INSTALLATION GUIDE - AUSTRALIA
URBAN RAIN HEAD CEILING MOUNTED URHCMCA
SYSTEM REQUIREMENTS
To ensure the optimum performance and customer satisfaction please adhere to the following:
• Flush out all pipe work prior to installation.
• Installation should comply with relevant local authority requirements.
Operating Pressures
Operating Hot Water Temperatures
Operating Cold Water Temperatures
AS/NZS 3500.1 states that pressures above 500kPa can cause damage from water hammer, reduce the life of appliances, taps & fittings,
cause excessive noise in the system and recommend that a pressure limiting valve (PLV) be fitted.
WHAT IS IN THE PACK
Failure to comply with the above will void warranties
1 x Vertical Arm
MINIMUM
Hot
70kPa (10.2psi)
55° C
5° C
1 x Rain Head
MAXIMUM
Cold
500kPa (72.1psi)
70kPa (10.2psi)
60° C
1 x Flow Restrictor
& Sleeve
(already fitted)
N/A
Advertisement
Table of Contents
Related Manuals for Felton URBAN URHCMCA
Summary of Contents for Felton URBAN URHCMCA
- Page 1 INSTALLATION GUIDE - AUSTRALIA URBAN RAIN HEAD CEILING MOUNTED URHCMCA SYSTEM REQUIREMENTS To ensure the optimum performance and customer satisfaction please adhere to the following: • Flush out all pipe work prior to installation. • Installation should comply with relevant local authority requirements. MINIMUM MAXIMUM Cold...
- Page 2 Warranty, Maintenance and Care YOUR COPY TO KEEP Felton Australia Pty Limited guarantees these mixers to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase. Fair wear and tear is expressly excluded.
