UM-19131-C
DT3162
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT3162 and is the answer not in the manual?

Questions and answers

Related Manuals for Data Translation DT3162

Summary of Contents for Data Translation DT3162

  • Page 1 UM-19131-C DT3162 User’s Manual...
  • Page 2 Third Edition Copyright © 2002 by Data Translation, Inc. June, 2002 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise, without the prior written permission of Data Translation, Inc.
  • Page 3 Changes or modifications to this equipment not expressly approved by Data Translation could void your authority to operate the equipment under Part 15 of the FCC Rules. Note: This product was FCC-Certified under test conditions that included use of shielded cables and connectors between system components.

  • Page 5: Table Of Contents

    Table of Contents About this Manual ....... . . Intended Audience........What You Should Learn from this Manual.
  • Page 6 DT3162 ........

  • Page 7: About This Manual

    Camera Interface Module. • Appendix “Connector Pin Assignments,” describes the pin assignments for the connectors on the DT3162 board and on the Camera Interface Module and STP15 screw terminal panel. • Appendix “RS-170 and CCIR Specifications and the DT3162,”...

  • Page 8: Conventions Used In This Manual

    • DT3162 Getting Started Manual (UM-19133). This manual (GS3162.PDF), included on the Imaging OMNI CD, describes how to set up, install, and wire signals to the DT3162 board, how to configure the DT3162 Device Driver, how to verify the operation of the board, and how to troubleshoot issues with the DT3162 board should they occur.
  • Page 9 About this Manual • GLOBAL LAB Image/2 User’s Manual (UM-17790), available from Data Translation, describes how to use GLOBAL LAB® Image/2 and GLOBAL LAB Image/2 Streamline to create scientific applications using object-oriented image processing tools. • DT Vision Foundry User’s Manual (UM-17755), available from Data Translation, describes how to use DT Vision Foundry...

  • Page 10: Where To Get Help

    Press, 1990. Provides an in-depth description of digital video fundamentals. Where to Get Help Should you run into problems installing or using the DT3162 board, the Data Translation Technical Support Department is available to provide technical assistance. Refer to the DT3162 Getting Started Manual for more information.

  • Page 11: Principles Of Operation

    Principles of Operation Video Input Signals ........Sync Signals.
  • Page 12 This chapter describes the features of the DT3162 board from a functional point of view. To aid the discussions in this chapter, refer to the block diagram of the DT3162, shown in Figure VID 0 3 to 1 VID 1...

  • Page 13: Video Input Signals

    • Triggers, and • Look-up tables (LUTs). Video Signal Types The DT3162 can acquire monochrome images from following types of standard, monochrome, composite video input signals: • RS-170/RS-343 − Standard for 60 Hz monochrome video signals. A video frame consists of 525 lines, 480 lines of which are visible.

  • Page 14: Video Input Sources

    You specify the video source (VideoSource0, VideoSource1, or VideoSource2) through software. Pin C1 of connector J1 on the DT3162 is provided for video source 0. Pin C2 of connector J1 on the DT3162 is provided for video source 1.

  • Page 15: Pixel Clock

    • Single-ended (TTL) Pixel Clock Input Source − This clock source is accessible on pin C4 of connector J1 on the DT3162. You can access this signal using the EP332 cable. Specify ExternalSource1 in software to select this pixel clock source.

  • Page 16: Triggers

    The DT3162 board supports both a software trigger and an external trigger input. The external trigger input is provided through pin 6 of connector J1 on the DT3162. You can access this signal using either EP332 cable or the Camera Interface Module.

  • Page 17: Look-Up Tables (Luts)

    Principles of Operation Look-Up Tables (LUTs) The DT3162 board provides two LUTs that you can use to change the value of an incoming pixel or affect the displayed image (also called palette matching). When the LUT gets an input pixel value, the...
  • Page 18 Video Input Signals Using software, you can select the LUT to use, and load an ASCII file or array that specifies the relationship between the pixel input values and the output values for the selected LUT.

