Installing on the wall

Install the monitor at least 100 mm away from the wall and leave about
100 mm of space at each side of the monitor to ensure sufficient ventilation.
Detailed installation instructions can be obtained from your local retail store.
Alternatively, please refer to the manual for how to install and set up a tilting
wall mounting bracket.
100 mm
100 mm
100 mm
100 mm
To install the monitor to a wall, attach a wall mounting bracket (optional) to the
back of the monitor.
Make sure that the wall mounting bracket is securely fixed to the monitor and
to the wall.
1
If you use screws longer than the standard length, it may damage the inside
of the product.
2
A non-VESA standard screw may damage the product and cause the monitor
to fall. LG Electronics is not liable for any accidents relating to the use of
non-standard screws.
wall mount (mm) 100 x 100
standard screw M4 x L10
number of screws 4
wall mount plate (optional)
LSW 149
13
