Matatakitoyo Torque Tools FTD-1N Operation Manual

Torque Screwdriver, Pre-Set Type
OPERATION MANUAL

BEFORE STARTING

1. Study this instruction before use.
2. This torque wrench as calibrated and tested before leaving the factory is certified to meet the current standard
specification and has an accuracy of ±6%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTERNERS ONLY. DO
NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Over torque will cause tool damage and personal injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result of losing accuracy and void the warranty.
7. Do not continuously apply force after hear click or feel shock.
8. Do not use any format of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Use special care at minimum torque setting.
10. Please wear gloves and goggles when working.
WARNING
BEFORE OPERATING
1. Before using the torque screwdriver, it is necessary to activate the inner spring to
ensure accuracy.
2. To activate the inner spring, place the bit securely in a bench vise and turn torque
screwdriver clockwise until it clicks.
3. Continue turning clockwise until 20 clicks have been reached.
Ignoring this step can result in improper torque and cause possible damage.

TO USE

1. Once the inner spring has been activated, simply turn the
torque screwdriver clockwise until it clicks.
2. The torque screwdriver is precisely calibrated to provide
accurate torque every time when used properly.
Models covered
FTD
TORQUE
4
CONTENTS
Torque Screwdriver
Supplied in
Manual
a metal box.
0.35
Nm
