Southern States SO17542STA Owner's Manual

17.5 hp 42 inch lawn tractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

For Parts Call K&T 606-678-9623 or 606-561-4983
MODEL NO. SO17542STA
17.5 HP 42 INCH
LAWN TRACTOR
•
Assembly
•
Operation
•
For Parts and Service, contact our authorized distributor:
call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886
Maintenance
•
Service and Adjustments
•
Storage
•
Troubleshooting
•
www.mymowerparts.com
Repair Parts
188322 Rev. 1 2.10.04 TR/MH
PRINTED IN U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SO17542STA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Southern States SO17542STA

Summary of Contents for Southern States SO17542STA

  • Page 1 For Parts Call K&T 606-678-9623 or 606-561-4983 MODEL NO. SO17542STA 17.5 HP 42 INCH LAWN TRACTOR • Assembly • Operation • Maintenance • Service and Adjustments • Storage • Troubleshooting • Repair Parts For Parts and Service, contact our authorized distributor: call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886 188322 Rev.

  • Page 2: Table Of Contents

    For Parts Call K&T 606-678-9623 or 606-561-4983 TABLE OF CONTENTS Warranty ..........2 Maintenance ........17 Safety Rules .......... 3 Service and Adjustments..... 21 Product Specifi cations ......6 Storage ..........26 Assembly/Pre-Operation ....... 8 Troubleshooting ........27 Operation..........11 Repair Parts.........

  • Page 3: Safety Rules

    For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES IMPORTANT: This cutting machine is ca pa ble of amputating hands and feet and throw- ing objects. Failure to observe the fol low ing safety instructions could result in serious injury or death. •...
  • Page 4 For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES • Watch for holes, ruts, or bumps. Un- • Use extra care when approaching blind even terrain could overturn the machine. corners, shrubs, trees, or other objects Tall grass can hide ob sta cles. that may obscure vision.
  • Page 5 For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES • Remove obstacles such as rocks, tree • Be sure the area is clear of other people limbs, etc. before mowing. Stop machine if anyone • Watch for holes, ruts, or bumps. Uneven enters the area.

  • Page 6: Product Specifi Cations

    For Parts Call K&T 606-678-9623 or 606-561-4983 PRODUCT SPECIFICATIONS CUSTOMER RE SPON SI BIL I TIES • Read and observe the safety rules. Gasoline 1.25 • Follow a regular schedule in main- Capacity and Unleaded tain ing, caring for and using your tractor. Type: Regular •...
  • Page 7 For Parts Call K&T 606-678-9623 or 606-561-4983 UNASSEMBLED PARTS Steering Wheel Steering Wheel Insert (1) Hex nut 1/2-20 (1) Large Flat Washer Steering (1) Hex Bolt 1/4-28 x 1-1/4 (1) Locknut Extension 1/4-28 Shaft Steering Wheel Steering Adapter Boot Seat (1) Washer 17/32 x 1-3/16 x 12 Gauge (1) Lock...

  • Page 8: Assembly/Pre-Operation

    For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY/PRE-OPERATION Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you as sem ble must be tightened securely. Use the correct tools as nec es sary to in sure proper tightness.
  • Page 9 For Parts Call K&T 606-678-9623 or 606-561-4983 4. Push down on seat to engage shoulder NOTE: You may now roll or drive your bolt in slot and pull seat towards rear of tractor off the skid. Follow the ap pro pri ate tractor.
  • Page 10 For Parts Call K&T 606-678-9623 or 606-561-4983 ✓CHECKLIST CHECK TIRE PRESSURE The tires on your tractor were over in - Before you operate your new trac tor, we fl ated at the factory for shipping pur pos es. wish to assure that you receive the best Correct tire pressure is important for best per for mance and sat is fac tion from this cutting performance.

