APP USER MANUAL
For Firmware V1.10
For Software V1.0.0
DESIGN INSPIRATION
The contents of this manual are subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ampero Control and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hotone Ampero Control

Summary of Contents for Hotone Ampero Control

  • Page 1 APP USER MANUAL For Firmware V1.10 For Software V1.0.0 DESIGN INSPIRATION The contents of this manual are subject to change without notice.
  • Page 2 Ampero Control and launch the app. 2. Login your account (optional). 3. Press and hold Footswitch 2+3 on your Ampero Control to enable Bluetooth Pair Mode. The Bluetooth indicator (on the bottom right corner of the screen on your unit) will flash to indicate pairing status on.
  • Page 3 1. You can enter offline mode if no device is found.  2. Ampero Control can only be edited by one device at a time. To use other devices, tap “Settings” icon on the lower right corner of the screen, find “Connection Status” and enter, then tap “Disconnect”.
  • Page 4 Ampero Control offers four footswitch modes: - Single: Send same MIDI message (s) when you press the footswitch. MIDI message (s) will be sent when the footswitch is released. - Toggle: You can set two different (A/B) groups of MIDI message (s).
  • Page 5 3. Add up to 16 MIDI messages depending on your needs by tapping the button on the bottom right of the screen. 4. Tap on a MIDI message button to edit message details: CH. : For setting MIDI output channel from 1-16; you can set it to Omni to send the message via all 16 channels.
  • Page 6 5. After editing all footswitches you needed, don’t forget to save your changes by tapping “Save” button on the top right corner of the screen. You can tap to edit bank info if needed. Note: To test your MIDI settings, you can tap button to send the MIDI message (s) immediately.
  • Page 7 Follow the instructions below: 1.Connect your expression pedal (s) to Ampero Control’s EXP/CTRL jack (s). 2.Hold footswitch 4 while powering up your Ampero Control. The screen will display “PdL” to indicate that your unit has entered Expression Pedal Calibration Mode:...
  • Page 8 USE MIDI TEMPLATES A MIDI template is a group of pre-edited MIDI message (s) that is suitable for many popular musical gear. You can simply load them or create your own MIDI templates. To Load A Template Follow the instructions below: 1.

  • Page 9: Template Menu

    To Save A Template Follow the instructions below: 1.Edit MIDI messages depending on your needs (see above). 2.Tap button to save a template. A menu will appear as shown on the right. 3.Choose a template group, enter your template name and tap Save button.
  • Page 10 To Manage Template Groups Follow the instructions below: 1. Tap to manage current template groups. 2. Tap to edit group info (see above). 3. Tap to select the template groups you want to delete. When finished, tap the Delete button on the bottom of the screen.
  • Page 11 To Manage Templates In A Group Follow the instructions: 1. Tap on a group to check the messages in the group, as shown on the right. In this menu you can tap on a message to see detailed template info: 2.

  • Page 12: Update The Firmware

    2. Tap “Settings” tab on the bottom right of your screen to enter Settings menu. 3. Tap “Device Name” button to enter your device name. Default is Ampero Control. UPDATE THE FIRMWARE Follow the instructions below: 1. Setup and pair your unit with your mobile device.
  • Page 13 4. Tap “Search Firmware Files Online” to check online firmware files. Online firmware files will be shown as below (“Downloaded” means you’ve already downloaded the firmware file to your phone): 5. Tap on a firmware file to see detailed firmware info. Click “Download Now”...
  • Page 14 2. Please DO NOT turn off the Bluetooth switch, or unplug the power jack while the update is in progress. Update fail may cause device malfunction. 3. While the update is in progress, please keep your Ampero Control and your smart device within 1m of each other to avoid signal interference.

  • Page 15: Factory Reset

    FACTORY RESET Follow the instructions below: 1. Setup and pair your unit with your mobile device. 2. Tap “Settings” tab on the bottom right of your screen to enter Settings menu. 3. Tap “Factory Reset” to execute factory reset. This will take several seconds.
