Summary of Contents for Data Translation DT3152-LS
Page 1
UM-16398-D DT3152-LS Getting Started Manual...
Page 2
Data Translation, Inc. Information furnished by Data Translation, Inc. is believed to be accurate and reliable; however, no responsibility is assumed by Data Translation, Inc. for its use; nor for any infringements of patents or other rights of third parties which may result from its use.
Key Hardware Features ........DT3152-LS Software........
Page 4
Contents Chapter 5: Installing and Configuring the Device Driver . . Before Installing the Device Driver ......Installing and Configuring the Device Driver in Windows 95 .
Page 5
Contents Using DT-Acquire........Performing an Area-Scan Operation .
About this Manual This manual describes how to get started using a DT3152-LS frame grabber board. Intended Audience This document is intended for engineers, scientists, technicians, or others responsible for setting up a DT3152-LS board to perform machine vision and/or image analysis operations. It is assumed that you have some familiarity with the operating characteristics of your video source.
Related Information Refer to the following documents for more information on using a DT3152-LS board: • The DT3152-LS User’s Manual (UM-16481), included on the Imaging OMNI CD provided with the DT3152-LS board, describes the features of the DT3152-LS board and DT3152-LS Device Driver in detail.
Where to Get Help Should you run into problems installing or using a DT3152-LS board, our Technical Support Department is available to provide technical assistance. Refer to the Troubleshooting chapter of the DT3152-LS User’s Manual for more information (see...
Key features of the DT3152-LS board are summarized as follows: • Operates on the PCI local bus interface; • In area-scan mode, can acquire images up to 4,096 pixels per line by 4,096 lines per frame;...
Page 13
• In line-scan mode, accepts four TTL-level digital input signals for general-purpose use; in area-scan and line-scan mode, provides four TTL-level digital output signals for general-purpose use. For more information on these features, refer to the DT3152-LS User’s Manual (see page 14 for information on installing and viewing this manual).
The DT3152-LS software, included on the Imaging OMNI CD provided with the board, includes the following components: • DT3152-LS Device Driver − You must install this device driver to use the DT3152-LS board with any of the supported software packages or utilities.
The flow diagram shown in Figure 1 illustrates the steps needed to get started using the DT3152-LS board. This diagram is repeated in each chapter; the shaded area in the diagram shows you where you are in the getting started procedure.
Installing the DT3152-LS Documentation....Viewing the DT3152-LS Documentation....
Page 18
Chapter 2 Prepare to Use the DT3152-LS Board (this chapter) Install the Board (see Chapter Connect Signals to the Board (see Chapter Install and Configure the Device Driver (see Chapter Verify Board Operation (see Chapter...
Open the shipping box and carefully remove the DT3152-LS frame grabber board. CAUTION: Keep the DT3152-LS board in its protective antistatic bag until you are ready to configure and/or install it. Verify that the following items are present: • DT3152-LS frame grabber board, and •...
Chapter 2 Checking the System Requirements For reliable operation, your DT3152-LS board requires the following minimum system requirements: • 120 MHz Pentium processor with an Intel PCI chip set that supports and enables PCI-to-posted memory writes. The following Intel PCI chip sets are known to work properly: −...
Page 21
Preparing to Use the DT3152-LS Note: Version 4, release 6 of the Phoenix BIOS works properly. However, early versions of this BIOS are known not to work properly. If your system contains an earlier version of the Phoenix BIOS, please call your system manufacturer to upgrade the BIOS to Version 4, release 6.
AC-coupled inputs to the DT3152-LS board. If your application uses only AC-coupled signals, leave jumper W1 uninstalled, and proceed to the next section. If you want to connect a DC-coupled signal to the DT3152-LS board, you must install jumper W1. Figure 2 shows the location of jumper W1 on the board.
Preparing to Use the DT3152-LS Installing the Software To install the DT3152-LS software, perform the following procedure: Insert the Imaging OMNI CD into your CD-ROM drive. Click Start from the Task Bar, then click Run. The Run dialog box appears.
If you are using Windows NT, Windows 2000, or Windows XP, perform the following steps to install the DT3152-LS documentation: Insert the Imaging OMNI CD into your CD-ROM drive. Click Start from the Task Bar, then click Run.
Page 25
Preparing to Use the DT3152-LS 15. Browse to the directory in which to copy the manual on your hard disk, the click Next. The manual is copied to your hard disk. 16. Click OK. 17. Click Main Menu, then click Exit.
