- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / Assembly instructions Croma Showerpipe 160 1jet 27245000...
- Page 2 中文 • 自动防止回流 安全技巧 • 该产品专为饮用水设计！ 装配时为避免挤压和切割受伤，必须戴上手 符号说明 套。 本产品只允许作为洗浴、卫生和洁身之用。 请勿使用含有乙酸的硅胶！ 不得让儿童和肢体、精神和/或意识有障碍的 调节 (参见第页 10) 成人在不受监管的情况下使用淋浴系统。受酒 精或毒品影响的人员不得使用淋浴系统。 热水温度调节。如果使用即热式喷头，则不建议 冷热水管间过大的压力差必须予以平衡。 安装热水阀门。 必须避免让身体敏感部位 (如眼睛) 接触到莲蓬 大小 (参见第页 11) 头喷水。必须保持莲蓬头与人头之间有足够的 距离。 流量示意图 (参见第页 11) 该产品不得作扶柄使用。必须安装单独的扶 时的流速 柄。 头顶花洒夹持杆只为夹持头顶花洒而设计，不 手持花洒 顶置花洒 得让其承载其它物品！ 备用零件 (参见第页 17) 安装提示 • 安装前必须检查产品是否受到运输损害。 安装 选装附件 (参见第页 17) 后将不认可运输损害或表面损伤。 • 管道和阀门必须根据通用标准进行安装、冲洗 不在供货范围内 和检查。 匹配瓷砖的圆盘 #95163000 • 请遵守当地国家现行的安装规定。 • 本安装说明中所规定的安装尺寸理想用于身高...
- Page 3 中文 问题 原因 补救 - 起泡器结垢，脏污 - 检查起泡器，视需要更换 龙头出水量小 - 阀芯损坏，结垢 - 更换阀芯 龙头不灵活 - 阀芯损坏 - 更换阀芯 龙头滴水 - 沉积物 - 清洁分流器 分流器不工作 给 形环上油 - 水压过低 - 增加水压 - 分流器损坏 - 更换分流器 - 温度限制器设置错误 - 设置温度限制器 热水温度过低，没有冷水。选择 - 交叉流动 - 更换阀芯 冷水时，热水器启动。 安装 (参见第页 6)
- Page 4 English • If required, the bottom part of the pipe between the Safety Notes fixture and the shower head can be shortened with a Gloves should be worn during installation to prevent fine-toothed saw. crushing and cutting injuries. Technical Data The product may only be used for bathing, hygienic Operating pressure: max. 1 MPa and body cleaning purposes. Recommended operating pressure: 0,15 - 0,5 MPa Children as well as adults with physical, mental and/ Test pressure: 1,6 MPa or sensoric impairments must not use this product (1 MPa = 10 bar = 147 PSI) without proper supervision. Persons under the Hot water temperature: max. 70°C influence of alcohol or drugs are prohibited from Recommended hot water temp.: 65°C using this product. Thermal disinfection: max. 70°C / 4 min The hot and cold supplies must be of equal • Safety against backflow pressures. • The product is exclusively designed for drinking Do not allow the streams of the shower touch water! sensitive body parts (such as your eyes). An Symbol description adequate distance must be kept between the shower and you.
- Page 5 English Fault Cause Remedy Insufficient water - Aerator calcified, dirty - Clean aerator, replace as necessary Mixer stiff - Cartridge defective, calcified - Exchange cartridge Mixer dripping - Cartridge defective - Exchange cartridge Diverter not operating - Residue - Clean converter / grease O-rings - Water pressure to low - Increase water pressure - Diverter defective - Exchange diverter Hot water temperature too low, no - Hot water limiter incorrectly set - Set hot water limiter cold water. Instantaneous water - Crossflow - Exchange cartridge heater starts up when cold water is selected. Assembly (see page 6)
- Page 6 36 mm max. 39 mm 95163000 max. 5 mm...
- Page 7 SW 24 mm SW 30 mm (17 Nm)
- Page 8 Ø...
- Page 9 94246000 95659000 94246000 SW 17 mm (10 Nm)
- Page 10 0,3 MPa 0,3 MPa 60 °C 10 °C 0,3 МПа 0,3 لﺎﻜﺴﺑﺎﺠﻴﻣ 36°C 38°C 50°C 60°C 43°C 55°C 17 x...
- Page 11 Croma Showerpipe 160 1 jet 27245000 Ø Ø 68 G1/2 ± 12 Croma Showerpipe 160 1 jet 27245000...
- Page 12 开 / open 开 /open 关 / close 热 / hot...
- Page 13 冷 / cold Croma 100 Vario 28537007...
- Page 14 www.hansgrohe.com/ cleaning-recommendation QUICK CLEAN www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation Just clean: simply rub over the spray nozzles to remove lime scale. 清洁：只需要揉搓花洒表面的出水孔即可去 除水垢。 www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation cleaning-recommendation www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation cleaning-recommendation cleaning-recommendation Cleaning recommendation / Warranty / Contact 清洁指南 / 担保 / 接触 www.hansgrohe.com/ www.hansgrohe.com/ www.hansgrohe.com/ cleaning-recommendation cleaning-recommendation cleaning-recommendation...
- Page 15 94246000 max. 10 min 20 mm > 1 min...
- Page 16 94246000 > 1 min...
- Page 17 Croma Showerpipe 160 1jet 27245000 95401000 95406000 95163000 94246000 95659000 28450000 (9 l/min) 96179000 96179000 95405000 95160000 28537007 94246000 93339000 98131000 (15x2,5) 94140000 SW 24 mm 96157000 98382000 SW 30 mm (12x2,25) 97981000 97979000 96467000 92730000 97977000 97220000 98163000 SW 30 mm (15x2) 98193000 95008000 95657000 (32x2) (SW 19 mm) 95140000 98058000...
