- Page 1 Cegonia 8W 20W 30W User Manual SOLTECH offers Eco-friendly technology to help users benefit clean energy.
-
Page 2: Table Of Contents
Contents Check List Introduction Cegonia 8W Specification Luminous Distribution Battery Notes Installation and Wiring Compliance Mounting Accessories Installation—8W 0 1 2 Installation—20W/30W Cegonia 20W Panel Angle Remote Control Guide Cegonia 30W... -
Page 3: Check List
01 Check List Cegonia 8W Cegonia 20W/30W Solar Panel Luminaire Battery Kit Solar Panel Luminaire Battery Kit Component Kit A Component Kit B Component Kit C Component Kit A Component Kit B Component Kit C Trunnion (Round and Square) Trunnion (Round and Square) -
Page 4: Introduction
Cegonia 30W Introduction Please save these instructions. Read all of the instructions carefully Cegonia combine stylish design with hight efficiency. You can adjust both before attempting to carry out any installation or wiring. Do not open or LED Nominal Power... -
Page 5: Luminous Distribution
(IAP) Intelligent Adaptive Program Battery Control Technology In order to extend the off-grid autonomy of the Cegonia under shady trees, heavy rain, and thick clouds, our controllers now integrate an adaptive smart control feature to actively track battery capacity and adjust light output accordingly. -
Page 6: Installation And Wiring Compliance
6.75 inch Electrical Codes. foundation are solid enough to withstand the lighting fixture(s). 2. The Cegonia 8W, 20W and 30W models are intended for outdoor 5. Before installation, please ensure that the battery is fully charged. Install 0.4 in 0.45 in use only and should not be installed in an unventilated area, and shall during sunny days if possible. -
Page 7: Installation-8W
08 Installation—8W Cegonia 8W A. On Wall Connect Battery Pack Connect ±45° Component Kit B 180° Component Kit C Component Kit A Component Kit B Component Kit A B. On Round Pole Solar Panel Component Kit B Connect Loose screws of component kit B to adjust the angle of solar panel. -
Page 8: Installation-20W/30W 014
09 Installation—20W/30W Cegonia 20W/30W Connect Component Kit B ±45° Connect A. On Wall Battery Pack 270° Component Kit B Component Kit D Component Kit A Component Kit A Insert Solar Panel B. On Round Pole Connect Connect Component Kit B ±45°... - Page 9 10 Panel Angle 70° N 69° N 68° N 67° N The Solar charge in a battery pack won’t last forever, the off–grid 66° N system relies on stored daylight for autonomy. Angling your solar 65° N panels properly can boost the power intake of your lights. You want to angle your solar panels at a tilt equal to the area’s latitude.
- Page 10 1 1 Remote Control Guide 3. 40%~100% Motion Sensor Mode 5. Night Owl Mode Constant 40% brightness (turn on at dusk, turn off at dawn); Changes as natural light decreases/increases (turn on at dusk); 70% 100% brightness turns on for 2 minutes when motion detected. brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours (turn 1.
- Page 11 1 1 Remote Control Guide 7. 100% Constant Mode 8. 70% Constant Mode 11. Timer Mode 4 Hours 12. Time Mode 8 Hours 100% brightness from dusk to dawn. 70% brightness from dusk to dawn. This is an additional mode which can work with any other modes. This is an additional mode which can work with any other modes.
- Page 12 Cegonia products are covered by a 5 year limited warranty. Cegonia urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 5 years from date of pur- chase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
- Page 13 SOLTECH offers Eco-friendly technology to help users benefit clean energy.
