AVS PARKING SENSORS – INSTALL GUIDE
MODELS COVERED BY THIS GUIDE: RS4F, RS4R, RS8B, RS8D
INTRODUCTION
Thank you for purchasing an AVS parking sensor system.
This system is designed to be installed by a professional installer with the appropriate qualifications, experience and
tools and is not suitable for DIY installation.
The AVS parking sensor system is suitable for vehicles with a 12VDC power system.
Sensors can be painted prior to installation, we recommend using PLASTIC ADHESION PROMOTER before ACRYLIC
colour and clear coats. Do not allow paint to run into the ring/gap on the sensor head as this may significantly effect
sensitivity.
SENSOR PLACEMENT
1.
Sensors must be installed on the outermost points on the front and/or rear of the vehicle. Vehicle parts which
extend further than the sensor position (e.g. bull bars & towbars) may cause false triggers. Position sensors
accordingly.
2.
The sensors must be installed at a height of between 40cm and 60cm from the ground.
3.
The surface chosen must be vertical and flat (avoid uneven areas).
STEP 1 – FITTING THE SENSORS
1.
Measure the width of the vehicle and divide by 8.
th
2.
Measure 1/8
from each side and mark location using a marker.
3.
Measure from both marks in 2/8
4.
Use included hole saw to drill holes at each mark.
5.
Fit the sensors (note the orientation on the back of the sensor U­P) and run the sensor cables to the control
module.
See the next page for diagrams.
Last updated: June 2019
th
and mark. You now have four marks.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RS4F and is the answer not in the manual?

Questions and answers

Summary of Contents for AVS RS4F

  • Page 1 This system is designed to be installed by a professional installer with the appropriate qualifications, experience and tools and is not suitable for DIY installation. The AVS parking sensor system is suitable for vehicles with a 12VDC power system. Sensors can be painted prior to installation, we recommend using PLASTIC ADHESION PROMOTER before ACRYLIC colour and clear coats.
  • Page 2 STEP 2 – POSITION THE CONTROL MODULE AND THE BUZZER/DISPLAY Position the control module in a location where it will be protected from damage, water and dust. Usually the control unit is mounted behind a panel in the boot close to the rear lights. Position the buzzer/display (model dependent) in a location where it can be easily heard/seen from the driver’s seat.
  • Page 3 STEP 3 – CONNECTING IT ALL TOGETHER AVS RS4F Instructions: Connect the RED wire to ACC (+12VDC) – include the optional override switch (AVSSWITCH) if using. Connect the YELLOW wire to the foot brake light switch (+12VDC when the brake is applied).
  • Page 4 AVS RS4R Instructions: Connect the RED wire to the reverse lights (+12VDC) Connect the BLACK wire to the vehicle’s ground/chassis. Solder and tape all connections. Ensure all sensor plugs and cables are connected correctly and the connectors are locked tight.
  • Page 5 AVS RS8B / RS8D Instructions: Connect the RED wire to ACC (+12VDC) – include the optional override switch (AVSSWITCH) if using. Connect the BLACK/WHITE wire to the reverse lights (+12VDC). Connect the BLACK wire to the vehicle’s ground/chassis. Connect the BLACK/WHITE wire to the foot brake light switch (+12VDC when the brake is applied).
  • Page 6 STEP 4 – OPERATION / TESTING THE REAR SENSORS When the vehicle is in reverse gear (reverse light on) objects in range of the sensors will be indicated by the buzzer/display. See the table below:...
  • Page 7 COMPLEX SITUATIONS There are some situations where the system will have difficulty detecting obstacles or may give inaccurate indications.
  • Page 8: Important Notes

    When the brake pedal is pressed the front sensors remain active for 12 secs or 20 seconds depending on the model (AVS RS8B / AVS RS8D = 12 secs, AVS RS4F = 20 secs). Objects in range of the sensors will be indicated by the buzzer/display.
  • Page 9: Troubleshooting

    Sensor is likely detecting the ground of the sensor TECHNICAL SPECIFICATIONS Voltage 9.6-15VDC Current 150mA Operating temperature -20° to 80°C Operating frequency 39.3-40.7KHz Horizontal detection angle 120° Vertical detection angle 60° Detection accuracy Max detection range RS4F 1m RS4R/RS8B/RS8D 2.5m...

This manual is also suitable for:

Rs4rRs8bRs8d
