hentech MS5000Q Instructions

Instruction for Bluetooth Lock
I. Introduction
MS5000Q applies advanced proximity technology. Every ID card has exclusive number,
which makes it easy to use and keep high security.
MS5000Q lock has 1 master card and 250 user cards. Master card can unlock MS5000Q
and add or delete user cards. User cards can only unlock MS5000Q. Once the master
card is set, you can add or delete the user cards whenever you want.
II.Electronic Parameter
Working Voltage： 6 VDC (4 pcs 1.5V AAA batteries)
External power supply: 4.5VDC-6VDC
Standby Current: less than 20uA
Operating Current: less than 90mA
Operating Temperature: -20 ℃- +75 ℃
Operating Humidity: less than 85%
Quantity of master card：1 pcs
Quantity of user card ：250 pcs
Card type ：
ID card（TK4100 or TM4001）
N o K e y , N o F u s s , I d e a s f o r l i f e
N o K e y , N o F u s s , I d e a s f o r l i f e
N o K e y , N o F u s s , I d e a s f o r l i f e
III.MS5000Q Structure
Latch
E-Key encode matching button EKeg
IV.Operation
1.Reset MS5000Q
Function: Reset the MS5000Q, all the master card and user cards will be removed.
Steps:
1) Remove the back cover of the inside handle.
2) Press the setup button (See picture2) on the battery box; the blue light is one with one
sound ¡ Bi-¡ .
3) Keep pressing the setup button 5 seconds, it will emit one long sound ¡ Bi-----¡ and the
green and blue light flash alternatively. It is tip to release the button.
4) If you release the button within 3 seconds, it will emit one sound ¡Bi---¡, Reset is Ok. If
you keep pressing the button, it will exit the operation after 3 seconds automatically.
① ②Press Setup Button
Take Off Back Cover
2.Delete Lock Password
Function: For the convenience of PDA management, you can use the PDA to set the lock
Inside
Encode button
Setup button ¡ Set¡
③ Blue/Green light flash
Setup button
Battery box
1