Chapter 2 Viewing the DT3152-LS Documentation Note: To view the DT3152-LS documentation, ensure that Adobe Acrobat 4.0 or greater is installed on your system. Acrobat Reader 5.0 is provided on the Imaging OMNI CD. If you install Acrobat Reader 5.0 from this CD, you must open Acrobat Reader and accept the license agreement before you can view the documentation.
Page 27
Preparing to Use the DT3152-LS Here are a few helpful hints about using Adobe Acrobat Reader: • To navigate to a specific section of the document, click a heading from the table of contents on the left side of the document.
Selecting an Expansion Slot ......Inserting the DT3152-LS Board in the Computer ... .
Page 30
Chapter 3 Prepare to Use the DT3152-LS Board (see Chapter 2 starting on page Install the Board (this chapter) Connect Signals to the Board (see Chapter 4 starting on page Install and Configure the Device Driver (see Chapter 5 starting on page...
Installing the Board Setting up the Computer CAUTION: To prevent electrostatic damage that can occur when handling electronic equipment, use a ground strap or similar device when performing this installation procedure. Perform the following procedure to set up the computer: Turn off the computer.
Remove the cover plate from the selected expansion slot. Retain the screw that held it in place; you will use it later to install the board. Next, insert the DT3152-LS board in the expansion slot, as described in the next section.
Installing the Board Inserting the DT3152-LS Board in the Computer To insert the DT3152-LS board in the computer, perform the following steps: To discharge any static electricity, hold the wrapped board in one hand while placing your other hand firmly on a metal portion of the computer chassis.
Page 34
Chapter 3 Carefully lower the board into the PCI expansion slot using the card guide to properly align the board in the slot. When the bottom of the board contacts the bus connector, gently press down on the board until it clicks into place. CAUTION: Do not force the board into place.
Connecting Signals Connecting Signals to Connector J1 on the Board... . Connecting Signals to Connector J2 on the Board... .
Page 36
Damage can result if connections are made with the power on. This section describes how to connect one or more video input sources to the DT3152-LS board. This section assumes that you have purchased two optional EP306 cables.
Connecting Signals Connecting Signals to Connector J1 on the Board To connect signals to connector J1 on the DT3152-LS board, perform the following steps: After making sure power to the computer is off, push the 15-pin connector of the EP306 cable into the J1 socket at the rear of the...
Page 38
Chapter 4 Note: If you are using a DC-coupled video source, jumper W1 must be installed. Refer to page 12 for more information on installing this jumper. The EP306 cable attaches to female BNC connectors. If the video out connector on your video source is a male BNC or an RCA connector, you need to obtain an appropriate adaptor (available at electronic equipment stores).
CD shipped with the board and/or to our Web site (www.datatranslation.com) for information on connecting specific line-scan cameras to the DT3152-LS. To connect signals to connector J2 on the DT3152-LS board, perform the following steps: After making sure power to the computer is off, push the 15-pin...
Page 40
For line-scan mode only, you can attach the digital output jacks on the line-scan camera to EP306 connectors 8 or 9, if desired. Once you have connected all the required video signals to the DT3152-LS board, apply power to the computer, then apply power to your video source.
Installing and Configuring the Device Driver Before Installing the Device Driver ......Installing and Configuring the Device Driver in Windows 95 . Installing and Configuring the Device Driver in Windows 98 .
Page 42
Chapter 5 Prepare to Use the DT3152-LS Board (see Chapter 2 starting on page Install the Board (see Chapter 3 starting on page Connect Signals to the Board (see Chapter 4 starting on page Install and Configure the Device Driver...
Installing and Configuring the Device Driver Before Installing the Device Driver The DT3152-LS Device Driver is provided to support the DT3152-LS board in IBM PC-compatible Pentium systems running Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, or Windows XP.
Installing the Device Driver Under Version 4.00.950 or 4.00.950a of Windows 95 In Windows 95, you can install the DT3152-LS Device Driver when Windows 95 first detects the new DT3152-LS board at startup or install the DT3152-LS Device Driver after Windows 95 has started.
Installing and Configuring the Device Driver As Windows 95 (Version 4.00.950 or 4.00.950a) Starts To install the DT3152-LS Device Driver under version 4.00.950 or 4.00.950a of Windows 95 as it starts, perform the following steps: Start Windows 95. The New Hardware Found dialog box appears stating that a new PCI Multimedia Video Device was detected.