  • Page 11: Operation

    For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. FAST IGNITION REVERSE HIGH SLOW NEUTRAL CHOKE LIGHTS ON ENGINE START ENGINE ON PARKING BRAKE ENGINE OFF PARKING BRAKE...
  • Page 12 For Parts Call K&T 606-678-9623 or 606-561-4983 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Ignition Switch Attachment Light Switch Position...
  • Page 13 For Parts Call K&T 606-678-9623 or 606-561-4983 The op er a tion of any trac tor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Al ways wear safety glass es or eye shields while op er at ing your trac tor or per form ing any ad just ments or repairs.
  • Page 14 For Parts Call K&T 606-678-9623 or 606-561-4983 • For best cutting performance, grass Attachment Clutch Lever “Engaged” Position over 6 inches in height should be mowed twice. Make the fi rst cut rela- Attachemnt tively high; the second to desired height. Lift Lever High Position TO ADJUST GAUGE WHEELS...
  • Page 15 For Parts Call K&T 606-678-9623 or 606-561-4983 BEFORE STARTING THE ENGINE TO START ENGINE When starting the engine for the fi rst time CHECK ENGINE OIL LEVEL or if the engine has run out of fuel, it will The engine in your tractor has been take extra cranking time to move fuel from shipped, from the factory, already fi...
  • Page 16 For Parts Call K&T 606-678-9623 or 606-561-4983 MOWING TIPS • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments sec tion of this manual. • The left hand side of mower should be used for trim ming.

  • Page 17: Maintenance Schedule

    For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE SERVICE DATES Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling...
  • Page 18 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR 4. Reassemble blade bolt, lock washer and fl at washer in exact order as Always observe safety rules when per- shown. form ing any main te nance. 5. Tighten blade bolt securely (27-35 Ft. BRAKE OPERATION Lbs.
  • Page 19 For Parts Call K&T 606-678-9623 or 606-561-4983 NOTE: The original equipment battery on TO CHANGE ENGINE OIL your tractor is maintenance free. Do not Determine temperature range expected attempt to open or remove caps or cov ers. before oil change. All oil must meet API Adding or checking level of elec tro lyte is service classifi...
  • Page 20 For Parts Call K&T 606-678-9623 or 606-561-4983 MUFFLER CLEANING Inspect and replace corroded muffl er and • Clean engine, battery, seat, fi nish, etc. spark arrester (if equipped) as it could cre- of all foreign matter. ate a fi re hazard and/or dam age. •...

  • Page 21: Service And Adjustments

    For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER- VICE OR AD JUST MENTS: 1. Depress clutch/brake pedal fully and set parking brake. 2. Place gearshift lever in neutral (N) position. 3.
  • Page 22 For Parts Call K&T 606-678-9623 or 606-561-4983 TO LEVEL MOWER HOUSING • Before making any necessary ad just - ments, check that both front links are Adjust the mower while tractor is parked equal in length. on level ground or driveway. Make sure •...
  • Page 23 For Parts Call K&T 606-678-9623 or 606-561-4983 TO REPLACE MOWER BLADE DRIVE 2. Measure distance between brake op er - at ing arm and nut “A” on brake rod. BELT 3. If distance is other than 1-1/2", loos en The mower blade drive belt may be jam nut and turn nut “A”...
  • Page 24 For Parts Call K&T 606-678-9623 or 606-561-4983 Engine Washers Pulley Retaining Ring Clutching Idler Axle Cover Stationary Idler Center Span Square Key Keeper (Rear Wheel Only) Transaxle TO START ENGINE WITH A WEAK Pulley BAT TERY WARNING: Lead-acid batteries gen er ate ex plo sive gases. Keep sparks, fl...
  • Page 25 For Parts Call K&T 606-678-9623 or 606-561-4983 REPLACING BATTERY TO REPLACE FUSE WARNING: Do not short bat tery ter- Replace with 20 amp automotive-type mi nals by al low ing a wrench or any other plug-in fuse. The fuse holder is located object to contact both terminals at the behind the dash.

  • Page 26: Storage

    For Parts Call K&T 606-678-9623 or 606-561-4983 STORAGE Immediately prepare your tractor for stor- blended fuels (called gasohol or using age at the end of the season or if the trac- ethanol or methanol) can attract moisture tor will not be used for 30 days or more. which leads to separation and formation of acids during storage.

