CD-Rewritable Drive
8x8x32
disc tray
headphone jack
volume control

Introduction

The TEAC CD-RW Drive can write to CD-R discs at a maximum of 8X speed, re-
write to CD-RW discs at 8X speed, and read CD-ROM discs at 32X speed. (It is also
capable of operating at slower speeds, if preferred.) CD-R discs enable you to create
audio or data discs for permanent archival storage. They cannot be overwritten. You
can overwrite CD-Rewritable (CD-RW) discs, typically up to 1,000 times.
The TEAC CD-RW Drive is designed for use in IBM PC or compatible computers.
It features a 5.25-inch standard chassis and a powered tray for convenient disc loading.

Recommended System Requirements

IBM PC-compatible computer, Pentium II 300MHz or higher
CD-ROM drive with DAE support for disc-to-disc audio recording
One available 5.25-inch drive bay
64MB of RAM
A hard drive that meets or exceeds the following minimum specifications:
1GB hard disk space (or more)
1.2MB/second data transfer rate (or faster)
12ms average access time (or less)
Sufficient hard disk space for software installation (see the documentation for
the recording software)
Windows 95/98/Me/2000-Professional and NT 4.0
TEAC CD-RW Installation Guide
LED status indicators
emergency eject
mechanism opening
1
Introduction
®
eject button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD-258 E and is the answer not in the manual?

Questions and answers

Summary of Contents for Teac CD-258 E

  • Page 1 Introduction The TEAC CD-RW Drive can write to CD-R discs at a maximum of 8X speed, re- write to CD-RW discs at 8X speed, and read CD-ROM discs at 32X speed. (It is also capable of operating at slower speeds, if preferred.) CD-R discs enable you to create audio or data discs for permanent archival storage.
  • Page 2 You can connect headphones or external speakers to this jack to listen to an audio CD being played on your TEAC drive. Use a 3.5 mm stereo mini-plug. For external speakers, connect a stereo adapter to split the output into separate cables for the left and right channels.
  • Page 3 FG: Frame ground. This is a ground connection for the CD-RW Drive. Configuring the CD-RW Drive The Master/Slave/CSEL jumper configuration of your TEAC CD-RW drive will depend on whether or not you have an IDE CD-ROM/DVD drive installed in your system.
  • Page 4 Installing the CD-RW Drive Installing the CD-RW Drive This section explains how to install the TEAC CD-RW Drive into an IBM PC or compatible personal computer. Follow the steps below and refer to your computer documentation for information specific to your system.
  • Page 5 The +5v terminal is on the left as you face the rear of the panel; the +12v terminal is on the right. The two center terminals are ground terminals. TEAC CD-RW Installation Guide...
  • Page 6 The premastering software is to be purchased separately. Recommended Software Before you can record data onto CD-R or CD-RW discs using your TEAC CD-RW Drive, you must first install pre-mastering or packet-writing software onto your computer’s hard disk. TEAC recommends the following applications for Windows 95/98/Me/2000-Professional and NT: ❑...
  • Page 7 Disc Type Manufacturer CD-R Taiyo Yuden CD-RW Mitsubishi (Verbatim) Mitsui Toatsu Chemical Ricoh Mitsubishi (Verbatim) Ricoh TDK Electronics Kodak Fuji Film Hitachi (Maxell) Pioneer Sony Maxell Note: Additional TEAC media may be purchased online at www.shopteac.com. TEAC CD-RW Installation Guide...
  • Page 8 20% to 80% (non-condensing) Storage Humidity 10% to 80% (non-condensing) Safety Standards UL, CSA, TUV Technical Support TEAC America, Inc. (USA) Technical Support Telephone: (323) 727-4860 • Fax: (323) 869-8751 Monday - Friday 8:00 a.m. - 5:00 pm http://www.teac.com/dsp/new-dsp.html E-mail: dspdtsg@teac.com...