DT3152-LS board to the DT3152-LS Device Driver configuration. After Windows 95 (Version 4.00.950 or 4.00.950a) Has Started To install the DT3152-LS Device Driver after version 4.00950 or 4.00.950a of Windows 95 has started, perform these steps: Open the Control Panel. Double-click System.
Installing the Device Driver Under Version 4.00.950B or 4.00.950 C of Windows 95 In Windows 95, you can install the DT3152-LS Device Driver when Windows 95 first detects the new DT3152-LS board at startup or install the DT3152-LS Device Driver after Windows 95 has started.
Page 48
Chapter 5 Note: If Windows 95 does not auto-detect a newly installed board at startup, follow the procedure to install the DT3152-LS Device Driver after Window 95 has started, on page Click Next. Insert the Imaging OMNI CD into the CD-ROM drive, click Other Locations, browse to x:\DRIVERS\DT3152LS\Win95 (where x is the letter of your CD-ROM drive), then click OK.
Installing and Configuring the Device Driver After Windows 95 (Version 4.00.950B or 4.00.950 C) Has Started To install the DT3152-LS Device Driver after version 4.00950B of Windows 95 has started, perform these steps: Open the Control Panel. Double-click System. The System Properties dialog box appears.
DT3152-LS board to the DT3152-LS Device Driver configuration. Adding a Board using the Configuration Utility To add a new DT3152-LS board to the DT3152-LS Device Driver configuration at system startup, perform the following steps: Click Add New to add a DT3152-LS board.
Page 51
Installing and Configuring the Device Driver To configure the board for area-scan (two-dimensional) operations, perform the following steps: On the General tab of the DT3152LS Configuration dialog box, click Enable 2 Dimensional Mode. b. Click the 2 Dimension tab of the DT3152LS Configuration dialog box.
Page 52
Chapter 5 Click OK. The DT3152-LS Device Driver Configuration dialog box reappears; you can see the name of the board you just added. Click Close to end the DT3152-LS configuration. The DT3152-LS Configuration COMPLETE! dialog box appears. Click OK. Click OK to restart the system.
DT3152-LS board needs to be configured. 12. Click OK, then click OK to indicate that you want to configure the board. 13. Click Add New to add a DT3152-LS board. The DT3152-LS Installation dialog box appears for the new board.
Page 54
DT-Acquire and the Frame Grabber SDK. Only one name (alias) per installed board is allowed. The DT3152-LS Configuration dialog box appears. 15. On the General tab of the DT3152LS Configuration dialog box, click Enable Board to activate the board.
Page 55
However, to maximize system memory, enable only one mode at a time. 18. Click OK. The DT3152-LS Device Driver Configuration dialog box reappears; you can see the name of the board you just added. 19. Click Close to end the DT3152-LS configuration.
Note: On power-up, the PCI bus takes one available interrupt from system resources for the DT3152-LS board. If any devices are using this interrupt, problems may arise. Verify that no other devices in your system are using the same interrupt that the DT3152-LS board is using and ensure that PCI interrupts are enabled in your system BIOS.
Page 57
A dialog box appears prompting you to configure the driver. 11. Click OK, then click OK. 12. Click Add New to add a DT3152-LS board to the configuration. The DT3152-LS Installation dialog box appears for the new board. 13. Enter any unique name (or alias) for the DT3152-LS board, then click Add.
Page 58
However, to maximize system memory, enable only one mode at a time. 17. Click Done. The DT3152-LS Configuration dialog box is redisplayed; you can see the name of the board you just added. 18. Click Close to end the DT3152-LS configuration.
Installing and Configuring the Device Driver Installing and Configuring the Device Driver in Windows NT To install and configure the DT3152-LS device driver under Windows NT 4.0, perform the following procedure: Start Windows NT 4.0. From the My Computer icon, double-click Control Panel.
Page 60
Chapter 5 14. To configure the board for area-scan (two-dimensional) operations, perform the following steps: On the General tab of the DT3152LS Configuration dialog box, click Enable 2 Dimensional Mode. b. Click the 2 Dimension tab of the DT3152LS Configuration dialog box.
Page 61
Installing and Configuring the Device Driver 16. Click OK. The DT3152-LS Configuration dialog box reappears; you can see the name of the board you just added. 17. Click Close to finish. A dialog box appears, indicating that you need to restart Windows NT for the changes to take effect.
Chapter 5 Installing and Configuring the Device Driver in Windows 2000 To install the DT3152-LS Device Driver in Windows 2000, you need to disable the device, then install and configure the device driver as described in the following sections. Note: In some machines, the DT3152-LS may not be detected automatically when you start Windows 2000.
