- Page 1 ROS RS-485 CEX-HD 30:1 COLOR ZOOM CAMERA OPERATION AND MAINTENANCE MANUAL SERIAL NUMBER: __________ SALES ORDER: __________ 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 52-51413 REV B...
- Page 2 STANDARD ORDERING FORMAT FOR THE RS-485 CEX-HD CAMERAS 52-51413 REV B...
-
Page 3: Table Of Contents
TABLE OF CONTENTS WARRANTY ..........................IV CUSTOMER ASSISTANCE ......................V CHANGE RECORD ........................VI DESCRIPTION ........................1 RS-485 CEX-HD CAMERA SPECIFICATIONS ..............2 POWER ............................2 CAMERA PERFORMANCE DATA ....................2 CONTROL SYSTEM ........................3 FEATURES ..........................3 DIMENSIONS ..........................3 WEIGHT ( ) ...................... -
Page 4: Warranty
(d) This warranty shall be governed by the laws of the State of California. In the event the defect is determined to be within the terms of this warranty, then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 5: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or fax or email. -
Page 6: Change Record
CHANGE RECORD DESCRIPTION DATE PRODUCTION RELEASE (EC-03235) 24AUG20 SEE EC-03310 19JAN21 52-51413 REV B... -
Page 7: Description
Soldering skills are required only for major repairs or modifications to the camera electronics. The ROS RS-485 CEX-HD camera is illustrated by the installation drawings in the appendix. The camera housing is constructed of hard-anodized aluminum or electro- polished stainless steel and is designed to be operated in natural but hostile environments. -
Page 8: Rs-485 Cex-Hd Camera Specifications
RS-485 CEX-HD CAMERA SPECIFICATIONS 2.1 POWER Operating voltage: 11 - 26 VDC, Current varies with input voltage Typical Power consumption: ~ 5 Watts 420 mA @ 12 VDC 200 mA @ 24 VDC 2.2 CAMERA PERFORMANCE DATA Sensor: 1/2.8" Exmor R CMOS (STARVIS) Pixels: 2.13M... -
Page 9: Control System
RS-485, 2 wire half duplex, 8-bit data, 1 stop bit, no parity, and no hardware flow control. Supported baud rates: 9.6k baud Networkability: Must be used with ROS IC-LINK. 2.4 FEATURES All features below are controlled via the IC-LINK: • Zoom: Direct zoom position • Focus: Automatic or manual. -
Page 10: Materials
0ºC to +50 C (32ºF to 122ºF) Storage Temperature: C to +60 Depth Rating: 70 m (230 ft) 2.9 RS-485 CEX-HD CONNECTORS Hydrogroup LPMBH-6-MP (-01 configuration) Endbell Connector: Hydrogroup LPMCBH-6-MP Inline Mating Connector: Hydrogroup LPMCIL-6-FS Figure 1: LPMCBH-6-MP Face View... -
Page 11: Camera Interconnections
SUBCONN MCBHRA-8-MP (-02 configuration) Endbell Connector: Subconn MCBHRA-8-MP Inline Mating Connector: Subconn MCIL-8-F Figure 2: MCBHRA-8-MP Face View 2.10 CAMERA INTERCONNECTIONS CONNECTOR PIN FUNCTION Camera Power Input (+11 to +26 VDC) VDC Return RS-485 A RS-485 B TVI Out Ground Spare (MCBHRA -02 only) Spare (MCBHRA -02 only) 52-51413 REV B... -
Page 12: Camera Operation
Operation of the RS-485 CEX-HD Camera is straightforward, but there are some differences, which may not be familiar to personnel accustomed to operating closed-circuit TV systems. The RS-485 CEX-HD is designed to be used with only the ROS IC-LINK controller. -
Page 13: Camera Boot-Up Sequence
RS-485 commands be accepted. 3.4 EXPOSURE CONTROL The RS-485 CEX-HD Camera provides operation over a wide range of scene illuminations. For most operations, it is recommended to simply leave the camera in automatic exposure mode, as it generally does very well at optimizing itself for the ambient illumination conditions. -
Page 14: Focus Control
Auto-Focus system will have a difficult time obtaining correct focus. In those cases, manual operation may be a better choice. 3.7 COMPUTER CONTROL All camera features are controlled using half duplex 2-wire RS-485. The ROS IC-LINK must be used to operate the CEX-HD. 52-51413 REV B... -
Page 15: Theory Of Operation
In the case of any sort of malfunction of the camera system, it is wise to resist the temptation to completely tear down the system and start replacing components indiscriminately. Many times, a quick call to the ROS Technical Support Department will help with restoring operation with minimum effort. Most failures in the field generally tend to be cabling problems, and the camera is typically the least likely cause. -
Page 16: Camera Disassembly
Check if the indicator LED (D3) on the 54-00446 is turned on. If the indicator LED is not turned on and F1 has an impedance of less than 3 ohms the 54-0046 circuit board may have to be replaced, ROS' Technical Services Department should be contacted for assistance. -
Page 17: Maintenance
6 MAINTENANCE Maintenance of the camera is typically limited to cleaning, and maintenance of the O-ring seals on the window and rear end plate. The acrylic window should only be cleaned with a commercial lens cleaner or with a mild soap and water. Use only a soft cloth or lens tissue to avoid scratching the surfaces. -
Page 18: Appendix
APPENDIX RS-485 CEX-HD CAMERA DRAWINGS 52-51405 Top Assembly, RS-485 CEX-HD 52-51411 Installation, RS-485 CEX-HD 52-51412 Wiring Diagram, RS-485 CEX-HD 52-51413 REV B...
