Frigidaire GLRT215RB Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. GLRT215RB
  6. Factory parts catalog
Frigidaire GLRT215RB Factory Parts Catalog

Frigidaire GLRT215RB Factory Parts Catalog

Top mount refrigerator
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
GLRT215RBB0
GLRT215RB
GLRT215RBQ0
GLRT215RB
GLRT215RBW0
GLRT215RB
MARKET
North America
SERIES
COLOR
R134a Gallery
black
R134a Gallery
bisque
R134a Gallery
white
Publication No.
5995369856
020410
-EN/SERVICE/DCS
357
VOLTS
115
115
115

Advertisement

loading
Need help?

Need help?

Do you have a question about the GLRT215RB and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire GLRT215RB

Summary of Contents for Frigidaire GLRT215RB

  • Page 1 PRODUCT NO. BASE MODEL NO. GLRT215RBB0 GLRT215RB GLRT215RBQ0 GLRT215RB GLRT215RBW0 GLRT215RB MARKET North America SERIES COLOR R134a Gallery black R134a Gallery bisque R134a Gallery white Publication No. 5995369856 020410 -EN/SERVICE/DCS VOLTS...
  • Page 2 DOOR...
  • Page 3 A = GLRT215RB (GLRT215RBB0) B = GLRT215RB (GLRT215RBQ0) C = GLRT215RB (GLRT215RBW0) POS. NO PART NO 240514611 240514607 240514612 240514608 240337703 240381303 240381302 240381301 240450312 240450306 240450302 240449703 240449702 240449701 240312405 240312407 240312403 240312406 240312408 240312404 240494003 240494002 240494001 240383603...
  • Page 4 CABINET...
  • Page 5 A = GLRT215RB (GLRT215RBB0) B = GLRT215RB (GLRT215RBQ0) C = GLRT215RB (GLRT215RBW0) POS. NO PART NO 240355404 5308000010 5300157666 5303292396 240313603 240371303 10*# 240385302 5303208309 13 # 240369701 218931001 5303292397 215812200 16 # 218906801 240411901 218252200 215774918 215774919 215774901 240335501...
  • Page 6 SHELVES...
  • Page 7 A = GLRT215RB (GLRT215RBB0) B = GLRT215RB (GLRT215RBQ0) C = GLRT215RB (GLRT215RBW0) POS. NO PART NO 240358003 5303299664 240417802 240362601 14 # 240505801 240436701 241500701 240407301 17*# 240388701 240360801 21 # 5304421256 240468201 23 # 215846606 5303001259 240350119 240355228 240364718...
  • Page 8 SYSTEM...
  • Page 9 A = GLRT215RB (GLRT215RBB0) B = GLRT215RB (GLRT215RBQ0) C = GLRT215RB (GLRT215RBW0) POS. NO PART NO 240444401 218944001 240496101 240385302 6 *# 240388701 14 # 5303918247 15 # 5303918250 5308000110 240434002 240362301 240362401 21 # 5303918202 240330006 218252200 218513300 240491501...

  • Page 10: Ice Maker

    ICE MAKER...
  • Page 11 A = GLRT215RB (GLRT215RBB0) B = GLRT215RB (GLRT215RBQ0) C = GLRT215RB (GLRT215RBW0) POS. NO PART NO 218976901 5304420650 5308000039 3206299 3206301 3206303 3206305 3206306 3206312 3206313 3206315 11 # 3206319 12 # 5304420651 13 # 3206322 5304420652 15 # 3206324...

  • Page 12: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 13: Wiring Diagram

    WIRING DIAGRAM...