10. Select the OEMSETUP.INF file, then click Open. 11. Click OK. A Digital Signature Not Found dialog box appears. 12. Click Yes to continue. 13. Select the DT-Open Layers DT3152-LS Frame Grabber, then click Next. 14. Click Next. Another Digital Signature Not Found dialog box appears.
Page 64
Chapter 5 18. On the General tab of the DT3152LS Configuration dialog box, click Enable Board to activate the board. If you want to retain the settings but disable the board, remove the checkmark next to Enable Board. 19. To configure the board for area-scan (two-dimensional) operations, perform the following steps: On the General tab of the DT3152LS Configuration dialog box, click Enable 2 Dimensional Mode.
Page 65
However, if you want to maximize system memory, enable only one mode at a time. 21. Click OK. The DT3152-LS Configuration dialog box reappears; you can see the name of the board you just added. 22. Click Close to finish.
Chapter 5 Installing and Configuring the Device Driver in Windows XP To install the DT3152-LS Device Driver in Windows XP, you need to disable the device, then install and configure the device driver as described in the following sections. Note: In some machines, the DT315-LS2 may not be detected automatically when you start Windows XP.
Installing and Configuring the Device Driver Select Don’t prompt me again to install this software, then click Finish. The Help and Support Center window appears. Click Cancel, then click Finish. Installing/Configuring the Device Driver Once you have disabled the device, install/configure the device driver by performing the following steps: From the Control Panel, click Add Hardware.
Page 68
Chapter 5 14. Click Next. A message about the compatibility with Windows XP appears. 15. Click Continue Anyway. The DT-Open Layers configuration dialog box appears. 16. Click Add New. 17. Enter a name for the device, then click Add. 18. On the General tab of the DT3152LS Configuration dialog box, click Enable Board to activate the board.
Page 69
However, if you want to maximize system memory, enable only one mode at a time. 21. Click OK. The DT3152-LS Configuration dialog box reappears; you can see the name of the board you just added. 22. Click Close to finish.
Verifying Board Operation Overview ..........Installing DT-Acquire or LS-Acquire.
Page 72
Chapter 6 Prepare to Use the DT3152-LS Board (see Chapter 2 starting on page Install the Board (see Chapter 3 starting on page Connect Signals to the Board (see Chapter 4 starting on page Install and Configure the Device Driver...
Verifying Board Operation Overview The DT-Acquire and LS-Acquire utilities provide a quick way to verify that your board is properly installed, that the camera or cameras are properly connected, and that you can acquire images. DT-Acquire allows you to • Acquire a two-dimensional frame of video information (area scan) to system memory;...
Chapter 6 Installing DT-Acquire or LS-Acquire To install DT-Acquire or LS-Acquire, perform the following steps: Insert the Imaging OMNI CD into the CD-ROM drive. Click Start from the Task Bar, then click Run. The Run dialog box appears. Enter x:\LAUNCH.EXE where x is the letter of your CD-ROM drive).
To start DT-Acquire, double-click the DT-Acquire icon in the Data Translation, Inc\DT-Acquire\ program group. The main menu is displayed. The following subsections describe how to verify that the DT3152-LS board is working using DT-Acquire. If you have any trouble performing any of these operations, refer to the Troubleshooting chapter of the DT3152-LS User’s Manual (refer to...
From the DT-Acquire main menu, click Setup, then click Select Device. Select the alias that you gave to the DT3152-LS board when you configured the device driver, then click OK. To get started, leave the remainder of the settings under Setup at their default values.
Device. Leave the remainder of the settings under Setup at their default values. Select the alias that you gave to the DT3152-LS board when you configured the device driver, then click OK. From the DT-Acquire main menu, click Run, then Start Pass Thru!.
8 bits (256 colors) or 16 bits (65,536 colors). To start LS-Acquire, click the LS-Acquire icon in the Data Translation, Inc.\DT3152-LS program group. The main menu is displayed. The following subsections describe how to verify that the DT3152-LS board is working using LS-Acquire.
Click Board, then click Select Device, and select the alias you specified for the DT3152-LS board when you configured the device driver. Change the parameter settings to match the requirements of your camera.
Page 80
Chapter 6 Click Board, then click Select Device, and select the alias you specified for the DT3152-LS board when you configured the device driver. Change the parameter settings to match the requirements of your camera. Click Start Pass. Lines are continuously acquired and displayed on the screen.