  • Page 19: Sync Signals

    • Sync input sources, and • Sync output mode. Sync Input Sources To digitize the incoming video signal, the DT3162 board requires both a horizontal and a vertical sync input signal. The way in which the board determines the sync information depends on whether composite or variable-scan video signals are connected to the board.

  • Page 20: Variable-Scan Video Signals

    Both the EP332 cable and the CAMERA connector on the Camera Interface Module accept horizontal and vertical sync input signals. Note: Pins 1 and 2 of connector J1 on the DT3162 accept sync input signals only if sync output mode, described in the following section, is disabled.

  • Page 21: Sync Output Mode

    1 of connector J1 on the DT3162 board; the horizontal sync signal is output on pin 2 of connector J1 on the DT3162 board. The sync signals are normally output when sync output mode is enabled; however, if expose/reset is enabled, the vertical sync does not occur until the acquisition operation is started.
  • Page 22 Sync Signals • The vertical sync pulse width − Values range from 1 to 4095 lines, in increments of 1. Setting this value determines the the number of lines that the vertical sync output pulse is in its active state (determined by the sync polarity). •...

  • Page 23: Image Acquisition

    Principles of Operation Image Acquisition This section describes the following topics related to image acquisition: • Fields and frames, • Acquisition modes, • Data transfer and storage, and • Overlays. Fields and Frames You can use software to specify whether to acquire fields or frames of video information.

  • Page 24: Acquisition Modes

    Using software, you can specify one of three ways to acquire the specified fields or frames: • Single-pass synchronous mode − The DT3162 board acquires a specified number of frames or fields, saves the corresponding region on interest (ROI) in each frame/field to buffers in memory, then stops.
  • Page 25 ROIs have been acquired, if you wish, using software. Specify SinglePassAsync in software to use this mode. • Continuous asynchronous mode − The DT3162 board continuously acquires an unlimited number of fields or frames and saves the corresponding ROIs to buffers in memory until you stop the acquisition.

  • Page 26: Data Transfer And Storage

    (maximum 132 MB/s). Data is stored in monochrome format, or 8-bits per pixel. Overlays For the DT3162 board, you can use software to add overlays, such as text or graphics, on top of another displayed image that was acquired. Overlays are useful for creating animation or to display...

  • Page 27: Video Area

    The total video area is as wide as the total pixels per line (the entire area between two consecutive horizontal sync signals) and as tall as the total lines per frame. You can use software to define the total video area for the DT3162 board. Table 1 lists the settings you can program.

  • Page 28: Active Video Area

    Using software, you can define the active area for the DT3162 board. The following sections describe how to use the settings of the board to define the horizontal and vertical components of the active video area.
  • Page 29 In the horizontal video signal, blanking occurs during the horizontal sync and image border periods, which are defined by the front porch (before the horizontal sync) and back porch (after the horizontal sync). Table 2 lists the horizontal input settings you can program on the DT3162 board.
  • Page 30 Video Area Table 2: Horizontal Input Settings Setting Description Range Clamp Start The position at which the 0 to 4095 pixels clamping circuit starts holding the blanking level portion of the video signal to a reference level. Clamp End The position at which the 0 to 4095 pixels clamping circuit stops holding the blanking level portion of the...

  • Page 31: Vertical Video Signal

    ROI Height Point Active Video Vertical Sync Active Line Count Blanking Total Lines Per Frame Figure 3: Vertical Video Signal You can use software to define the vertical input settings for the DT3162. Table 3 lists the settings you can program.

  • Page 32: Region Of Interest (Roi)

    The width of the ROI is the number of pixels per line of video. The height of the ROI is the number of lines per frame. Table 4 shows the settings you can program on a DT3162 board to define the ROI.
  • Page 33 Principles of Operation Table 4: ROI Settings for the DT3162 Boar d Setting Description Range ROI Left The first pixel in the region 0 to 2039 pixels of interest, relative to the first active pixel, to acquire. ROI Width The number of pixels per...
  • Page 34 Video Area First Active Pixel ROI Left Total Video Area First Active Line Active Video Area Total Lines Active per Frame Line Height Count ROI Width Active Pixel Count Total Pixels per Line Figure 4: Spatial Relationship...

