AVS RS4R-2020 Install Manual

Parking sensors

Advertisement

Quick Links

AVS PARKING SENSORS – INSTALL GUIDE
INTRODUCTION
Thank you for purchasing an AVS parking sensor system.
This system is designed to be installed by a professional installer with the appropriate qualifications, experience and tools and
is not suitable for DIY installation.
The AVS parking sensor system is suitable for vehicles with a 12VDC power system.
Sensors can be painted prior to installation; we recommend using PLASTIC ADHESION PROMOTER before ACRYLIC colour and
clear coats. Do not allow paint to run into the ring/gap on the sensor head as this may significantly effect sensitivity.
SENSOR PLACEMENT
1.
Sensors must be installed on the outermost points on the front and/or rear of the vehicle. Vehicle parts which extend
further than the sensor position (e.g. bull bars & towbars) may cause false triggers. Position sensors accordingly.
2.
The sensors must be installed at a height of between 40cm and 60cm from the ground.
3.
The surface chosen must be vertical and flat (avoid uneven areas).
STEP 1 – FITTING THE SENSORS
1.
Measure the width of the vehicle and divide by 8.
th
2.
Measure 1/8
from each side and mark location using a marker.
3.
Measure from both marks in 2/8
4.
Use included hole saw to drill holes at each mark.
5.
Fit the sensors and run the sensor cables to the control module.
See the next page for diagrams.
MODELS COVERED BY THIS GUIDE: RS4R-2020, RS8
th
and mark. You now have four marks.
Last updated: July 2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the RS4R-2020 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVS RS4R-2020

  • Page 1 This system is designed to be installed by a professional installer with the appropriate qualifications, experience and tools and is not suitable for DIY installation. The AVS parking sensor system is suitable for vehicles with a 12VDC power system. Sensors can be painted prior to installation; we recommend using PLASTIC ADHESION PROMOTER before ACRYLIC colour and clear coats.
  • Page 2 STEP 2 – POSITION THE CONTROL MODULE AND THE BUZZER/DISPLAY Position the control module in a location where it will be protected from damage, water and dust. Usually the control unit is mounted behind a panel in the boot close to the rear lights. Position the buzzer/display (model dependent) in a location where it can be easily heard/seen from the driver’s seat.
  • Page 3 STEP 3 – CONNECTING IT ALL TOGETHER AVS RS4R-2020 Instructions: Connect the RED wire to the reverse lights (+12VDC) Connect the BLACK wire to the vehicle’s ground/chassis. Solder and tape all connections. Ensure all sensor plugs and cables are connected correctly and the connectors are locked tight.
  • Page 4 AVS RS8 Instructions: Connect the RED wire to Reverse (+12VDC) Connect the BLACK wire to the vehicle’s ground/chassis. Connect the YELLOW wire to the foot brake light switch (+12VDC) when the brake is applied). Solder and tape all connections. Ensure all sensor plugs and cables are connected correctly and the connectors are locked tight.
  • Page 5 STEP 4 – OPERATION / TESTING THE REAR SENSORS When the vehicle is in reverse gear (reverse light on) objects in range of the sensors will be indicated by the buzzer/display. See the table below:...
  • Page 6 COMPLEX SITUATIONS There are some situations where the system will have difficulty detecting obstacles or may give inaccurate indications.
  • Page 7: Important Notes

    STEP 4 – OPERATION / TESTING THE FRONT SENSORS When the brake pedal is pressed the front sensors activate. Objects in range of the sensors will be indicated by the buzzer/display. See the table below: IMPORTANT NOTES Ø Parking sensors are an aid to vehicle reversing and parking however they are not a replacement for rear vision mirrors. Always use the vehicle’s mirror and visually check for obstacles before moving the vehicle.
  • Page 8: Troubleshooting

    TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Check power lead connections and The system fails to start when Incorrect connection of power control module connector (if vehicle is in reverse gear source applicable) The system always detects the Check and adjust the vertical angle Sensor is likely detecting the ground same distance of the sensor...
