages above 600V ACor DC- the circuitry of the multimeter will be destroyed.
DIGITAL AUTOMOTIVE ANALYSER
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE

Advertisement

loading
Need help?

Need help?

Do you have a question about the VS-228 and is the answer not in the manual?

Questions and answers

Summary of Contents for Veto VS-228

  • Page 1 DIGITAL AUTOMOTIVE ANALYSER Thank you for purchasing the product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &...
  • Page 2 WARNING! NEVER connect the multimeter to a voltage source / live circuit when the rotary switch is set to any other function apart from Voltage testing.. WARNING! Voltage checks on electrical outlets can be difficult and misleading because of the uncertainty of connection to the recessed electrical contacts.
  • Page 3: Introduction & Specification

    Features auto-ranging, and data hold functions with overload protection on all ranges. Includes relative functions including Min/Max and Peak Hold. Supplied with Inductive Coupler, test probes and thermocouple in carry case. SPECIFICATION:............Model No: VS-228 Diode Check............Yes Tach (RPM)…2-10cyl, 4-Stroke 60-9000 (x1)rpm, 600-12000 (x10)rpm Back Light.............Yes...
  • Page 4: Push Button Functions

    3. MAIN METER FEATURES Original Manual Range & Stroke 4/2(DIS), Hz, %, ms +, CYL Button Press to this button to select; STROKE 4, 2DIS, Hz ,%, ms+, CYL fig.1 Fig.2 4. PUSH BUTTON FUNCTIONS Fig.3 range& V/A/R/CAP/Hz manual Range...
  • Page 5 reference. 4.1.1 Manual Ranging The meter turns on in the autoranging 4.3.1 Press the DATA HOLD button to “freeze” mode. Press the Range button to go to the reading on the display.The “ ” manual ranging. The display icon " " will symbol will appear in the display.
  • Page 6 4.5.1 Press the MAX/MIN button to activate terminal marked “V”. If the test lead is the MAX/MIN recording mode. The in an Amp (A) or Milliampere (mA) display icon "MAX" will appear. Press the terminal, you may be injured or the MAX/MIN button again, The display icon meter damaged.
  • Page 7 DIODE (- to +) Reverse probes (+ to -) 0.4 to 0.9V Over Limit (OL) GOOD Over Limit (OL) 0.4 to 0.9V Over Limit (OL) 1.0 to 3.0V Audible Continuity ( 1.0 to 3.0V Over Limit (OL) IMPORTANT: Turn the power OFF on 0.4 to 0.9V 0.4 to 0.9V the test circuit...
  • Page 8 the Temperature Probe is also reduced 5.10.4 Connect the Black test probe to ground. w h e n s u b j e c t e d t o v e r y h i g h 5.10.5 Connect the Red test probe to the signal temperatures.
  • Page 9 terminal. 5.11.5 Insert the red lead into the V-Ω-RPM terminal. 5.11.6 Connect jumper wires between the fuel injector and the harness connector. 5.11.7 Touch the Black test probe to a good ground at the fuel injector or the negative (-) vehicle battery post. 5.11.8 Touch the Red test probe to the fuel injector solenoid driver input on the jumper cable.
  • Page 10: Electrical Specifications

    GENERAL INSTRUMENT SPECIFICATION Instrument complies IEC 1010-1 EN61010-1 with Insulation Class 2, Double Insulation Overvoltage category CATIII1000V/CATIV600V 6000 counts LCD display 5.12. RPM and ×10RPM Display with function indication 5.12.1. Using the rotary switch, select either the RPM range or the ×10RPM range (1,000 Automatic, (-) negative Polarity polarity indication.
  • Page 11 Maximum Input: 600mA DC or 600mA AC RMS on mA ranges, Electrical Specification (ACCURACY). 20A DC or AC RMS on 20A range. Accuracy is given as ± ([% of reading] + AC CURRENT [number of least significantdigits]) at Range Resolution Accuracy C to 28 C (65...
  • Page 12: Maintenance

    TYPE K TEMPERATURE CAPACITANCE Range Resolution Accuracy Range Resolution Accuracy -30°C 9.999nF ±2.5% of rdg ± 20dgts 1.0°C ± 3 % of rdg ± ~1000°C 99.99nF 5°C/8°F -22°F ~ 1.0°F (Meter only) 999.9nF 0.1nF 1832°F 9.999uF ±2.5% of rdg ± 10dgts 99.99uF 10nF 999.9uF...
  • Page 13 WARNING! To avoid electric shock, do not use the analyser until it has been fully re-assembled. 8. PARTS Item Part No. Description VS-228.01 TEMPERATURE PROBE VS-228.02 INDUCTIVE PICK-UP Environmental Protection. Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycle centre and disposed of in a manner which is compatible with the environment.