  • Page 35: Expose/Reset Signal

    You can access the expose/reset signal, which is provided on pin 7 of connector J1 on the DT3162 board, using the EP332 cable or the CAMERA connector on the Camera Interface Module.
  • Page 36 Expose/Reset Signal Note: The expose/reset stop line plus the vertical sync delay must be less than or equal to 65535. The qualified acquisition trigger can be an internal (software) trigger if you are acquiring one frame only, or an external trigger (ExternalForEach) if you are acquiring more than one frame.

  • Page 37: Strobe Output Signal

    You can generate a strobe output pulse to control lighting for a progressive scan camera. The strobe output pulse is provided on pin 12 of connector J2 on the DT3162 board. To access this signal, use the STP15 screw terminal panel and EP337 cable.

  • Page 38: Digital I/O Signals

    DT3162 boards provide four dedicated digital input lines and four dedicated digital output lines. Pins 1 to 4 of connector J2 on the DT3162 board are provided for the digital input signals. Pins 6, 7, 8, and 11 of connector J2 on the DT3162 board are provided for the digital outputs.

  • Page 39: Appendix A: Specifications

    Specifications...
  • Page 40 High-Level Output Voltage (VOH) 2.4 V − Low-Level Output Voltage (VOL) 0.5 V Table 6 lists the digital input electrical specifications for the DT3162 frame grabber board. Table 6: Digital Input Electrical Specifications Minimum Maximum Feature Specification Specification Input High Level (V 2.0 V...
  • Page 41 Specifications Table 7 lists the power specifications for the DT3162 board. Table 7: Power Specifications Feature Specification +5 V Typical: 30 mA Maximum: 45 mA +3.3 V Typical: 250 mA Maximum: 375 mA +12 V Typical: 110 mA Maximum: 165 mA −12 V...
  • Page 42 Appendix A Table 8 lists the physical and environmental specifications for the DT3162 board. Table 8: Physical and Environmental Specifications Feature Specification Dimensions Overall including faceplate and connectors: 10.6 cm x 19.5 cm (4.2 in x 7.7 in) PCB: 10.6 cm x 18.1 cm (4.2 in x 7.1 in) Weight 130 g (4.6 ounces)
  • Page 43 µ Minimum pulse width: Maximum frequency: 300 Hz Power Consumption 5 V (from the DT3162) @ 10.5 mA typical; External +12 V @ 4.7 mA typical without camera Enclosure Dimensions 158 mm (6.22 inches) x 34.3 mm (1.35 inches) x 77.5 mm (3.05 inches) Weight 278 g (0.613 g)
  • Page 44 Appendix A Table 10 lists the specifications for the connectors on the DT3162 board and the Camera Interface Module. Table 10: Connector Specifications Connector Specifications DT3162 J1 Connector Molex MicroCross connector (DVI-I Digital/Analog Visual Interface) part number 74320-1004 DT3162 J1 Mating Connector...

  • Page 45: Appendix B: Connector Pin Assignments

    Connector Pin Assignments J1 Connector ......... . . J2 Connector .

  • Page 46: J1 Connector

    Appendix B J1 Connector The DT3162 has a Molex MicroCross connector, labelled J1, which accommodates the following signals: three video sources, one differential pixel clock, one TTL pixel clock, one horizontal sync, one vertical sync, one trigger input, one expose/reset signal, and a +5 V power signal.
  • Page 47 The Camera Interface Module accepts a TTL pixel clock and converts it to these differential signals for use by the DT3162. If you want to provide a differential pixel clock source, you must build your own cable to mate with this...