  • Page 27: Troubleshooting

    For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING CHART PROBLEM CAUSE CORRECTION Will not start 1. Out of fuel. 1. Fill fuel tank. 2. Engine not “CHOKED” 2. See “TO START ENGINE” in properly. Operation section. 3. Engine fl ooded. 3.
  • Page 28 For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING CHART PROBLEM CAUSE CORRECTION Loss of power 3. Build-up of grass, leaves and 3. Clean un der side of mower (continued) trash under mower. housing. 4. Dirty air fi lter. 4. Clean/replace air fi lter. 5.
  • Page 29 For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING CHART PROBLEM CAUSE CORRECTION Poor grass 1. Engine speed too slow. 1. Place throttle control in discharge “FAST” position. 2. Travel speed too fast. 2. Shift to slower speed. 3. Wet grass. 3.
  • Page 30 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE NOTES www.mymowerparts.com...
  • Page 31 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA SCHEMATIC BLACK BATTERY FUSE STARTER AMMETER (OPTIONAL) BLACK WHITE SOLENOID CLUTCH / BRAKE (PEDAL UP) WHITE SEAT SWITCH IGNITION (NOT OCCUPIED) SWITCH WHITE BLACK BLACK BLACK BLACK ATT'MENT CLUTCH...

  • Page 32: Repair Parts

    For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR -- MODEL NUMBER SO17542STA ELECTRICAL D .C www.mymowerparts.com...
  • Page 33 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA ELECTRICAL KEY PART NO. NO. DESCRIPTION 163465 Battery 12 Volt 25 Amp 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 176689 Box Battery 176138 Switch Interlock Push -In...
  • Page 34 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA CHASSIS AND ENCLOSURES Chassis-Elite_Basic_2 www.mymowerparts.com...
  • Page 35 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA CHASSIS AND ENCLOSURES KEY PART NO. NO. DESCRIPTION 174619 Chassis 176554 Drawbar 155272 Bumper Hood/Dash 168337X012 Dash 72140608 Bolt Carriage 3/8-16 x 1 174996 Panel Dash Lh 179174X010 Panel Dash Rh...
  • Page 36 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA GROUND DRIVE drive-fender_49 www.mymowerparts.com...
  • Page 37 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA GROUND DRIVE KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 17120614 Screw 3/8-16 x .875 - - - - - - Transaxle Peerless (206-545C) 8883R Cover Pedal Blk Round...
  • Page 38 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA STEERING steering_pl.lt_46 www.mymowerparts.com...
  • Page 39 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA STEERING KEY PART NO. NO. DESCRIPTION 140044X428 Wheel Steering Auto Black 175131 Axle Asm Front 169840 Spindle Asm Lh 169839 Spindle Asm Rh 6266H Bearing Race Thrust Harden 121748X Washer 25/32 x 1 5/8 x 16 Ga.
  • Page 40 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_17 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 170551 Control Throttle /Choke Flag 17670412 Screw Hexwsh Thdrol 1/4-20 x 3/4...
  • Page 41 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA LIFT ASSEMBLY 17 18 lift-rh.1piece_3 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 173288 Link Front 159461 Wire Asm Inner/Sprg w/Plunger 73350800 Nut Jam Hex 1/2-13 unc...
  • Page 42 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA SEAT ASSEMBLY seat_lt.bolt_1 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 175389 Seat 72050412 Bolt Rdhd Sht Nk 1/4-20 x 1-1/2 140551 Bracket Pnt Pivot Seat (blk)
  • Page 43 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA DECALS KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 156368 Decal Oper 190431 Decal Ins Strg Whl 190535 Decal Chassis 160396 Decal V-Belt Schematic 190427 Decal Hood Rh...
  • Page 44 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA MOWER DECK 42_deck_man-t-path_3 www.mymowerparts.com...
  • Page 45 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR -- MODEL NUMBER SO17542STA MOWER DECK KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 165892 Mower Deck Assembly, 42" 137729 Screw, Thdrol 1/4-20 x 5/8 T 72140506 Bolt 133944 Washer, Hardened...
  • Page 46 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE NOTES www.mymowerparts.com...
  • Page 47 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE NOTES www.mymowerparts.com...
  • Page 48 For Parts Call K&T 606-678-9623 or 606-561-4983 www.mymowerparts.com...
