- Page 1 C400 Low Light Black & White Camera OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 52-51225 REV B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................V WARNINGS ......................1 DESCRIPTION ......................1 PRODUCT SPECIFICATIONS ................2 SET UP ........................3 OPERATION ......................3 MAINTENANCE ....................... 3 TROUBLESHOOTING ..................... 3 Table of Tables Table 1, Specifications .................... -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE SEE EC-01853 18NOV13 SEE EC-02192 10FEB15 52-51225 REV B... -
Page 6: Warnings
The Remote Ocean System C400 Low Light Black & White Camera is ideally suited to output video in harsh low light level environments. The C400 is rated to operate in both air and water and depths to 3000MSW. Video output is 650TVL of resolution with EIA and CCIR versions available. -
Page 7: Product Specifications
3 PRODUCT SPECIFICATIONS Electronics Horizontal Resolution 650 TVL Minimum Scene Illumination .001 Lux 1/3” SuperHAD CCD II Sensor Type Power Input 10-36 VDC Video Output Composite, 1.0 V p-p into 75 ohm Optical Focus Control Fixed, 6.0 in (152mm) to infinity Field of View in Air 83°... -
Page 8: Set Up
OFF, simply remove power with the source. 6 MAINTENANCE The C400 is intended to be maintenance free. The C400 is purged with dry Nitrogen to eliminate moisture which prevents problems with corrosion and condensation. Though the C400 is constructed of highly corrosion resistant materials, corrosion of all components can further be minimized by applying a fresh water rinse after being immersed in saltwater. -
Page 9: Table 2, Trouble Shooting
1. If possible, replace the interconnecting cable and check functionality. 2. If possible, replace the C400 camera and check functionality. 3. Verify that there is voltage from the source using a multimeter. The system should function over a range of 10 to 36 VDC.
