Instruction for Blue tooth IC Card Lock
Manufacturer: Hentech Technology Development Co., LTD
Add: Xinmin Industrial Zone, Longzhou Road, Lunjiao Town, Shunde District,
Foshan City, Guangdong Province, China 528308
Export Department: +86-757-27332335/27332339
Technical Support: +86-757-27333890
Fax: +86-757-27332330
URL：http://www.hentech.cn
(Applicable to IT5500BT and IT5600BT)
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
N
o
K
e
y
,
N
o
F
u
s
s
,
I
d
e
a
s
f
o
r
l
(Ⅰ) Function Introduction
● Electric mechanics integration, highly integrate
● Convenient for hotel use
● Use Siemens encryption techniques
i
f
e
i
f
e
i
f
e
● Made of pure brass, use IC Chip card
● Mechanical key for emergency use
● Support Blue tooth, extremely convenient for management
(Ⅱ) Characteristic
● High security
● Convenient for management
●Easy to control lock by Blue tooth devices (PDA, PPC, Smart Phone)
● Low power consumption
● No key, no fuss
(Ⅲ) Relative Parameters
User Card Quantity
Supply Voltage
Standby Current
Working Current
Alarm Voltage
Working Temperature
Working Humidity
Battery Working Time
255
6V DC (4 AA Batteries)
＜6uA
200mA
4.8V
-20 ℃ -- +75 ℃
＜90%
Over One Year
Advertisement
Related Manuals for hentech IT5500BT
Summary of Contents for hentech IT5500BT
- Page 1 ● Electric mechanics integration, highly integrate Instruction for Blue tooth IC Card Lock ● Convenient for hotel use (Applicable to IT5500BT and IT5600BT) ● Use Siemens encryption techniques ● Made of pure brass, use IC Chip card ● Mechanical key for emergency use ●...
- Page 2 IV. Manipulation (Attention: this operation is only for the users who have bought the install the lock for the first time, reinitialize the lock or reset the lock address. hotel management software and the card reader) Initialization card is to initialize the lock. If you want to set the address of the lock, you Before setting the cards, you should install the driver of the card reader, please refer must first use the initialization card to initialize the lock.
- Page 3 3. To Set the Clock Card icon from the software and set a room forbidden card. Insert it into the lock slot; you Clock card is held by the administrator of the hotel, it is used to set the clock of the will hear one sound ¡...
- Page 4 Memory card (use AT24C64 card) is a special card for memorizing the data of opening set it. Insert it into the card slot; you will hear one sound ¡ di¡ ¡ with the green light on the door; it can be used after you set it to data card by software. The data include the floor the lock panel turns on.
- Page 5 Insert an unknown card to a lock you will hear ¡ di, di¡ with red light on the card is Floor block/recover card: ¡ di--¡ with green light blink one timesuccessful. maybe the other IC card that has been used by others, so the card has different password. ¡...
- Page 6 icon as Pic6.2 and you can run ¡ HT_BTLM.exe¡ to sign in the system. Then you could see Pic6.3 and input ¡ admin¡ for user ID and ¡ ht¡ for password. Pic6.2 Pic6.3 Pic6.6 Pic6.7 You can enter the system as Pic6.4 show. Make sure to open the Bluetooth Now the lock has been connected to PDA, you can use all functions as you port and then press ¡...
- Page 7 Pic6.10 Pic6.11 Pic6.8 Pic6.9 For normal use, just choose ¡ Management device¡ and ¡ Management log data¡ . First, about the ¡ Management device¡ , there are several functions as bottom side show you: Time, Address, Other and Mode. Please refer to Pic6.9 to get item ¡ Time¡ information, you can read time from the lock and set time to the lock.
- Page 8 Pic6.14 Pic6.15 Pic7.1 outline of control board Position of the initialization button (See below): Pic6.16 Ⅷ. Wires of PCB Pic7.2 Initial button...
- Page 9 How to use this button to initial a lock? You need to press down this button, you will hear ¡ di¡ and green light is on, keep Then connect the CR03 to the computer, and you should find out the correct pressing it for five seconds, green and red light will flicker alternately, then release the simulate COM port as following: button, the lock will initialized successfully.
- Page 10 After you install this card reader¡s driver, and you insert the card reader to the computer (by USB or COM, design by the type of reader you buy from our company), the computer will find a hardware and ask you to chose the driver, and you just use auto search. Now you could install the software.
- Page 11 Step 6: choose ¡ COM Setting¡ Step 7: choose the right COM Port and card reader And the steps for setting other function cards please refer to our instruction above or our software guide.