  • Page 48: J2 Connector

    Appendix B J2 Connector The DT3162 has a 15-pin subminiature-D connector, labelled J2, which accommodates the digital I/O, strobe output, and +5 V signals. Figure 5 illustrates the pin locations of connector J2. Table 11 describes the pin assignments of this connector.
  • Page 49 Connector Pin Assignments Table 12: DT3162 - J2 Connector Pin Assignments Description Description Digital Input 0 Digital Input 1 Digital Input 2 Digital Input 3 Ground Digital Output 0 Digital Output 1 Digital Output 2 Not Connected Ground Digital Output 3...

  • Page 50: Camera Interface Module Connectors And Screw Terminals

    Table 13. By configuring jumpers on the Camera Interface Module, you can affect which signals are accessed through pins 6 to 11 on this connector. Refer to the DT3162 Getting Started Manual for more information on configuring these jumpers. WARNING! Refer to you camera documentation before configuring pins 6 through 11 of this connector.
  • Page 51 Connector Pin Assignments Table 13: Hirose (CAMERA) Connector Pin Assignments Description Description Digital Ground +12 V Video 0 Return Video 0 Digital Ground HSync or Expose/ Reset VSync or Expose/Reset Digital Ground HSync, Pixel Clock, or Digital Ground Expose/Reset Pixel Clock, Digital Ground Expose/Reset, or +12 V a.
  • Page 52 DT3162. The VCP connector (J1) on the Camera Interface Module connects to connector J1 on the DT3162 board. The pin assignments of the VCP connector on the Camera Interface Module are listed in Table...
  • Page 53 Connector Pin Assignments Table 14: Camera Interface Module - VCP Connector Pin Assignments Description Description Not Connected Digital Ground Reserved Reserved Video Input 0 Video Input 1 Video Input 2 Reserved Analog Ground a. Use software to specify whether these signals are inputs or outputs (sync output enabled or disabled).

  • Page 54: Stp15 Connectors And Screw Terminals

    The STP15 contains one 15-pin connector and two screw terminal blocks (TB1 and TB2). The 15-pin connector provides access to the signals from connector J2 on the DT3162 board. Figure 7 shows the layout of the STP15 and the screw terminal descriptions.
  • Page 55 STP15 on a DIN rail. To mount the STP15 on a DIN rail, you need two DIN rail mount adapters (Phoenix Contact part number 1201578 or Data Translation part number 18083), and four thread form screws (Bossard part number BN2724M3x8 or Data...
  • Page 56 Appendix B...

  • Page 57: Appendix C: Rs-170 And Ccir Specifications And The Dt3162

    RS-170 and CCIR Specifications and the DT3162 RS-170 Specification ........

  • Page 58: Rs-170 Specification

    483 total active lines, and 241.5 active lines per field. Field 2 (the even field) is dominant. Figure 8 shows the relationship between the line numbers defined by the RS-170 specification and those defined by the DT3162 in a vertical signal, as well as the transition between fields.
  • Page 59 RS-170 and CCIR Specifications and the DT3162 RS170 Line Numbers Video V Sync Field 2 (Even) Field 1 (Odd) Field DT3162 Line Numbers RS170 Line Numbers Video V Sync Field 2 (Even) Field 1 (Odd) Field DT3162 Line Numbers Figure 8: Line Numbers and Field Transitions for RS-170 Vertical Signals...
  • Page 60 Appendix C First Active Line RS170 Line Numbers Video High signal V Sync Field 1 (Odd) Field DT3162 Line Numbers First Complete Active Line RS170 Line Numbers Video High signal V Sync Field 2 (Even) Field DT3162 Line Numbers First Complete...

  • Page 61: Rs-170 Horizontal Signals And The Dt3162

    RS-170 and CCIR Specifications and the DT3162 RS-170 Horizontal Signals and the DT3162 As defined by the RS-170.CCF configuration file provided with the DT3162, each line of RS-170 video contains 794 total pixels and 640 active pixels. Figure 10 shows the default settings for RS-170 horizontal signals.

