Digilink MK2
Digilink MK2
Digilink MK2
Digilink MK2
Digilink MK2
Programmable UHF Radio Paging System
Models DL4EDC, DL8EDC
Installation & User Manual
Scope Communications UK Ltd, Quantum House, Steamer Quay, Totnes, Devon TQ9 5AL
Tel: +44 1803 860700 Fax: +44 1803
Digilink Uhf
Digilink Uhf
Digilink Uhf
Digilink Uhf
Digilink Uhf
863716 Email: sales@scope-uk.com Web: www.scope-uk.com
DIGEDC5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digilink MK2 DL4EDC and is the answer not in the manual?

Questions and answers

Related Manuals for scope Digilink MK2 DL4EDC

Summary of Contents for scope Digilink MK2 DL4EDC

  • Page 1 Models DL4EDC, DL8EDC Installation & User Manual Digilink Uhf Digilink Uhf Digilink Uhf Digilink Uhf Digilink Uhf Scope Communications UK Ltd, Quantum House, Steamer Quay, Totnes, Devon TQ9 5AL Tel: +44 1803 860700 Fax: +44 1803 863716 Email: sales@scope-uk.com Web: www.scope-uk.com DIGEDC5...

  • Page 2: Important Installation Information

    It is the purchasers’ responsibility to determine the suitability of this equipment and its derivatives for any given application, Scope cannot give specific advice in this manual, as each use will require independent evaluation. Scope has, wherever possible, employed extra safeguards or designed optional equipment to further monitor the system’s performance.

  • Page 3: Equipment Applications

    All applications should be thoroughly assessed by the installer in conjunction with the customer so as to minimize risk. Scope has no control of the use and application of the frequencies issued by the FCC. Some equipment that is individually licensed may have a greater degree of protection than other equipment that is operated on a FCC License Assignment basis.

  • Page 4: Warranty

    There are no other expressed or implied warranties except as stated herein, and those excluded include those of merchantability and fitness for a particular purpose. In no event will Scope or any of its agents be liable for direct, indirect, special incidental or consequential damages resulting from any defect in the product, even if advised of the possibility of such damages.

  • Page 5: System Overview

    DigiLink US, ECO DC Version System Overview The Scope DigiLink DL4DCUSA & DL8DCUSA are DC powered (12 to 13.8V dc), programmable radio paging systems which can be used to transmit both text and numeric messages direct to pocket pagers carried by individuals or entire groups.
  • Page 6 Coaxial cable intended for TV, Satellite or CCTV installations is normally 75 OHM and therefore totally unsuitable for any transmitter installation manufactured by Scope. Also remember that the performance of the system will be affected by the type of material the unit is mounted on and its surroundings.
  • Page 7 DigiLink US, ECO DC Version Installation The following procedure must be adhered to when installing the DigiLink paging system. Ensure you have taken into consideration all of the above information before selecting the location for your transmitter. If in doubt consult your dealer.
  • Page 8 DigiLink US, ECO DC Version Installation The Transcoder PCB contains static sensitive components. Care should be taken to avoid contact wherever possible and anti-static precautions should be observed during installation. DIGUSDCECO Issue 1...

  • Page 9: Section 2: System Operation

    DigiLink US DC Version Section 2: System Operation Confirmation of power connection is by way of the red LED on the front fascia. This will remain off until a zone is triggered. It will then blink continuously, except during transmission repeat periods or when the power source falls below 10.5V dc, when it will remain off.
  • Page 10 DigiLink US DC Version Transcoder PCB: terminal connections DIGUSDC 02/00 Issue 3...

  • Page 11: Other Antennas

    DigiLink US DC Version Other Antennas The range and performance of this equipment can be improved by the addition of more efficient antennas*. These can be installed either inside or outside the building and are connected to the transmitter with 50 OHM coaxial cable. Glass mount antenna (UHFGM): for installation on the inside of a suitable window.

  • Page 12: System Specification

    COM1: serial port for programming function only Footprint (mm): 184 (L) x 138 (W) x 45 (D) max excluding aerial Scope’s policy is one of continuous development and specifications are subject to change without prior notice DIGUSDC 02/00 Issue 3...
