Instruction for Solar RFID Card Lock MS3800S
Manufacturer: Hentech Technology Development Co., LTD
Add: Xinmin Industrial Zone, Longzhou Road, Lunjiao Town, Shunde District,
Foshan City, Guangdong, China 528308
Export Department: +86-757-27332335/27332339
Technical Support: +86-757-27333890
Fax: +86-757-27332330
URL：http://www.hentech.cn
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
i
f
e
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
i
f
e
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
i
f
e
Ⅰ
(
) Function Introduction
● Intelligent circuit of power recharging inside.
● High quality solar recharging, even in weak light condition.
● Open lock proximity RFID card or, support network function.
● Unlock with the mechanical structure driven by the micro-electronics machine.
● M echanical key can be used to open the door at emergency.
● This lock can be locked up automatically or manually.
● Li-ion rechargeable battery is optional
Ⅱ Characteristic
(
)
● Micro-electronics machine overcomes the shortcomings and make the lock have a
longer service-life.
● By using solar technology, it is extremely energy-saving
● Made of pure brass, long-lasting and elegant appearance
● Automatically low voltage warning
● No key, no fuss
Ⅲ
( ) Relative Parameters
Supply Voltage
Operating voltage
Standby Current
Max Current
Operating Temperature
Operating Humidity
Master Card Quantity
User Card Quantity
6 VDC (4 PCS 1.5V AA batteries)
4.40v----6.50v
20uA---60uA
130mA
-20 ℃ -- +60 ℃
< 90%
1
255
