Page 1: Fujitsu Lifebook
Fujitsu LifeBook S Series BIOS Guide LifeBook S Series Model: S2110 Document Date: 06/30/2005 Document Part Number: FPC58-1351-01 F U J I T S U C O M P U T E R S Y S T E M S... -
Page 2: S Series Bios
1. Turn on or restart your notebook. 2. Press the [F2] key when a message appears under the Fujitsu logo prompting you to “Press <F2>: BIOS Setup”. This will open the main menu of the BIOS Setup Utility with the current settings displayed. - Page 3 3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key. 4. When the setup utility starts with a fault present, the system displays the following message: Warning! Error message [Continue] 5.
-
Page 4: Main Menu - Setting Standard System Parameters
L i f e B o o k S S e r i e s N o t e b o o k B I O S MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS The Main Menu allows you to set or view the current system parameters. - Page 5 Table 1: Fields, Options and Defaults for the Main Menu Menu Field Options Primary Selects Primary Master: Master submenu Secondary Selects Secondary Master: Master submenu ■ Language: English (US) ■ Japanese (JP) Default Description The product # of Display the type of device on this ATA/ATAPI interface, if there is the Hard Drive one.
- Page 6 L i f e B o o k S S e r i e s N o t e b o o k B I O S Primary Master Submenu of the Main Menu The Primary Master submenu identifies what ATA devices are installed.
- Page 7 Menu Field Options ■ Transfer Mode: Standard ■ Fast PIO 1 ■ Fast PIO 2 ■ Fast PIO 3 ■ Fast PIO 4 ■ Multiword DMA 1 ■ Multiword DMA 2 ■ Ultra DMA Mode: Disabled ■ Mode 0 ■ Mode 1 ■...
- Page 8 L i f e B o o k S S e r i e s N o t e b o o k B I O S Secondary Master Submenu of the Main Menu The Secondary Master submenu is for the internal DVD/ CD-ROM drive.
- Page 9 Table 3: Fields, Options and Defaults for the Secondary Master Submenu of the Main Menu Menu Field Options ■ Transfer Mode: Standard ■ Fast PIO 1 ■ Fast PIO 2 ■ Fast PIO 3 ■ Fast PIO 4 ■ Multiword DMA 1 ■...
-
Page 10: Advanced Menu - Setting Device Feature Controls
L i f e B o o k S S e r i e s N o t e b o o k B I O S ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: Set the I/O addresses for the serial, parallel, and ■... - Page 11 Table 4: Fields, Options and Defaults for the Advanced Menu Menu Field Description Serial/Parallel Port When selected, opens the Serial/Parallel Port Configurations submenu which allows the user to modify set- Configurations tings for the serial, parallel, and internal ports. The serial and parallel ports are found on the optional port replicator.
- Page 12 L i f e B o o k S S e r i e s N o t e b o o k B I O S Serial/Parallel Port Configuration Submenu of the Advanced Menu The Serial/Parallel Port Configuration submenu provides the ability to set the I/O addresses and interrupt levels for the serial, parallel, and internal ports of your notebook and optional port replicator.
- Page 13 Table 5: Fields, Options and Defaults for Serial/Parallel Port Configuration Submenu of Advanced Menu Menu Field Options Menu Field Options ■ Serial Port: Disabled ■ Enabled ■ Auto ■ I/O Address: 3F8 - 3FF ■ 2F8 - 2FF ■ 3E8 - 3EF ■...
-
Page 14: Keyboard/Mouse Features Submenu Of The Advanced Menu
L i f e B o o k S S e r i e s N o t e b o o k B I O S Keyboard/Mouse Features Submenu of the Advanced Menu The Keyboard/Mouse Features submenu is for setting the parameters of the integrated and external mouse and keyboard. -
Page 15: Video Features Submenu Of The Advanced Menu
Video Features Submenu of the Advanced Menu The Video Features Submenu is for setting the display parameters. Main Advanced Video Features Display: [Auto] Compensation: [Enabled] Help Select Item Exit Select Menu Table 7: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu Menu Field Options ■... -
Page 16: Internal Device Configurations Submenu Of The Advanced Menu
L i f e B o o k S S e r i e s N o t e b o o k B I O S Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configuration submenu allows the user to configure other internal devices. Main Advanced Internal Device Configurations... -
Page 17: Usb Features Submenu Of The Advanced Menu
USB Features Submenu of the Advanced Menu The USB Features Submenu enables and disables legacy USB support for your system. Main Advanced USB Features Legacy USB Support: SCSI SubClass Support: Help Select Item Exit Select Menu Table 9: Fields, Options and Defaults for the ACPI Features Submenu of the Advanced Menu Menu Field Options ■... -
Page 18: Miscellaneous Configurations Submenu Of The Advanced Menu
L i f e B o o k S S e r i e s N o t e b o o k B I O S Miscellaneous Configurations Submenu of the Advanced Menu The Miscellaneous Configurations Submenu configures the miscellaneous features for your system. Main Advanced Miscellaneous Configurations... -
Page 19: Event Logging Submenu Of The Advanced Menu
Event Logging Submenu of the Advanced Menu The Event Logging Submenu configures event logging features for DMI events. Main Advanced Event Logging Event Log Capacity: Event Log Validity: View Event Log: Event Logging: System Boot Event: Clear All Event Logs: Mark Events as Read: Help Select Item... -
Page 20: Security Menu - Setting The Security Features
L i f e B o o k S S e r i e s N o t e b o o k B I O S SECURITY MENU – SETTING THE SECURITY FEATURES The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration. - Page 21 Table 12: Fields, Options and Defaults for the Security Menu Menu Field Options Supervisor –— Password is: User Password is: –— Set Supervisor [Enter] Password Set User Password [Enter] Minimum User Password Length: ■ Password on Boot: Disabled ■ First Boot ■...
-
Page 22: Hard Disk Security Submenu Of The Security Menu
L i f e B o o k S S e r i e s N o t e b o o k B I O S Hard Disk Security Submenu of the Security Menu The Hard Disk Security Submenu is for configuring hard disk security features. Main Advanced Hard Disk Security... -
Page 23: Owner Information Submenu Of The Security Menu
Owner Information Submenu of the Security Menu The Owner Information Submenu is for setting owner information. Note that Owner Information cannot be set without having entered a supervisor’s password. Main Advanced Owner Information Owner Information Is: Set Owner Information Foreground Color: Background Color: Help Select Item... -
Page 24: Boot Menu - Selecting The Operating System Source
Turns on and off booting with a truncated set of Power On Self Tests. (Fewer tests mean faster turn on.) [Disabled] Turns on and off display of test results instead of Fujitsu logo screen during Power On Self Test. [Enabled] When disabled, the boot menu is disabled and the F12 key is ignored. - Page 25 The Boot Device Priority Submenu of the Boot Menu The Boot Device Priority Submenu is for setting the order of checking of sources for the operating system. Main Advanced Boot Device Priority +Floppy Disk Drive +Hard Disk Drive CD-ROM Drive Help Select Item Exit...
-
Page 26: Info Menu - Displays Basic System Information
L i f e B o o k S S e r i e s N o t e b o o k B I O S INFO MENU – DISPLAYS BASIC SYSTEM INFORMATION The Info menu is a display only screens that provides the configuration information for your notebook. -
Page 27: Exit Menu - Leaving The Setup Utility
EXIT MENU – LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through the Setup Utility on page 2 for more information). The following table shows the names of the menu fields for the Exit menu, the default settings and a description of the field's function and any special information needed to help understand the field's use.
