Abu Garcia Orra Instruction Manual

ORRA™ LOW PROFILE INSTRUCTION MANUAL
a. Congratulations
b. Pictures of Components
c. Family Info
d. How to Fill with Line
e. Drag Adjustment
f. Spool Tension Knob
g. Removing the Sideplate
h. Reel Function
i. Maintenance
j. Warranty Information
A. CONGRATULATIONS:
Thank you for purchasing one of the world's most advanced low profile reels. The combination
of low profile design, ultra-lightweight materials and precision engineering makes Abu Garcia®
THE choice for serious anglers around the globe. These reels are widely used by pros on the
tournament circuit, guides, record seeking experts and anglers who demand the very best from
their equipment. Rely on Abu Garcia® quality and dependability to keep the fun in fishing.
The following guide will explain how to get the most out of your new Orra™ low profile reel.
Each element is described by its name and function. Some features are not found on every reel
model. Read these instructions carefully before using your reel to ensure a proper understanding
of its operation.
B. COMPONENTS:
Include:
Star drag Line guide Handle Spool Spool Tension Knob
Palm Sideplate Thumbscrew Knobs Thumb Bar Brake Dial
Handle Sideplate Gear Box Frame Nut Retainer Handle Nut
Maintenance Port Screw Nut Retainer Screw Trim Ring Handle Knob Caps