  • Page 62: Ccir Specification

    Figure 11 shows the relationship between the line numbers defined by the CCIR specification and those defined by the DT3162 in a vertical signal, as well as the transition between fields. Note: To maintain field 1 dominance and not acquire half lines at the top of field 1 and at the bottom of field 2, only 572 lines can be acquired.
  • Page 63 RS-170 and CCIR Specifications and the DT3162 CCIR Line Numbers Video V Sync Field 2 (Even) Field 1 (Odd) Field DT3162 Line Numbers CCIR Line Numbers Video V Sync Field 2 (Even) Field 1 (Odd) Field DT3162 Line Numbers Figure 11: Line Numbers and Field Transitions for CCIR Vertical Signals...
  • Page 64 Appendix C First Complete Active Line CCIR Line Numbers Video High signal V Sync Field Field 1 (Odd) DT3162 Line Numbers First Complete Active Line CCIR Line Numbers Video High signal V Sync Field 2 (Even) Field DT3162 Line Numbers...

  • Page 65: Ccir Horizontal Signals And The Dt3162

    RS-170 and CCIR Specifications and the DT3162 CCIR Horizontal Signals and the DT3162 As defined by the CCIR.CCF configuration file provided with the DT3162, each line of CCIR video contains 960 pixels and 768 active pixels. Figure 13 shows the default settings for CCIR horizontal signals.
  • Page 66 Appendix C...

  • Page 67: Appendix D: Values For Use With The Dt-Active Monochrome Frame Grabber Control

    Values for Use with the DT-Active Monochrome Frame Grabber Control...
  • Page 68 Appendix D Table 15 lists the DT3162 values for each property of the DT-Active Monochrome Frame Grabber control. Table 15: DT3162 Values for the DT-Active Monochrome Frame Grabber Control Category Property DT3162 Values General ActiveLUT 0 or 1, in increments of 1...
  • Page 69 Values for Use with the DT-Active Monochrome Frame Grabber Control Table 15: DT3162 Values for the DT-Active Monochrome Frame Grabber Control Category Property DT3162 Values Trigger TriggerType Internal, ExternalToStart, or Properties ExternalForEach TriggerTransition OnHighToLow or OnLowToHigh Video Signal LineFrequency 1 to 65535 Hz, in increments of 1 Hz...
  • Page 70 Appendix D Table 15: DT3162 Values for the DT-Active Monochrome Frame Grabber Control Category Property DT3162 Values Region of RoiLeft 0 to 2039 pixels, in increments of 1 Interest RoiTop 0 to 2047 lines, in increments of 1 Properties RoiWidth...

  • Page 71: Index

    Index Symbols connector CAMERA +12 V screw terminal block J1 on the Camera Interface Module J1 on the DT3162 J1 on the STP15 AC-coupled signals VIDEO 1 AcquireType property VIDEO 2 acquisition modes continuous mode active line count contrast active video area...
  • Page 72 InputLineEventMask property interlaced frame internal pixel clock physical specifications interrupts pin assignments CAMERA connector J1 connector on the Camera Interface J1 connector Module on the Camera Interface Module J1 on the DT3162 on the DT3162 board on the STP15 J2 connector...
  • Page 73 Index pixel RoiLeft active number per line RoiTop first active RoiWidth modifying value StrobeEnabled total number per line StrobePolarity pixel clock StrobeStartLine external StrobeStopLine internal SyncInSource PixelClockSource property SyncOutEnabled power specifications SyncOutPolarity progressive frame Timeout properties TotalLinesPerFrame AcquireType TotalPixelsPerLine ActiveLineCount TriggerTransition ActiveLUT TriggerType...
  • Page 74 Index TRIGGER screw terminal block triggers screw terminal blocks TriggerTransition property on the Camera Interface Module TriggerType property on the STP15 screw terminal panel layout single-pass asynchronous mode single-pass synchronous mode variable scan signals sources vertical specifications sync signals digital input video signal digital output VIDEO 1 connector...
